Jetson Pinky Manuel utilisateur

USER MANUAL

MODEL #: JPNKY | VERSION #: 032017

PINKY

Three-in-One Scooter

Model #: JPNKY | Version #: 032017

Congratulations on your new Jetson 3-in-1 Pinky Scooter! Please

note, this is not an electric device. Before your rst ride, please

check whether the wheels are damaged, or parts are loose. If there

are any abnormalities, please contact Jetson Customer Support at

1-(888) 976-9904, or email customerser[email protected].

This product manual can help you understand, assemble, use, and maintain

your Jetson Pinky. In order to avoid danger caused by collisions, falls, and

loss of control, please use caution and learn how to ride the Jetson Pinky

safely. Jetson and authorized dealers cannot be held liable for injury or

damage caused from riding the Jetson Pinky. Falling, losing control, and colli-

sions (including failure to obey the Jetson Pinky manual) may cause injury. In

order to minimize the risk, ensure you read the Jetson Pinky manual careful-

ly. Users ride at their own risk.

The user is responsible for consequences caused by violating warnings or

improper operations.

If for any reason you want to return this product, please call us at 1-(888)

976-9904 or email us at customerservice@jetsonbike.com before returning

it to the store.

WHAT’S IN THE BOX:

• 1 x Pinky Scooter

• 1 x Seat Housing (Seat

and Front Covering)

• 1 x Removable Drawer

• 1 x Sliding Sleeve

• 3 x Allen Wrench

Model #: JPNKY | Version #: 032017

FOR YOUR SAFETY:

• This product is suitable for children age 2-6+, and for use on private

property and closed courses. Always ride defensively, and watch out for

potential obstacles that may catch your wheel or cause you to swerve sud-

denly.

• The Jetson Pinky should always be used under supervision.

• Always check any local laws or regulations which may a󰀨ect where the

Jetson Pinky may be used.

• Ride at your own risk and use common sense. Any rider that is unable to t

comfortably on the product should not attempt to ride it. All decisions on who

is allowed to ride the Jetson Pinky should be made based on their maturity,

skill, and ability to follow the rules.

• The Jetson Pinky is designed for one rider. Never carry passengers, and do

not attach the Jetson Pinky to other objects.

• This product was manufactured for performance and durability, but is not

impervious to damage. Jumping and aggressive riding should be avoided

under all circumstances. The rider assumes all responsibility and risk associ-

ated with high-stress activity.

• Keep your ngers and other body parts away from all other moving compo-

nents when operating the Jetson Pinky. Keep your hands on the handlebars

at all times.

• Do not wear headphones or use a cell phone while operating the Jetson

Pinky.

• Do not operate the Jetson Pinky in wet or icy weather, and never immerse

the product in water.

• Avoid excessive speeds when riding downhill, as it increases the risk of

accident and injury. Avoid wet, slick, bumpy, uneven or rough surfaces while

using the Jetson Pinky. Never risk damaging surfaces such as carpet and

ooring by using the product indoors.

• Do not ride at night, or when visibility is limited.

• Always wear proper protective equipment, such as a helmet, elbow pads,

and knee pads. Athletic shoes with rubber soles are best for riding the Jet-

son Pinky.

• Never operate the product barefooted or in sandals, and keep shoelaces

tied and away from the wheels.

• The brake may become hot while operating, do not touch the brake with

your bare skin.

• Make sure all screws are tightened, and all clamps and locks are properly

secured before riding.

Model #: JPNKY | Version #: 032017

OVERVIEW:

UNFOLDING THE PINKY:

To unfold your Pinky,

insert the long Allen

Wrench into the hole of

the Steering Rod and pull

up (Figure A).

NOTE: Images of the product in this instruction manual may differ slightly from the product itself.

While pulling up with the

Allen Wrench, lift the

Handlebar away from the

Deck (Figure B).

The unfolding process

is complete when the

Steering Rod is upright

and locked in place

(Figure C).

Model #: JPNKY | Version #: 032017 4

To fold your Pinky for

storage, insert the long

Allen Wrench into the

Steering Rod and pull

up (Figure D).

SEAT AND DRAWER INSTALLATION:

To install the seat

and drawer, rst

slide the Seat

Housing onto the

Steering Rod.

EASY FOLDING COVER INSTALLATION:

The Easy Folding Cover is a very useful attachment that allows you to easily fold and

unfold your Pinky once you no longer use the Seat Housing and Drawer. Please note

that you will not be able to install or use the Seat and Drawer while the Easy Folding

Cover is installed. To install the Sliding Sleeve, you must rst remove the Collar Clamp

which has two screws and the T-Bar.

