Jasco Enbrighten Zigbee Instructions d'installation

43094 PRODUCT SPECIFICATIONS

Specications

Power: 120VAC, 60Hz Signal Frequency: 2.4Ghz

Maximum load for the Zigbee-controlled outlets:

600W (5A) incandescent/1/2HP motor or 1800W (15A) resistive

Zigbee controlled outlet is fused @ 5A. This fuse is not user

serviceable

Range: Up to 150ft. from controller or closest Zigbee device

Operating Temperature: 32-104° F (0-40° C)

Warranty: 5-year limited product warranty

For indoor use only

www.byjasco.com 1

Design Features

· Remote ON/OFF control

via the Zigbee controller

· Manual ON/OFF control

with the top push button

· Works with Google and Alexa

(requires compatible hub*)

· Can be included in multiple

groups and scenes

· Two Zigbee-controlled

AC outlets

· Both outlets controlled

together (cannot be

controlled independently)

· Space-efcient design

· Does not block the lower

outlet when plugged in to

the upper outlet of a duplex

wall receptacle – assumes

that the duplex receptacle is

mounted with the ground

pin down.

· Plugs and cords route

to the side allowing close

placement of furniture

· Over-the-air updates –

once joined to your Zigbee

network, the smart switch

can automatically receive

updates through your

Zigbee gateway

· Zigbee 3.0 certied for simple

pairing and integrated home

automation

· Visit ezzigbee.com/hubs for hub

compatibility

· Trilingual instruction manual –

English, French, Spanish

Zigbee Features

· Effortless device pairing to

Zigbee certied gateways

· Backward compatible with all

generations of Zigbee devices

· Supports wireless upgrades

to future-proof your home

* Requires Zigbee hub or controller –

functions may vary depending on brand.

Enbrighten Zigbee

Plug-in Dual-Outlet Smart Switch

43094 PRODUCT SPECIFICATIONS

www.byjasco.com 2

Two-Outlet Smart Switch

Wirelessly control both outlets simultaneously

Leaves 2nd outlet free for use

Grounded

wirelessly

controlled outlet

Grounded

wirelessly

controlled outlet

Manual ON/OFF & program button

Device Conguration

Adding your devices to a Zigbee network

Once the hub is ready to add the smart switch, pairing begins

automatically when power is supplied. The switch appears in the

controller’s menu when paired.

To remove and reset the device

Choose to remove the lighting device as instructed by your hub. The

controller indicates the smart switch was removed.

To return to factory defaults

If plugged in, unplug the switch. Press the program button while

plugging in the switch – must release button within four seconds of

plugging in the switch.

Compliances, specications and availability are

subject to change without notice

Distributed by Jasco Products Company LLC

10 E. Memorial Rd., Oklahoma City, OK

©Jasco 2020

V1 3/22/20

Certications & Compliances

Related Products – Enbrighten Zigbee Smart Controls

43100

Plug-in

Outdoor

Smart Switch

43076

In-Wall

Smart Switch,

Paddle

43084

In-Wall Smart

Switch, Toggle

43102

In-Wall

Smart Outlet

43080

In-Wall

Smart Dimmer,

Paddle

43090

In-Wall

Smart Dimmer,

Toggle

43096

Plug-In

Dual-Outlet

Smart Dimmer

43077

In-Wall

Smart Switch,

Paddle 120/277
