JBL CINEMA SB120 Manuel utilisateur

JBL CINEMA SB120

OWNER’S MANUAL

IMPORTANT SAFETY INSTRUCTIONS

Verify Line Voltage Before Use

The JBL CINEMA BAR 120 (soundbar) has been designed for

use with 100-240 volt, 50/60 Hz AC current. Connection to a

line voltage other than that for which your product is intended

can create a safety and re hazard and may damage the unit. If

you have any questions about the voltage requirements for your

specic model or about the line voltage in your area, contact your

retailer or customer service representative before plugging the unit

into a wall outlet.

Do Not Use Extension Cords

To avoid safety hazards, use only the power cord supplied with

your unit. We do not recommend that extension cords be used with

this product. As with all electrical devices, do not run power cords

under rugs or carpets, or place heavy objects on them. Damaged

power cords should be replaced immediately by an authorized

service center with a cord that meets factory specications.

Handle the AC Power Cord Gently

When disconnecting the power cord from an AC outlet, always

pull the plug; never pull the cord. If you do not intend to use this

speaker for any considerable length of time, disconnect the plug

from the AC outlet.

Do Not Open the Cabinet

There are no user-serviceable components inside this product.

Opening the cabinet may present a shock hazard, and any

modication to the product will void your warranty. If water

accidentally falls inside the unit, disconnect it from the AC power

source immediately, and consult an authorized service center.

www.jbl.com

English

TABLE OF CONTENTS

IMPORTANT SAFETY INSTRUCTIONS 2

1 INTRODUCTION 4

2 WHAT’S IN THE BOX 4

3 PRODUCT OVERVIEW 5

3.1 CONTROLS AND INDICATORS 5

3.2 CONNECTORS 5

3.3 REMOTE CONTROL 6

4 PLACE 7

4.1 DESKTOP PLACEMENT 7

4.2 WALL-MOUNTING 7

5 CONNECT 8

5.1 TV CONNECTION 8

5.2 BLUETOOTH CONNECTION 8

6 PLAY 9

6.1 POWER-ON/AUTO STANDBY/AUTO WAKEUP 9

6.2 PLAY FROM THE TV SOURCE 10

6.3 PLAY FROM THE BLUETOOTH SOURCE 10

7 SOUND SETTINGS 11

7.1 PRE-DEFINED EQ SETTINGS 11

7.2 VOICE MODE 11

8 RESTORE FACTORY SETTINGS 12

9 SOFTWARE UPDATE 12

10 PRODUCT SPECIFICATIONS 13

11 TROUBLESHOOTING 13

12 TRADEMARKS 14

13 OPEN SOURCE LICENSE NOTICE 15

1 INTRODUCTION

Thank you for purchasing the JBL CINEMA BAR 120 (soundbar)

which is designed to bring an extraordinary sound experience to

your home entertainment system. We encourage you to take a

few minutes to read through this manual, which describes the

product and includes step-by-step instructions for setting up and

getting started.

To make the most of product features and support, you

may need to update the product software through the USB

connector in the future. Refer to the software update section

in this manual to ensure that your product has the latest

software.

Designs and specications are subject to change without notice.

If you have any questions about the soundbar, installation or

operation, please contact your retailer or customer service

representative, or visit our website: www.jbl.com.

2 WHAT’S IN THE BOX

Unpack the box carefully and ensure that the following parts are

included. If any part is damaged or missing, do not use it and

contact your retailer or customer service representative.

Main unit

Remote control (with 2 AAA batteries)

(AAA)

Power cord*

* Power cord quantity and plug type vary by region.

HDMI cable

Wall-mounting kit

www.jbl.com

English

Product information & wall-mounting template 3 PRODUCT OVERVIEW

3.1 Controls and indicators

1 2 3 4

1. (Power)

• Switch on or to standby

2. -/+ (Volume)

• Decrease or increase the volume

• Press and hold to decrease or increase the volume

continuously

• Press the two buttons together to mute or unmute.

3. (Source)

• Select a sound source: Bluetooth (default) or HDMI

ARC (TV connected through the connector),

or Optical (TV / digital device connected through the

connector)

4. Status indicators

Solid red Entering standby mode

Solid white HDMI ARC source selected

Solid amber Optical source selected

Solid blue Connected to Bluetooth

Fast ﬂashing blue Entering Bluetooth pairing mode

Flashing blue Volume change ongoing

Slow ﬂashing blue Maximum volume level reached

Sound muted

3.2 Connectors

ERVICEONLY

1 2 3 4

• Connect to power

• USB connector for software update

• Connect to a USB storage device for audio play (for the

US version only)

• Connect to the HDMI ARC input on your TV

• Connect to the optical output on your TV or digital device

3.3 Remote Control

1 6

• Switch on or to standby

2. Source selectors

• Select the HDMI ARC source

• Select the Optical source

• Select the Bluetooth source

• Press and hold to connect another Bluetooth device

3. Sound effect buttons

/ MUSIC / MOVIE

• Select the pre-dened EQ (equalizer) settings for news/

music/ movie

• Select the voice mode to enhance vocal clarity

4. Playback buttons

I/I

• Bluetooth source: Skip to the previous or next track

• Bluetooth source: Start or pause playback

5. + / -

• Increase or decrease the volume

• Press and hold to increase or decrease the volume

continuously.

