PrograMill Base
Operating Instructions
Table of Contents
3
Table of Contents
1 About this Document 5
1.1 Target groups 5
1.2 Signs and symbols 6
1.3 Revision and validity 7
1.4 Supporting documents 7
2Safety 8
2.1 Intended use 8
2.2 Hazardous areas on the PrograMill Base 9
2.3 Safety instructions for individual operating phases 10
3 Design and Function 11
3.1 Complete system 11
3.2 Overview of PrograMill Base 13
3.3 Suggestion for the placement of items within the drawer 15
4 Transportation and Assembly 17
4.1 Choosing the location site 17
4.2 Transportation of the PrograMill Base 17
4.3 Unpacking the PrograMill Base 18
4.4 Checking delivery contents and condition 18
5 Initial Operation 19
5.1 Setting up the PrograMill Base 19
5.2 Placing the PrograMill milling machine onto the PrograMill Base 20
5.3 Setting up the PrograMill accessories 22
6 Cleaning 26
7 Technical Data 27
7.1 Measurements, weight 27
7.2 Ambient conditions 27
About this Document
5
1 About this Document
These Operating Instructions will familiarize you with the PrograMill Base features. The
PrograMill Base will be referred to as “base cabinet” from now on.
This product is a cabinet for accessories, tools and discs / blocks from the PrograMill milling
systems.
The Operating Instructions are an integral part of the product. They describe the safe and
correct use in all operating processes.
Improper use can be dangerous. Please observe the relevant safety instructions and read the
Operating Instructions carefully.
These Operating Instructions only apply together with the Operating Instructions from the
milling systems PrograMill PM3, PM5 and PM7 (“Supporting documents”, page 7). Read the
instructions carefully before using PrograMill Base, in particular the chapter regarding safety
instructions and warnings.
Should you lose these Operating Instructions, you can download them from
www.ivoclarvivadent.com.
For all types of technical questions, please contact your authorized service partner.
1.1 Target groups
Target group Duties
Operator •Keep these Operating Instructions
available at the place where the unit is
operated, also for future use.
•Request personnel read and observe
these instructions and the applicable
documents included. This applies in
particular for the safety instructions and
warnings (“Safety”, page 8).
•Observe additional product-related
stipulations and regulations.
Dental technician •Read and observe these Operating
Instructions and the applicable
documents, in particular safety
instructions and warnings (“Safety”,
page 8).
Qualified dental staff
CNC technician
Authorized Ivoclar Vivadent service partner
About this Document
6
1.2 Signs and symbols
1.2.1 Warnings
Warnings are used in these Operating Instructions to warn you of a risk of injury to persons
and/or damage to property.
1. Always read and observe these warnings.
2. Follow all measures marked with the warning symbol and warning word.
Depending on the severity and probability of the danger, the following warning levels are
distinguished:
Clarification of the structure of a warning:
WARNING! Name of source of danger, cause of hazard or type of risk.
Consequences of non-compliance with instructions.
Action in order to avoid danger.
Hazard example:
WARNING! Risk of injury from the PrograMill Base tipping over or falling down.
Crushing extremities.
Damage to the PrograMill Base.
Only use suitable means of transportation (e.g. fork lift trucks, capacity > 500 kg).
Secure the PrograMill Base with suitable transport straps to prevent falling (e.g. tension
belts).
Avoid impact, jerky movements and vibration during transportation.
Stay well clear of suspended loads or raised parts.
Warning
symbol Warning word Danger level
Consequences resulting
from non-observance
DANGER Immediate imminent
danger
Death, severe personal
injury
WARNING Potential danger Death, severe personal
injury
CAUTION Potential danger Slight personal injury
- NOTICE Potential danger Damage to property
About this Document
7
1.2.2 Signs and symbols
1.3 Revision and validity
1.4 Supporting documents
You can obtain information about the applicable documents from your local sales partner or
in the download area of Ivoclar Vivadent at: http://www.ivoclarvivadent.com.
