All-in-one type Full HD sports camera with 2.0” screen
1
PREFACE
Thank you for purchasing the high resolution digital camcorder. The
camcorder is a small, all-in-one design that is convenient for you to record activities
anytime and anywhere. With the high speed dynamic photograph function, it can
clearly record any activity, and let you share the experience with anybody.
Please read this manual carefully to ensure you understand it before using this
product. Please also keep this manual safe for future reference.
PRODUCT ASSURANCE
This product has authoritative CE, RoHS & FCC certication to assure customer
safety when using it.
PRODUCT OVERVIEW
The camcorder has world leading digital video/photography/audio storage,
high-speed HDMI video transmission and other functions, as well as a number
of invention patents & technical patents.
Getting Started
Getting Started
19 20 21 22
2
1. 110°lens
2. Horizontal laser light
3. Camera shutter
4. [⊙]Press and Hold for 2 seconds to
power on or power o the Cam
5. Recording key
6. Turn on or turn o the horizontal laser light
7. 200°rotating lens
8. Recording indicator
9. External MIC interface
10. Wired-Remote jack、USB jack、AV-OUT jack
11. 1/4 Screw Thread
12. Lanyards orice
13. Power indicator
PRODUCT STRUCTURE
14. Locking key of rear cover
15. Internal MIC
16. Loudspeaker
17. 2-inch LCD Screen
18. Playback integrated key
19. Battery Holder
20. HDMI output jack
21. Micro-SD Holder
22. Screen Cover
MAIN UNIT
HDMI OUT
CARD/BATT
OPEN
▲
HDMI OUT
CARD/BATT
OPEN
▲
▲
3
Installing the Battery
1. Slide the lock on the rear cover and it will automatically open. (Refer to picture1)
2. Follow the instructions. Insert the battery with the correct Polarity (+/-). (Refer to picture2)
3. Push the rear cover closed. (Refer to picture3)
NOTE: IF YOU DO NOT INTENT TO USE THE PRODUCT FOR
A LONG TIME, PLEASE REMOVE THE BATTERY. BATTERIES
CONTAIN CHEMICAL SUBSTANCES SO THEY SHOULD BE
HANDLED AND DISPOSED OF CORRECTLY.
Installing the Micro-SD card
1: Slide the lock on the rear cover and it will automatically open. (Refer to picture4)
2: Follow the instructions. Insert the SD card in the correct direction. (Refer to picture 5)
3: Push the back cover to the closed position. (Please refer to picture6)
NOTE: THE CAMECORDER REQUIRES A CLASS 4 OR ABOVE SD
CARD TO OPERATE CORRECTLY. MOST FAULTS WITH
OPERATING CAMERAS ARE BECAUSE A CHEAP SD CARD
IS USED. CHOOSE ADDITIONAL SD CARD WITH CARE.
Picture2 Picture3
Picture5 Picture6
Basic Operations
Basic Operations
Basic Operations
REC
4
Picture2 Picture3
Recording Instructions
1.Press [⊙] key and hold for 2 seconds to power up the camera.
2. Adjust the lens to the proper angle.
a) Face a blank surface and press [⊙] to turn on the lasers ( The lasers will disappear in 15
seconds). The laser can be turned on or o at any time with the laser light button.
b) Check whether the laser light is horizontally aligned. If not, rotate the lens until it is in
the horizontal state. （Refer to picture1）
WARNING: DO NOT DIRECT THE LASER LIGHT INTO ANYBODY’S EYES
The indicator light glows green to indicate standby mode.
3. Start / stop recording
a) Slide the recording switch forward. The recording indicator ( red ) turns on and ashes
while camera beeps (These audio beeps can be turned o in the menu), and camera is
recording . (Refer to picture2)
b) To stop recording, slide the switch backwards, the camera beeps and the indicator light
turns green indicating standby mode. (Refer to picture3)
* With the LCD screen constantly on the battery will only last for approximately 30 minutes.
By pressing the LCD button the screen will turn o and then the battery will last for 2-3
hours. By pressing the LCD button for 2 seconds the camera will completely turn o.