6. (Mute)

• Mute/unmute

www.jbl.com

English

4 PLACE

4.1 Desktop placement

Place the soundbar on a at and stable surface.

2.5-3.0 m / 8.2-9.8 ft

5 cm / 2”

NOTES:

−The power cord shall be properly connected to power.

−Do not place any objects on the top of the soundbar or subwoofer.

4.2 Wall-mounting

>2” (50mm) 1a)

1c)

≤8 mm/0.31" 4mm/ 0.16"

≥30 mm/1.18"

1b)

Figure 1

1. Preparation:

a) With a minimum distance of 2” (50mm) from your TV, stick

the supplied wall-mounting template to a wall by using

adhesive tapes.

b) Use your ballpen tip to mark the screw holder location.

Remove the template.

c) On the marked location, drill a 4 mm/0.16” hole. Refer to

Figure 1 for the screw size.

2. Install the wall-mounting bracket.

3. As shown in the diagram, remove the fastening screw by

using a screwdriver.

4. Fasten the wall-mounting screw included in the supplied

mounting kit.

5. Mount the soundbar.

NOTES:

−Make sure that the wall can support the weight of the soundbar.

−Install on a vertical wall only.

−Avoid a location under high temperature or humidity.

−Before wall-mounting, make sure that cables can be properly

connected between the soundbar and external devices.

−Before wall-mounting, make sure that the soundbar is unplugged from

power. Otherwise, it may cause an electric shock.

5 CONNECT

5.1 TV connection

Connect the soundbar with your TV through the supplied HDMI

cable or an optical cable (sold separately).

Through the supplied HDMI cable

An HDMI connection supports digital audio and video with a

single connection. HDMI connectivity is the best option for your

soundbar.

HDMI

(ARC)

HDMI ARC

1. Connect the soundbar with your TV by using the supplied

HDMI cable.

2. On your TV, check that HDMI-CEC and HDMI ARC have been

enabled. Refer to the owner’s manual of your TV for more

information.

NOTES:

−Full compatibility with all HDMI-CEC devices is not guaranteed.

−Contact your TV manufacturer if you have problems with the HDMI-

CEC compatibility of your TV.

Through an optical cable

OPTICAL

• Connect the soundbar with your TV by using an optical cable

(sold separately).

5.2 Bluetooth connection

Through Bluetooth, connect the soundbar with your Bluetooth

device, such as a smartphone, tablet and laptop.

Settings Bluetooth

Bluetooth

DEVICES

JBL CINEMA SB120

Now Discoverable

< 10 m / 33 ft

Connect a Bluetooth device

1. Press to switch on (See ”6.1 Power-on/Auto standby/Auto

wakeup” in the ”6 PLAY”chapter).

2. To select the Bluetooth source, press on the soundbar or

on the remote control.

→Ready for pairing: The status indicator ashes blue.

3. On your Bluetooth device, enable Bluetooth and search for “

” within three minutes.

→Connected: The status indicator lights up solid blue. A

conrmation tone is heard.

To reconnect the last paired device

Your Bluetooth device is retained as a paired device when the

soundbar goes to standby mode. Next time you switch to the

Bluetooth source, the soundbar reconnects the last paired device

automatically.

www.jbl.com

English

To connect to another Bluetooth device

1. In the Bluetooth source, press and hold on the soundbar or

on the remote control until the status indicator ashes blue.

→The soundbar enters the Bluetooth pairing mode. The

status indicator ashes blue.

2. Follow Step 3 under ”Connect a Bluetooth device”.

• If the device has ever been paired with the soundbar, rst

unpair “ ” on the device.

NOTES:

−The Bluetooth connection will be lost if the distance between the

soundbar and Bluetooth device exceeds 33 ft (10 m).

−Electronic devices may cause radio interference. Devices that generate

electromagnetic waves must be kept away from the soundbar, such

as microwaves and wireless LAN devices.

6 PLAY

6.1 Power-on/Auto standby/Auto wakeup

2 1

AC~

Switch on

1. Connect the soundbar to power by using the supplied power

cord.

2. Press to switch on.

NOTES:

−Use the supplied power cord only.

−Before switching on the soundbar, make sure that you have

completed all other connections (See ”5.1 TV connection” in the ”5

CONNECT”chapter).

Auto standby

If the soundbar is inactive for more than 10 minutes, it will switch

to standby mode automatically. Next time you switch on the

soundbar, it returns to the last selected source.

Auto wakeup

In standby mode, the soundbar will wake up automatically when

• the soundbar is connected to your TV through the HDMI

ARC connection and your TV is switched on;

• the soundbar is connected to your TV through an optical

cable and audio signals are detected from the optical cable.

1010

6.2 Play from the TV source

With the soundbar connected, you can enjoy TV audio from the

soundbar speakers.

