DOUBLE CORNER SHOWER BASKET
USER GUIDE
John Lewis Partnership
171 Victoria Street
London SW1E 5NN
www.johnlewis.com
Made in Taiwan Please retain these instructions for future reference.
80930519
We recommend regular cleaning with a mild soap liquid and drying with a soft, lint
free cloth.The use of abrasive, powder or ammonia based cleaners and bleaches
WILL damage the product.
Care and Maintenance
Spare Parts
Parts Available
Missing any parts or require spares, please contact 03456 050 144
and we will be able to help.
- Wall xing pack
- Cover cap set
Please read the instructions carefully before use to ensure safe and satisfactory use
of this shower basket.
We recommend that this product should ONLY be installed by persons competent
in DIY. Please read the instructions carefully before use to ensure safe and
satisfactory use of this shower basket.
Please check the pack contents before attempting to assemble this product.
A full checklist of components is given in this leaet. If any components are missing,
please contact the branch from whom you bought this product.
The ttings pack contains SMALL ITEMS which should be KEPT AWAY
FROM YOUNG CHILDREN. Read this leaet carefully and in full before
commencing assembly.
1. Choose the position you would like to x your Shower Basket, making
absolutely sure that there are no buried pipes or electric cables in the wall.
2. Once you have selected your position, carefully mark the positions of
each hole with a pencil, & using a level to make sure that both holes
are horizontal.
3. Drill the holes to a depth of 30mm using a 5.5mm masonary drill
(please note that if drilling into tiles then a specialist drill bit should be
used) - & insert the 2 plastic plugs. (Please note that the wall plugs
provided are suitable for solid walls only, if xing into any other surface,
specialist xings are required. They can be obtained from a specialist
D.I.Y. outlet)
4. Once the plugs have been tted, & before the Shower Basket is xed
to the wall, assemble the screws with the collar.
5. Line the Shower Basket up with the 2 holes, insert the wall xing screws &
then carefully tighten each of them so that their collars t tightly against the
chrome upright.
6. Once both screws are in place & the Shower Basket is xed rmly to the
wall, nally t the 2 cover caps to the collars, again making sure that each
one ts tightly against the chrome upright. Hand tighten only.
Getting started
Necessary Tools
Fittings and parts
checklist
Wall screw xing -
if in doubt seek
professional advice
Fixing steps:
Parts Name Qty
Screw & Wall plug set
(Suitable for solid walls only)
1
Set of cover caps & collars 1
Type of Wall Wall Screw Fixing
Wood
If xing to wood make sure that it
isn’t chipboard as screws can easily
pull away from the core structure.
Brick or
Masonry
Use the wall plugs supplied,
provided you are sure your wall
is sound.
Cavity wall Special toggle wall plugs are
needed. Seek expert advice.
Please make sure that if you are tting this product above a shower tray or near a
basin that during xing you carefully cover these items with a suitable, protective
cover & take great care when using any tools so as not to damage any surfaces.
PLEASE BE AWARE THAT THE MAXIMUM WEIGHT RECOMMENDED
FOR THIS BASKET IS 5KG.
Safety Instructions
