Cyclonic Dust Collection System

With the best air ow in its class,

this unit will function better than

others in small to medium size

production shops, as well as larger

home shops. The cyclonic action of

the JET® Dust Collection System

 lters out 99% of all the chips and

dust before it ever has a chance

to pass through the impeller or hit

the  nal  lter. Dust and chips are

deposited into an easily disposable

drum and garbage can. The  nal

 lter cleans the remaining particles

before allowing the air to pass back

into the shop.

STOCK NO. 900817

5M 07/05

©2005 WMH TOOL GROUP, Inc. All Rights Reserved.

HIGH EFFICIENCY

CYCLONIC DUST COLLECTION SYSTEM

 Cyclonic action

separates the heavier chips and particles and disposes of

them into the 55-gallon drum

 Large 8-in, 14-in. steel impeller

creates high velocity air ow, lets lighter dust particles pass

through and be trapped in the lter

 Filter bag

provides almost 40 sq. ft. of ltration surface area of all

particles 5 microns or larger

 Collection bag has “snap-in” design

for quick, easy installation and removal

 EXCLUSIVE pressure tube

allows use of a plastic collection bag in the drum without

getting sucked into the cyclone

 Special rectangular inlet pipe

for added separation and additional air ow

 Steel construction with welded seams and

powder-coated paint

ensures long, dependable performance

 3HP motor is totally enclosed and fan-cooled

to keep dust and contaminants out

STOCK NUMBER 708653K 708654K

Model JC-3BF JC-3CF

Impeller diameter (in.) 14 14

Impeller ns 8 8

Impeller material Steel Steel

Air inlet (in.) 8 8

Air outlet (in.) 8 8

Separator tank diameter (in.) 19-1/2 19-1/2

Separator tank height (in.) 17-3/8 17-3/8

Filter (dia. x H/in.) 20 x 90-1/2 20 x 59-1/2

Filter Specications/Filtration 99% @ 5 micron /

39.64 sq. ft.

99% @ 2 micron /

130 sq. ft.

Max. Air Flow w/Filters (CFM) 1450 1450

Max. Static Pressure (in. of

water) 12.12 12.12

Sound Rating @ 3 ft. 80 dB 80 dB

Overall Dimension

(L x W x H/in.) 67-3/4 x 45-3/8 x 111 67-3/4 x 45-3/8 x 111

Motor 3HP, 1Ph, 230V 3HP, 1Ph, 230V

Net Weight (lbs.) 257 280

Steel Dust Collection

Components

2-Micron

Canister Filter

708655

Dust Collection Hose Plastic Dust Collection

Components

OPTIONAL ACCESSORIES

5-Micron Filter Bag

708654

jettools.com

CYCLONIC DUST COLLECTION SYSTEM

Quick-Install

Collection Bag

55-gallon

Drum

Casters

Solid Steel

Construction

EXCLUSIVE

Pressure

Tube

3HP

Motor

2-Micron

Canister

Filter

Collector barrel

not included

5

YEAR

WARRANTY