1. Make sure that your TV is set to support external speakers

and the built-in TV speakers are disabled. Refer to the owner’s

manual of your TV for more information.

2. Make sure that the soundbar has been properly connected

to your TV (See ”5.1 TV connection” in the ”5 CONNECT”

chapter).

3. To select the TV source, press on the soundbar or

/ on the remote control.

→The status indicator turns solid white ( ), if your TV is

connected to the soundbar through the

connector.

→The status indicator turns solid amber ( ), if your TV

is connected to the soundbar through the

connector.

6.2.1 TV remote control setup

To use your TV remote control for both your TV and the soundbar,

check that your TV supports HDMI-CEC. If your TV does not

support HDMI-CEC, follow the steps under ”TV remote control

learning”.

HDMI-CEC

If your TV supports HDMI-CEC, enable the functions as instructed

in your TV user manual. You can control the volume +/-, sound

source, and power on/standby functions on your soundbar

through the TV remote control.

TV remote control learning

Through IR learning, your Infra-red TV remote control can learn

some commands of the soundbar.

1. Check that you have switched the soundbar to standby mode.

2. On the soundbar, press and hold and +until the status

indicator ashes amber.

→You enter the TV remote control learning mode.

3. Within seconds, do the following on the soundbar and your

TV remote control:

a) On the soundbar: press and hold one of the following

buttons: +, -, and , until the status indicator ashes

red three times.

b) On your TV remote control: double press the desired

button.

→When the status indicator ashes amber on the soundbar,

the function of the soundbar button is learnt by your TV

remote control button.

4. Repeat Step 3 to complete the button learning.

5. To exit the TV remote control learning mode, press and hold

and + on the soundbar until the status indicator ashes amber

three times.

6.3 Play from the Bluetooth source

Through Bluetooth, stream audio from your Bluetooth device to

the soundbar.

< 10 m / 33 ft

1. Check that the soundbar has been properly connected to

your Bluetooth device (See ”5.2 Bluetooth connection” in the

”5 CONNECT” chapter).

2. To select the Bluetooth source, press on the soundbar or

on the remote control.

3. Start audio play on your Bluetooth device.

4. Adjust the volume on the soundbar or your Bluetooth device.

Autres manuels pour CINEMA SB120

Table des matières

Autres manuels JBL Système de haut-parleurs

JBL

JBL CS680 (230V) Manuel utilisateur

JBL

JBL VT4886 Manuel utilisateur

JBL

JBL DSC 500 Manuel utilisateur

JBL

JBL SYNTHESIS S1S-EX Manuel utilisateur

JBL

JBL CONTROL X Manuel utilisateur

JBL

JBL MS28 Manuel utilisateur

JBL

JBL JRX118SP/230 Manuel utilisateur

JBL

JBL SYN 3 Manuel utilisateur

JBL

JBL Bar 5.1 Surround Manuel utilisateur

JBL

JBL Motion Picture Loudspeaker Systems Manuel utilisateur

JBL

JBL T88 Manuel utilisateur

JBL

JBL T696 LIMITED Manuel utilisateur

JBL

JBL LSR305 Manuel utilisateur

JBL

JBL Harman CINEMA SB160 Manuel utilisateur

JBL

JBL SCS180.6 Manuel utilisateur

JBL

JBL TLX271P Manuel utilisateur

JBL

JBL PRX500 Series Manuel utilisateur

JBL

JBL LS Series Manuel utilisateur

JBL

JBL VRX932LA Manuel utilisateur

JBL

JBL Harman BAR 700 Manuel utilisateur

JBL

JBL BAR 2.0 ALL-IN-ONE Manuel utilisateur

JBL

JBL JBL4660 Manuel utilisateur

JBL

JBL BAR 2.0 ALL-IN-ONE Manuel utilisateur

JBL

JBL S2600 Manuel utilisateur

Manuels Système de haut-parleurs populaires d'autres marques

JVC

JVC CA-MXK5R Manuel utilisateur

LG NB4532B Manuel utilisateur

JVC

JVC CA-FSH100 Manuel utilisateur

5Core

5Core Pro Series Manuel utilisateur

EAW

EAW MQV1394e Manuel utilisateur

Lynx

Lynx GXR-LA10A Manuel utilisateur

iLive

iLive ITB066B Manuel utilisateur

RDX

RDX QuickStation 4 Manuel utilisateur

Electro-Voice

Electro-Voice S-122 Manuel utilisateur

Sven

Sven SPS-619 GOLD Manuel utilisateur

Pioneer

Pioneer CS-7070 Manuel utilisateur

EAW

EAW UB82e Manuel utilisateur

Sondpex

Sondpex Active Speaker System and Digital Music... Manuel utilisateur

JVC

JVC NX-PN7 Manuel utilisateur

Marshall Amplification

Marshall Amplification AR-DM61-BT Manuel utilisateur

Yamaha

Yamaha NX-A01 - Speaker Sys Manuel utilisateur

SE Audiotechnik

SE Audiotechnik I-LINE Manuel utilisateur

Gemini

Gemini WRX-843 Series Manuel utilisateur
