Jenn-Air JFC2089HEP13 Manuel utilisateur
CABINET PARTS
1
12−08 Litho In U.S.A. (mat)(bay) Part No. W10242320 Rev.A
REFRIGERATOR
For Models: JFC2089HES13, JFC2089HEP13
(Stainless) (Stainless)
CABINET PARTS
2
For Models: JFC2089HES13, JFC2089HEP13
(Stainless) (Stainless)
W10242320
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
1 Literature Parts
67006616 Tech Sheet
W10137647
Owners Manual
67005643 Energy Guide
2
W10137519
Elbow, Fill Tube
3 67003405 Block, Pivot
4 B5759649 Gasket
5 Cover, Right Hinge
12684202B
Black
6 Cabinet (Not A
Serviceable Part)
7 67006118 Roller Assy.(Rear)
8 67006287 Screw
9 67006521 Screw
10
12566604ED
Hinge, Top Right
11 67006380 Screw (6)
12 67006697 Bolt, Adjusting
(Rear)
13 Cover, Left Hinge
8208248 Black
14 67006303 Screw (6)
15 Hinge, Center
67006443 Black, Right
67006442 Black, Left
16 67004092 Block, Fill Tube
17 Cover, Corner (2)
67003485 Black
18
12566605ED
Hinge, Top Left
19 Roller Assy.
(Front)
W10130459
Right
W10130460
Left
20 67006564 Screw (8)
21 12579702 Shim, Hinge
22 Grille, Toe
W10131134
Black
23 M0108105 Clamp, Tube
25 67006425 Screw (10)
26 67003331 Cover, Water Line
27 67004098 Cover, Water Valve
28 67006669 Screw (2)
29 67004101 Sweep, Dual Tube
30 67006101 Cover, Unit
31 67001067 Clip, Drain Tube
32 A3076901 Plug, Button
33 67003796 Insulation, Sound
34
W10141622
Brake, Foot
35 M0104106 Clip (2)
36 67001066 Tube, Drain
37 M0114003 Clip
FREEZER LINER PARTS
3
For Models: JFC2089HES13, JFC2089HEP13
(Stainless) (Stainless)
W10242320
FREEZER LINER PARTS
4
For Models: JFC2089HES13, JFC2089HEP13
(Stainless) (Stainless)
W10242320
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Seviceable Part)
2 67001291 Gasket, Foam
3 67005874 Guide, Fill Tube
4 67003905 Cover, Light
5 67003636 Motor, Evaporator
6
Y12570701
Socket, Light
7 12002355 Thermistor
8 67003924 Cover, Thermistor
9 A0282812 Bulb, Light
10 67001035 Housing, Light
11 67005873 Cover, Evaporator
12 67006425 Screw (4)
13
W10121318
Grommet
14 67003906 Module, Fz Control
15
W10167028
Clip, Evap Motor
16 67005653 Switch, Light
17 67006530 Screw
18 D7753903 Funnel, Drain
19 M0500703 Seal
20 67002492 Gasket, Bottom
21 B8381501 Gasket
22
W10175909
Grille, Fz Air
23
W10167023
Shroud, Evap Fan
24 2169142 Blade, Fan
(Evaporator)
25 Bracket, Door
W10119064
Left
W10119295
Right
26 67006473 Screw (8)
27 Cradle, Basket
67004728 Left
67004729 Right
28
W10180420
Slide, Drawer (2)
29 Adapter, Slide
67004971 Left
67004972 Right
30 67006406 Screw (6)
31 67004017 Shaft
32 12002497 Gear
(Includes RH & LH)
Following Parts Not Illustrated
67006095 Harness, Fz Module
REFRIGERATOR LINER PARTS
5
For Models: JFC2089HES13, JFC2089HEP13
(Stainless) (Stainless)
W10242320
REFRIGERATOR LINER PARTS
6
For Models: JFC2089HES13, JFC2089HEP13
(Stainless) (Stainless)
W10242320
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Serviceable Part)
2 67004078 Module, Light
3 67005445 Keyboard
4 67005444 Module, Control
5 67005397 Board, Control
6 C3680310 Switch, Light (2)
7 67003897 Cover, Light
8 67003901 Housing, Light
9 A0282812 Bulb, Light (2)
10
Y12570701
Socket, Light (2)
11 67003900 Insert,
Damper Cover
12 67006602 Screw
13 67003899 Cover, Damper
14 67006604 Insulation
15
W10127429
Control, Damper
16 12002355 Thermistor
17 67001668 Plate
18 67006524 Head, Water Filter
19
UKF8001AXX
Filter, Water
20 12568001 Cover, Filter
21 67006415 Screw (2)
22 B8390302 Clip, Facade (2)
23
W10158503
Facade, Disp.
