3.6V Grass Shearer

Instruction Manual

Model Ref: ZQ558

INTRODUCTION

Thank you for choosing this 3.6V Cordless Shearer.

This product is manufactured to the highest standards of

performance and safety.

Before use, please read this manual carefully. It gives

important instructions about safety, use and maintenance of

your device.

Remove all packaging material. You may wish to keep

the packaging for future use or storage of your device.

Alternatively, dispose of accordingly.

CONTENTS

Introduction.....................................................01

Important Safety Information ........................02

Special Safety Instructions ...........................06

Product Overview...........................................07

Using The Shearer..........................................08

Starting The Machine .....................................08

Specication ...................................................11

IMPORTANT SAFETY INFORMATION

WARNING - Read all safety warnings and all instructions.

Failure to follow the warnings and instructions may result in

electric shock, re and/or serious injury. Save all warnings

and instructions for future reference. The term “power tool”

in the warnings refers to your mains-operated (corded)

power tool or battery-operated (cordless) power tool.

Work area safety

- Keep work area clean and well lit. Cluttered or dark areas

invite accidents.

- Do not operate power tools in explosive atmospheres,

such as in the presence of ammable liquids, gases or dust.

Power tools create sparks which may ignite the dust or

fumes.

- Keep children and bystanders away while operating a

power tool. Distractions can cause you to lose control.

Electrical safety

- Power tool plugs must match the outlet. Never modify the

plug in any way. Do not use any adapter plugs with earthed

(grounded) power tools. Unmodied plugs and matching

outlets will reduce risk of electric shock.

- Avoid body contact with earthed or grounded surfaces,

such as pipes, radiators, ranges and refrigerators. There is

an increased risk of electric shock if your body is earthed or

grounded.

- Do not expose power tools to rain or wet conditions. Water

entering a power tool will increase the risk of electric shock.

- Do not abuse the cord. Never use the cord for carrying,

pulling or unplugging the power tool. Keep cord away from

heat, oil, sharp edges or moving parts. Damaged

or entangled cords increase the risk of electric shock.

- When operating a power tool outdoors, use an extension

cord suitable for outdoor use. Use of a cord suitable for

outdoor use reduces the risk of electric shock.

- If operating a power tool in a damp location is

unavoidable, use a residual current device (RCD with a

tripping current of 30 mA or less) protected supply. Use

of an RCD reduces the risk of electric shock. NOTE the

term “residual current device (RCD)” may be replaced by

the term “ground fault circuit interrupter (GFCI)” or “earth

leakage circuit breaker (ELCB)”.

Personal safety

- Stay alert, watch what you are doing and use common

sense when operating a power tool. Do not use a power

tool while you are tired or under the inuence of drugs,

alcohol or medication. A moment of inattention while

operating power tools may result in serious personal injury.

- Use personal protective equipment. Always wear eye

protection. Protective equipment such as dust mask, non-

skid safety shoes, hard hat, or hearing protection used for

appropriate conditions will reduce personal injuries.

- Prevent unintentional starting. Ensure the switch is in

the o󰀨-position before connecting to power source and/or

battery pack, picking up or carrying the tool.

Carrying power tools with your nger on the switch or

energizing power tools that have the switch on invites

accidents.

- Remove any adjusting key or wrench before turning the

power tool on. A wrench or a key left attached to a rotating

part of the power tool may result in personal injury.

- Do not overreach. Keep proper footing and balance at

all times. This enables better control of the power tool in

unexpected situations.

- Dress properly. Do not wear loose clothing or jewellery.

Keep your hair, clothing and gloves away from moving

parts. Loose clothes, jewellery or long hair can be caught in

moving parts.

- If devices are provided for the connection of dust extraction

and collection facilities, ensure these are connected and

properly used. Use of dust collection can reduce dust-related

hazards.

Power tool use and care

- Do not force the power tool. Use the correct power tool for

your application. The correct power tool will do the job better

and safer at the rate for which it was designed.

- Do not use the power tool if the switch does not turn it on

and o󰀨. Any power tool that cannot be controlled with the

switch is dangerous and must be repaired.

- Store idle power tools out of the reach of children and do

not allow persons unfamiliar with the power tool or these

instructions to operate the power tool.

Power tools are dangerous in the hands of untrained users.

- Maintain power tools. Check for misalignment or binding of

moving parts, breakage of parts and any other condition that

may a󰀨ect the power tool’s operation. If damaged, have the

power tool repaired before use. Many accidents are caused

by poorly maintained power tools.

- Keep cutting tools sharp and clean. Properly maintained

cutting tools with sharp cutting edges are less likely to bind

and are easier to control.

- Use the power tool, accessories and tool bits etc. in

accordance with these instructions, taking into account the

working conditions and the work to be performed. Use of the

power tool for operations di󰀨erent from those intended could

result in a hazardous situation.

Service

- Have your power tool serviced by a qualied repair person

using only identical replacement parts. This will ensure that

the safety of the power tool is maintained.

Battery/Battery charger safety warnings

- Protect the battery charger from rain and moisture. The

penetration of water in a battery charger increases the risk of

electric shock.

- Recharge only with the charger specied by the

manufacturer. A charger that is suitable for one type of

battery pack may create a risk of re when used with another

battery pack.

- Do not charge other batteries. The battery charger is

suitable only for charging lithium ion batteries within the listed

voltage range. Otherwise there is danger, re and explosion.

- Keep the battery charger clean. Contamination may cause

the danger of electric shock.

