Italkero ECO SC Manuel utilisateur
USER
0476
CR1228
Wall gas stoves
- NATURAL -
Eco
SC - SV - SE
SC SV, SE
2
user
Contents
Basic safety rules Page 5
General information “ 6
Getting to know your convection heater “ 8
Using the convection heater
- commissioning “ 10
- setting the clock and timer “ 14
- setting the room thermostat “ 15
Prolonged disuse “ 16
Cleaning “ 17
Maintenance “ 17
Troubleshooting “ 18
3
user
Dear client,
Thank you for choosing our convection heater,
a modern, high quality,
high performance product which will provide you outstanding comfort,
silent operation and safety over its long service life.
To get best results from your appliance,
please have it regularly serviced and repaired with the manufacturer's
original spare parts by an Authorised Technical Service Centre.
You can also stipulate a Scheduled Service Contract,
which will cost you less in case of need.
This instruction booklet is intended to provide
you with important information;
please follow these instructions
when using your convection heater.
Thank you again for choosing ITALKERO.
4
user
Your convection heater
is covered by a
WARRANTY
which runs from the date of certification by your local
Technical Service Centre,
available on our website
or by phoning the manufacturer directly.
Please contact the Technical Service Centre,
which will provide the following
FREE SERVICES
• commission your convection heater.
• ratify the WARRANTY
furnished with the appliance;
we suggest you read the certificate carefully.
The Technical Service Centre will give
you good advice on how to get the most from your convection heater
Our CONVECTION HEATERS
are conforming with:
• Gas Directive 90/396/EEC
• Electromagnetic Compatibility Directive 89/336/EEC
• Low Voltage Directive 73/23/EEC
Π0476
The following symbols are used in the manual:
CAUTION = indicates actions which demand special care and preparation
PROHIBITED = indicates actions which MUST NOT be done.
5
user
BASIC SAFETY RULES
When using a product with combustion
or electrical energy, always follow basic
safety precautions to reduce the risk of
injury. Read this manual carefully to
learn its use and limitations as well as
potential hazards associated with its use.
Do not allow children or
unsupervised disabled persons
access to the convection heater.
Do not use this product in the
presence of an explosive gaseous
fume.
Should you do so:
• ventilate the room by opening the doors
and windows;
• close the fuel/gas supply cock;
• contact Technical Service or a qualied
technician immediately.
Do not touch the convection heater when
barefoot, or when wet.
Do not touch the grille when hot air is
coming out of it.
Always unplug the appliance before
cleaning any part of it.
Do not pull, take apart, or twist the
electrical cables running from the
convection heater, even if when they are
disconnected from the mains.
Do not place towels, dishcloths, doilies or
any other such objects on the convection
heater; they can cause malfunctions or
even serious danger.
6
user
This booklet is an integral part of
the appliance and must be kept
carefully and ALWAYS accompany the
convection heater when it is handed on
to another user or installed in another
system.
If it is damaged or lost, please request
a new copy from your local Technical
Service.
The convection heater must be used
for the purpose specified by the
manufacturer.
The manufacturer is not liable in
anyway for damage or injury to persons
or animals resulting from incorrect
installation, adjustments or improper use
of the appliance.
The convection heater must be
installed by a technician qualied
pursuant to Italian Law 5 March 1990
n° 46, who will issue a declaration
of conformity with the installation
regulations and instructions provided by
the manufacturer in the included booklet.
If the convection heater is not
used for a long time, the following
procedure must be completed:
• set the appliance's master switch to
OFF;
• set the master switch of the installation
(if present) to OFF or pull its power plug;
• close the gas supply cock.
GENERAL WARNINGS
7
user
GAS CONVECTION HEATER, TYPE C, SEALED CHAMBER, FOR
HEATING.
ECO SC
ECO SV
ECO SE
8
user
It is a standalone gas appliance, with atmospheric
burner, high performance, suited for room heating.
It has a Type C combustion circuit with
sealed combustion chamber, totally isolated
from the room in which it is installed, for
unbeatable occupant safety.
It also uses (in certain models) a very quiet
tangential fan, which quickly heats the room
to the required temperature.
SC convection heaters do not have a fan, SV
heaters have a fan which is actuated by a
switch (regardless of the power setting), and
SE heaters have a fan which is controlled
automatically by the power setting (MIN
power - fan stopped, MAX power - fan
running). All appliances have an accident-
proof door to protect the control panel and
tray for humidifying the room.
GETTING TO KNOW YOUR
CONVECTION HEATER
1
9
user
ECO SC / SV
ECO SE
1) Ignition/command knob.
2) Timer (24 h).
3) Pressure regulator screw.
4) Timer function selector:
-- clock: timer mode (programmable).
-- hand: room thermostat controlled
operation.
-- zero: appliance shut down, only the clock
still runs.
5) Room thermostat knob.
6) Tangential fan On/Off.
1) Room thermostat knob.
2) Timer (24 h).
3) Timer function selector:
-- clock: timer mode (programmable).
-- hand: room thermostat controlled
operation.
-- zero: appliance shut down, only the clock
still runs.
4) MIN/MAX power button
5) On/Off/Reset button.
6) Operational status led.
7) Fan on led (the fan only runs
automatically when the appliance is set to
MAX power).
10
user
COMMISSIONING
The heater must be commissioned by
technical service, after which the user can
operate it as he wishes: manual or automatic,
thermal power from MIN to MAX, with the
fan on or off.
The user may need to restart the heater
himself, without contacting Technical
Service, for instance after being away for a
period of time or after prolonged disuse.
In such cases, proceed as follows:
• Check that the gas cock is open;
• Set the master switch, if present, to ON, or
t the power socket into the appliance's plug
(fan/timer models);
• Check that the mains power plug (fan/timer
models only) is fitted into the wall socket in
the right orientation (phase-neutral);
• Set the room thermostat to MAX to
minimise the time the heater takes to heat
up;
WARNING! Do not touch the fins hot air
outlet to avoid serious burns.