24 67002742 Plate, Switch
25 12575501 Switch, Limit
26 67003728 Guide, Waterline
27 67002816 Clip, Waterline
28 67005674 Facade, Disp (Top)
29
W10153959
Tank, Water
30 61006182 Union
31 12664501 Plug, Bypass
32 67006400 Screw
33
W10163893
Insulation, Water
Tank
Following Parts Not Illustrated
67005417 Harness, Control
(Refrigerator)
REFRIGERATOR DOOR PARTS
7
W10242320
For Models: JFC2089HES13, JFC2089HEP13
(Stainless) (Stainless)
REFRIGERATOR DOOR PARTS
8
For Models: JFC2089HES13, JFC2089HEP13
(Stainless) (Stainless)
W10242320
Illus. Part
No. No. DESCRIPTION
1 Door, Left
13024033SQ
Stainless
2 Door, Right
13024031SQ
Stainless
3 67003637 Door, Dairy
4 67001279 Tray, Dairy
5 67004748 Bin, Shelf (3)
6 67006786 Screw
7
W10133608
Screw, Mount
8 Gasket, Door (2)
12723206B
Black
10 67006109 Mount, Handle
11 67002731 Bushing, Door
(Bottom Right)
12 67004749 Bin, Shelf (2)
13 67002721 Bushing, Door
(Bottom Left)
14 Mullion, Door
67003264 Black
15 67006287 Screw
16 Closure, Door
67003639 Black
17 Stop, Door
67007011 Black
18 Plug, Button
67004838 Black
19 Bushing, Door
(Upper Left)
12395501B
Black
20 Bushing, Door
(Upper Right)
67004978 Black
21 12848704 Nameplate
25 Handle, Door
12850910 (JFC2089HES13)
12859109 (JFC2089HEP13)
UNIT PARTS
9
W10242320
For Models: JFC2089HES13, JFC2089HEP13
(Stainless) (Stainless)
UNIT PARTS
10
For Models: JFC2089HES13, JFC2089HEP13
(Stainless) (Stainless)
W10242320
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
1 67006433 Screw
2
W10162928
Blade, Fan
3 67005889 Basepan
4 67006425 Screw (2)
5 67005491 Block, Condenser
6 67004700 Tube, Discharge
7
W10119857
Harness, Evap
Heater
8 67007175 Pan, Drain
9 61004743 Grommet (3)
10 67002493 Heater, Defrost
11 67007052 Clip, Capacitor
12 67005561 Relay, Start
13 61003210 Gasket
14
W10165425
Thermostat, Def.
15 67005680 Grommet (2)
16 67006573 Screw (4)
17 67003493 Grommet (4)
18 67006131 Condenser
19 67006432 Screw (3)
20 67002490 Tray, Drip
21 67006737 Screw
22 12002041 Evaporator Kit
(Incl. Evap., Heat
Shield, & Instr.
Sheet)
23 Dam
67001084 Right Side
67001083 Left Side
24 67004432 Motor, Fan
25 10428101 Clip, Heater
26 13060201 Harness, Unit
with Power Cord
27 2317845 Drier
28 67005565 Compressor Kit
(Includes Items
12,17,27,& 30)
29 67005562 Capacitor
30 67005419 Harness, HV
31
W10158508
Shroud
32 67004953 Bracket, Fan Motor
33 67004954 Screw (3)
34 10547003 Clip, Drier
35 67006615 Screw, Cover
36
W10137529
Grommet, Cond. (4)
37 10623002 Clip, Evaporator
38 67004969 Box, HV
39
W10173398
Board, HV Control
(Inc. Inst. Sheet)
40 67005418 Spacer, HV Box
41 67006550 Screw (2)
42 67005421 Cover, HV Box
Following Parts Not Illustrated
and Optional Parts Not Included
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
876764 Valve, Access
(3/16")
REFRIGERANT CHARGE
5.0 Ozs.
(R−134A)