- Check the battery charger, cable and plug each time before

using. Do not use the battery charger when defects are

detected. Do not open the battery charger yourself and have

it repaired only by qualied personnel using original spare

parts. Damaged battery chargers, cables and plugs increase

the risk of electric shock.

- Do not operate the battery charger on easily inammable

surfaces (e. g. paper, textiles, etc.) or in combustible

environments. There is danger of re due to the heating of

the battery charger during charging.

- Under abusive conditions, liquid may be ejected from the

battery; avoid contact. If contact accidentally occurs, ush

with water. If liquid contacts eyes, additionally seek medical

help. Liquid ejected from the battery may cause irritation or

burns.

- Do not open the battery yourself. There is danger of a short

circuit.

- Protect the battery against heat, e.g., including against

continuous sun irradiation and re. There is a danger of

explosion.

- Do not short-circuit the battery. There is a danger of

explosion.

- In case of damage and improper use of the battery,

vapours may be emitted. In case of complaints, provide for

fresh air and consult a physician. The vapours can irritate

the respiratory system.

SPECIAL SAFETY INSTRUCTIONS

- Keep all parts of the body away from the cutter blade. Do

not remove cut material or hold material to be cut when

blades are moving. Make sure the switch is o󰀨 when clearing

jammed material. A moment of inattention while operating

the hedge trimmer may result in serious personal injury.

- Carry the hedge trimmer by the handle with the cutter

blade stopped. When transporting or storing the hedge

trimmer always t the cutting device cover.

Proper handling of the hedge trimmer will reduce possible

personal injury from the cutter blades.

- Hold the power tool by insulated gripping surfaces only,

because the cutter blade may contact hidden wiring or its

own cord. Cutter blades contacting a “live” wire may make

exposed metal parts of the power tool “live” and could give

the operator an electric shock.

- Keep cable away from cutting area. During operation the

cable may be hidden in shrubs and can be accidentally cut

by the blade.

PRODUCT OVERVIEW

Operating Controls

1 Blade

2 Button for battery power status display

3 Charger LED-indicator

4 Safety lock

5 Handle

6 On/O󰀨 switch

7 SDS drive cover

8 Battery charger

9 SDS drive cover release button

STARTING THE MACHINE

WARNING! Only use this machine for applications that will not

cause harm or damage to the user or the product.

Starting:

Push in safety lock 4 and press On/O󰀨 switch 6 at the same

time, Release safety lock 4.

Stopping:

Release the On/Off switch 6.

Cutting hedges

- Before cutting check the hedge for foreign objects e. g. wire

fences.

- Cut stems up to 8 mm in thickness. When cutting, move

steadily along the line of cut, so that stems are fed directly into

the cutter blades. The double edge of the cutting blade enables

cutting to either direction, or with a side to side motion.

- After use replace the blade transport guard.

Recommended cutting/trimming times:

- Cut hedges with deciduous leaves in June and October.

- Cut evergreen hedges in April and August.

- Cut conifer and other fast growing shrubs approx. every six

weeks from May onwards.

Changing the blade

Wear gloves when changing the blade.

Removing

- Push the SDS-blade cover release button 9 and slide the cover

7 towards the On/O󰀨 switch 6. Lift away from the housing.

- Lift the blade 1 out.

Fitting

- Fit the blade as shown aligning the holes in the blade onto the

drive pins.

- When retting the SDS drive cover ensure all 5 location legs

are inside the housing prior to sliding cover into place.

- Slide the blade cover back towards the blade 1 to secure.

Maintenance

Note: To ensure long and reliable service, carry out the following

maintenance regularly.

- Check for obvious defects such as loose, dislodged

or damaged blade, loose xings and worn or damaged

components.

- Check that covers and guards are undamaged and correctly

tted. Carry out necessary maintenance or repairs before using.

- If the machine should happen to fail despite the care taken in

manufacturing and testing, repair should be carried out by an

authorized customer service agent.

- For all correspondence and spare parts orders, always include

the 10-digit part number (TYP) from the nameplate of the

machine!

Table des matières

Manuels Coupeur populaires d'autres marques

Milwaukee

Milwaukee HEAVY DUTY M12 FCOT Manuel utilisateur

Makita

Makita DCS552 Manuel utilisateur

SignWarehouse.com

SignWarehouse.com Bobcat BA-60 Manuel utilisateur

Makita

Makita 4112HS Manuel utilisateur

GEISMAR STUMEC

GEISMAR STUMEC MTZ 350S Manuel utilisateur

Hitachi

Hitachi CM 4SB2 Guide de dépannage

Dexter Laundry

Dexter Laundry 800ETC1-20030.1 Manuel utilisateur

GCC Technologies

GCC Technologies AFJ-24S Manuel utilisateur

DeWalt

DeWalt XR LI-ION DCS350N Manuel utilisateur

Baudat

Baudat ES1 Manuel utilisateur

Mafell

Mafell ZAF 200 Mode d’emploi

Makita

Makita 4100NH Manuel utilisateur

Formax

Formax FD 574 Manuel utilisateur

EINHELL

EINHELL TE-MA 1500 Manuel utilisateur

Husqvarna

Husqvarna Cut-n-Break K 760 Manuel utilisateur

CLEAN ROOM DEVICES

CLEAN ROOM DEVICES CRD130SS Manuel utilisateur

TRI tool

TRI tool 301A Manuel utilisateur

Roller

Roller King 1 1/4 Manuel utilisateur