Symbol Significance
Additional information, e.g. for better understanding, for simplifying
workflows or for further information
Prerequisite which must be followed before the subsequent actions can be
performed
Individual steps which you must perform
1., 2. Several steps that you must perform in the given order
The result indication of an operation step or several steps, for success control
Version Date
Amendments to the
previous version
1.0 30-11-2017 Initial creation date
Document Clarification
Checklist for your PrograMill system Information about requirements that must be
observed for transport, installation and use of
the PrograMill system
Operating Instructions PrograMill PM3 Instructions on operating the milling machine
PrograMill PM3 and the PrograMill Tank
Operating Instructions PrograMill PM5 Instructions on operating the milling machine
PrograMill PM5 and the PrograMill Tank
Operating Instructions PrograMill PM7 Instructions on operating the milling machine
PrograMill PM7 and the PrograMill Tank
Operating Instructions PrograMill
Suction Unit
Important information about the use of the
PrograMill Suction Unit (optional)
Safety Data Sheet PrograMill Fluid Important information about the use of the
PrograMill Fluid coolant concentrate
Safety
8
2Safety
These Operating Instructions only apply together with the Operating Instructions from the
milling systems PrograMill PM3, PM5 and PM7 (“Supporting documents”, page 7). Read the
instructions carefully before using PrograMill Base, in particular the chapter regarding safety
instructions and warnings.
WARNING! Improper use of the product.
Danger to the user.
The safety chapter contains important information on the safety of the product: Please
read thoroughly prior to use.
The product is built according to state-of-the-art technology and recognized safety
regulations. Nevertheless, its use could constitute a risk of injury of the user or third party or
possibly cause impairment to the product and other property.
2.1 Intended use
PrograMill Base is designed for use in the dental technical field as a place to stand the
PrograMill PM3, PM5 or PM7 milling systems and store accessories, cleaning materials, tools
and discs / blocks. Use the PrograMill Base exclusively for this purpose.
In the case of damage caused by improper use or failure to observe the Operating Instructions,
all liability and warranty claims are void.
2.1.1 Potential improper use
Equipment, accessories and components whose weight exceeds the load-bearing capacity of
PrograMill Base and built-in pull-out shelf must not be placed on or in PrograMill Base.
The following is considered as misuse of the system:
•Non-compliance with the intended use, intended operator specifications or intended
environment
•Modifications, maintenance and repairs without the permission of Ivoclar Vivadent
•Operation with unsuitable parameters
Improper use of the PrograMill Base can lead to the following:
•Danger for operating personnel
•Impairment of the operability of the PrograMill Base
Ivoclar Vivadent assumes no liability for damage resulting from improper use.
Safety
9
2.2 Hazardous areas on the PrograMill Base
No. Hazardous areas Safety measures Protective effect
1 Pull-out shelf Lock on the handles Secures against unintentional
movement when doors are opened
or work is carried out on the
PrograMill milling machine or
PrograMill Base.
11
Safety
10
2.3 Safety instructions for individual operating phases
2.3.1 Transportation
Only transport the PrograMill Base according to the description in these Operating
Instructions (“Transportation and Assembly”, page 17).
2.3.2 Use
Keep unauthorized persons, such as patients, children and animals, away from the
product.
Do not use a damaged, non-functioning product or accessories, instead notify the
authorized service partner.
To ensure the stability of the PrograMill system, only operate the CNC milling machine
with a crossbeam mounted on the PrograMill Base.
2.3.3 Improper maintenance, modifications and repairs
Improper service and improper repairs or modifications will endanger users and result in
damage to the product.
Should you carry out any maintenance to the system or modifications to the product without
prior written consent by an authorized service partner, all warranty claims are void.
Maintenance and repair of damaged safety equipment or other parts of the PrograMill
Base should only be performed by an authorized Ivoclar Vivadent service partner.