Slide the Front

Covering around

the Steering Rod

until the screw

holes align with

the Seat Housing.

Use the Allen

Wrench to secure

the screw rmly into

the nut by turning

clockwise through

the Front Covering

and Seat Housing.

Once the Seat

Housing is secured

to the Pinky, slide

the Drawer into the

Seat Housing.

FOLDING THE PINKY:

While pulling up with

the Allen Wrench,

lower the Handlebar

towards the Deck

(Figure E).

The folding process is

complete when the Steer-

ing Rod is at against

the Deck and locked in

place(Figure F).

Model #: JPNKY | Version #: 032017

Open the lever on the Col-

lar Clamp and use the Allen

Wrench counter-clockwise

to loosen the screw that is

screwed into the steering

rod (Figure A).

Remove the Collar Clamp

from the Steering Rod by

lifting up (Figure D).

To unfold the Pinky using the Easy Folding Cover, slide the Easy Folding Cover up the

Steering Rod and raise the Handlebar until it locks into place. To fold the Pinky up for

storage, slide the Easy Folding Cover up the Steering Rod and lower the Handlebar

towards the Deck.

Then, loosen the

second screw on

the Collar Clamp

(Figure B).

Press the Height

Adjustment Button

on the Steering Rod

and pull the T-Bar

out (Figure C).

Before installing the Easy

Folding Cover, your Pinky

should look like Figure E.

Put the Easy Folding Cover

on the Steering Rod, and line

up the screw holes featured

in Figure E.

Tighten the screws us-

ing two Allen Wrenches

(Figure F). Reinstall the

Collar Clamp and T-Bar

before attempting to

use the Pinky.

Model #: JPNKY | Version #: 032017

MAINTENANCE:

To change the Deck, loosen the six screws

(labeled “A”) from the bottom of the deck. Re-

move the deck, and replace with a new deck.

Tighten all six screws back in place before at-

tempting to ride. Once you have replaced the

deck, check the screws after riding to ensure

that they remain tight.

To change the Brakes, loosen the six screws

(labeled “A”) from the bottom of the deck.

Then, remove the deck and loosen the two

brake screws (labeled “B”). Replace the brake

and tighten the brake screws, then reattach

the deck and tighten all six deck screws.

To change the Steering Spring, loosen the

four screws (labeled “C”) from under the front

wheels. Then, remove the mudguard and

loosen the two spring screws (labeled “D”).

Pull the spring upwards to remove it. Once

the new spring is inserted, screw in the spring

screws, reattach the mudguard, and tighten

the four screws under the front wheels.

To change the Collar Clamp, loosen the

two screws (labeled “E” and “F”) on either

side of the Collar Clamp. Then, lift the Collar

Clamp upwards to remove it. Once the new

Collar Clamp has been added, tighten the two

screws on either side of it.

To change the Sliding Sleeve, rst remove

the Collar Clamp (as described above). Then,

loosen the two screws (labeled “G”) on either

side of the Sliding Sleeve. Then, lift the Collar

Clamp upwards to remove it. Once the new

Collar Clamp has been added, tighten the two

screws on either side of it.

PRODUCT REGISTRATION

Please complete and mail this card within 10 days of purchase.

Name: _____________________________________________________________________

Age: _______________________________________________________________________

Address: ___________________________________________________________________

City, State, Zip: _____________________________________________________________

Email: _____________________________________________________________________

Home Phone: __________________ Work Phone: ________________________________

Purchase Date: ___________ Purchased from: _________________________________

Serial Number: _____________________________________________________________

Product: ___________________________________________________________________

Gender: _______________ Occupation: ________________________________________

Is this your rst Jetson product? _____________________________________________

Other similar product owned before: _________________________________________

How did you hear about the Jetson® Pinky?

____________________________________________________________________________

Complete this form and mail it to:

Attention: Product Registration

Jetson Electric Bikes

1 Rewe Street

Brooklyn, NY 11211

WWW.JETSONBIKE.COM

• ELECTRIC MOPED

• ELECTRIC SKATEBOARD

...AND MORE!

• ELECTRIC BICYCLE

• FOLDING ELECTRIC SCOOTER

IF YOU LIKE THIS PRODUCT, PLEASE CHECK OUT THE

OTHER PRODUCTS ON OUR WEBSITE, INCLUDING OUR:

A LEADER

IN ELECTRIC TRANSPORTATION

888-976-9904

CUSTOMERSERVICE@JETSONBIKE.COM