* The LCD screen will shut o automatically 30 seconds after the camera starts recording,
and the LCD screen will also shut o automatically 60 seconds when in standby mode if
no keys pressed. It allows more time to the user for tuning the camera. But the LCD
won’t shut o during Playback mode.
Basic Operations
Basic Operations
DIGITAL
REC
DIGITAL
5
Start / stop Recording Via Wired Remote
Press [⊙] key ( hold for 2 seconds ) to power up the camera.
1. Connect wired remote to the DIGITAL interface of camera (Refer to picture 1)
2: Press [REC] key on the wired remote to start recording, recording indicator ( red ) turns
on and ashes when it is recording.
3. During recording, press [REC] key on wired remote again to stop, and recording indicator
turns o when camera stops recording.
Start / stop recording automatically by power-on wired remote.
1. Connect one end of power-on wired remote to the DIGITAL interface on the camera.
(Refer to picture 1)
2: Connect the other end of power-on wired remote to a 5V power source. (Refer to picture 2)
As long as the DC5V input is detected by camera it will start recording automatically.
During recording, if DC5V is stopped being detected by camera, then it will stop recording
automatically.
NOTE: 1. YOU MUST HAVE A WELL CHARGED BATTERY INSERTED IN TO THE CAMERA FOR THE AUTO
5V INPUT AUTO RECORD FUNCTION TO WORK CORRECTLY.
2. IN STANDBY MODE OR RECORDING MODE YOU CAN ENTER INTO REAL-TIME PREVIEW
IMAGES AFTER OPENING THE LCD.
3. IN STANDBY MODE OR RECORDING MODE YOU CAN ENTER INTO REAL-TIME PREVIEW BY
CONNECTING THE CAMERA TO OTHER DISPLAY DEVICES.
4. IN RECORDING MODE YOU CAN CONNECT AN EXTERNAL MIC TO ENHANCE AUDIO
RECORDING , AND EXTERNAL MIC AND INTERNAL MIC AUDIO RECORDING CAN BE MIXED.
Basic Operations
Basic Operations
MOVIE
100-0014
6
Picture2 Picture3
Picture Shooting Instructions
In standby mode , press [ ] key to take photos. (Refer to picture1)
Picture Resolution: 5 mega pixels
Picture Size: 2560 x 1920
Playback Instructions
1. Playback on the camera
a)Press and push the screen cover backwards to open it. (Refer to picture1)
b)Gently press [LCD] key , and the screen will come on.
c)Press [MODE] to switch until you see the Play Mode, the screen shows 6 video les per
page in grid form.
d)Press [+][-] to choose which video to play, the video will be highlighted with yellow
borders, press [ ‖]to start recording, and press again to stop.
e)When playing video, user can short press [+][-] to turn up or turn down the volume.
f)When playing video, user can Long press [+][-] to Fast forward or reverse at X2/X4/X8.
g)Press[MODE]to stop playback, and return to the video les listing.
h)Gently press [LCD]key to turn the LCD screen o.
i)Push the rear cover back on to protect the screen when not in use.
Push the screen cover by this way.
Basic Operations
A
BC
D
E
7
Mount Installation
Mount Installation
MOUNTS
A .Cradle: with two 1/4 tripod threads tted for use with other mounts as shown
below, this camera can be widely used with any equipment and any application.
B. Goggle Strap Mount: can be xed on to your goggle strap and any other elastic
band or strap.
C. Flat Mount: With a high performance, waterproof and heat-resistant 3M sticker
at the back, it is ideal for at, non-porous surfaces.
D. Bar Mount: with 3 sizes of rubber, the camera can be mounted on to the tubes
of mountain bike handle bars, roll bar cages etc.
E: Vented Helmet Mount, with the Velcro strap is ideal for mounting the camera to
various styles of vented helmets.
Main Mount
Bar Mount
Note: 1) Other mounts require this main mount for installing
2) Tripod thread on device for installing on surface
Main Mount
Bar Mount
3 × Rubber Insert
1 × Hand screw
Step 1
to adapt dierent bike bar
Step 2
Step 3
Step 4
Step 1 Step 2
Note: please choose the proper rubber insert of dierent thicknesses.
8
AV OUT
DIGITAL
100°
100°
MIC -IN
AV OU T
DIGITAL
Bike bar
Ruber insert
Mount Installation
