iWave WF28 Manuel utilisateur
Contents
Safety Instructions....................................................................................................1
Notes ............................................................................................................................2
1. Storage ................................................................................................................2
2. Use ......................................................................................................................2
Overview......................................................................................................................3
I. Structure ....................................................................................................................4
1.1 Appearance........................................................................................................4
1.2 Keys ..................................................................................................................5
1.3 Power ................................................................................................................7
1.3.1 Battery.....................................................................................................7
1.3.2 Power Adapter .....................................................................................8
II. Interface ..................................................................................................................9
2.1 Layout...............................................................................................................9
2.2 Page Details ......................................................................................................9
III. Operation.............................................................................................................11
3.1 Turn on............................................................................................................11
3.2 Color Difference Measurement....................................................................11
3.2.1 Type Sample Measurement.............................................................11
3.2.2 Sample Measurement ......................................................................12
3.3. Check out Information...................................................................................13
3.3.1 Type Sample Record ........................................................................13
3.3.2 Sample Record..................................................................................13
3.4. System Setting ...............................................................................................14
3.4.1 Auto Save ...........................................................................................15
3.4.2 Manual Save ......................................................................................15
3.4.3 SCI/SCE...............................................................................................16
3.4.4 Tolerance set......................................................................................16
3.4.5 Date and Time....................................................................................16
IV. Product Specification.......................................................................................17
WF28 User Manual
Shenzhen Wave Optoelectronics Technology Co., Ltd. 1
Safety Instructions
In order for safe and proper use of the instrument,
please read carefully and follow the instructions of the
manual.
Use only original power adapter and original battery to avoid
fault or damage of the instrument.
Upon long time no use, cut off external power and remove the
battery to avoid damage to the instrument resulting from battery
fluid overflow.
Do not use the instrument under the conditions with flammable
and explosive gases, dusts or smokes to avoid accident.
Do not use the instrument under the conditions of strong
magnetic field, rattling, dust and smoke to avoid unexpected data
and performance failure.
The product is a precision instrument, do not disassemble it
without permission, or it may be damaged and unrepairable.
WF28 User Manual
Shenzhen Wave Optoelectronics Technology Co., Ltd. 2
Notes
1. Storage
●Upon long time no use, put the instrument into a packing box;
●Store the instrument in a cool and dry environment with a
temperature at -10°C~50°C and relative humidity under 85%;
2. Use
●When using the instrument, the ambient temperature should be
0°C~40°C, relative humidity at 85%, without condensation;
●Do not use the instrument under the conditions of strong
magnetic field, rattling, dust and smoke to avoid unexpected data
and performance failure.
●Prevent foreign objects as liquid, powder or solid etc. from
entering into the instrument to avoid unexpected measurement
data.
WF28 User Manual
Shenzhen Wave Optoelectronics Technology Co., Ltd. 3
Overview
The Colorimeter is a professional colorimeter designed and
produced subject to the relevant standards of International
Commission on Illumination (CIE) and national stands. Being with
brand new imported key components, the instrument is well
designed and features in precision, stability, easy handling, easy to
learn and cost-effective.
The instrument applies to the color quality control, color
difference control, color difference analysis, sampling testing and
online testing for industries as textile, printing and dyeing, garments,
shoes, leather, chemical, plastic, pigment, paint, ink, printing, metal,
photography and toys etc., as well as to the auxiliary color
matching during the processes as injection, inking, painting and
spraying coating etc.
WF28 User Manual
Shenzhen Wave Optoelectronics Technology Co., Ltd. 4
I. Structure
1.1 Appearance
Figure 1. Instrument Appearance
7. Body
6.Show screen
4. Saving
1. Up
5. Confirm
2. Down
3. Paging
10. Switch
11. Printing interface
12. Battery cover
13. DC connector
8. Measurement
9. Measurement port
WF28 User Manual
Shenzhen Wave Optoelectronics Technology Co., Ltd. 5
1.2 Keys
Figure 2. Bird's View
Up - move the position of the cursor in the screen;
adjust the value of the activated items .
Down - move the position of the cursor in the screen;
adjust the value of the activated items.
Paging - Switching between tabs.
Saving - Save settings.
Confirm - Confirm or activate selected items in the
screen (a blue background of the item will be changed to a green
background after activation); fast switching between "standard
measurement" and "sample measurement".
Show screen - show measurement result etc.
1. Up
2. Down
6.Show screen
4. Saving
5. Confirm
3. Paging
WF28 User Manual
Shenzhen Wave Optoelectronics Technology Co., Ltd. 6
Figure 3. Back View
Measurement - Measuring
Measurement port - Optical channel for measuring.
Figure 4. Right View
Switch - In (I) or Out (O) of the instrument.
Printing interface - connect to the printer to print the measuring
data.
Battery cover - cover for the special lithium battery
compartment DC connector - dedicated power adapter connector.
8. Measurement
9. Measurement port
10. Switch
11. Printing interface
12. Battery cover
13. DC connector
WF28 User Manual
Shenzhen Wave Optoelectronics Technology Co., Ltd. 7
1.3 Power
The Colorimeter is powered by dedicated power adapter or
special lithium batteries, the use of other facilities for power supply
may damage the Colorimeter.
Ensure that the Switch is on Out (O) before connecting to the
power adapter or mounting the battery.
1.3.1 Battery
1. First check and confirm if the
Switch is on Out (O), then following
the arrow direction as shown on
Figure 5, take out the battery cover by
pressing down.
Figure 5. Remove the battery cover
2. Mount the battery into the
compartment as shown in Figure 6,
pay attention to the front and back of
the battery.
Figure 6. Mounting the battery
WF28 User Manual
Shenzhen Wave Optoelectronics Technology Co., Ltd. 8
3. Follow the directions on Figure 7,
press up to mount the battery into the
compartment.
Figure 7. Mounting the battery cover
1.3.2 Power Adapter
1. First check and confirm if the
Switch is on Out (O),
2. Plug the input cable of the power
adapter as shown on Figure 8 into the
DC connector.
Figure 8. Power Adapter connection
