Iseo Libra SMART Demo Kit Manuel utilisateur
Libra SMART Demo Kit
User Manual - Manuale Utente
EN - IT 04
2
ENGLISH
• Introduction ....................................... 4
• Quick Start ........................................ 5
• Battery replacement ........................... 11
• Mechanical knob installation............... 12
ITALIANO
• Introduzione....................................... 16
• Per iniziare ........................................ 17
• Sostituzione batteria .......................... 23
• Installazione pomolo meccanico .......... 24
4
Introduction
The Libra Smart Demo Kit allows to demonstrate the Argo app functionalities with the Libra
electronic cylinder. The kit includes:
• Libra electronic cylinder with RFID reader and Premium mechanical knob.
• Covers in 4 different nishes.
• Standard mechanical knobs in 2 different nishes.
• ARGO System Cards Set (1 Master Card demo and 4 User Cards).
• Assembly/disassembly tooling kit for electronic knob cover.
• Allen key for mechanical knob assembling.
• Demo Kit User Manual.
To know more about Argo download the Argo User Manual at web site:
https://app.iseo.com.
5
Quick Start
1. On your smartphone download the ISEO Argo app from the Apple Store (iOS) or the Play
Store (Android).
2. Open the ISEO Argo app: you will see in the smartphone display, the Libra Smart, within a
radius of 10meters, identied by its serial number.
Info App menu
Libra Smart available within a radius of 10mt.
6
A not initialized Libra can be opened by any RFID card or tag. When opening the
orange light ashes 2 times, before the standard opening signal, to show the device
not initialized.
3. Touch Info App to nd the Argo User Manual or to change the Argo app language. Argo app
language is set by default like the phone’s language. Then go back to the Home menu by
pressing in the upper left corner.
4. Bring the Master Card demo close to the Libra to assign the System Code: the Libra emits
3 acoustic signals together with 3 green light signals to conrm device initialization.
Touch to open the Argo User Manual
(link to app.iseo.com).
Touch to change the app’s language.
7
6. As soon as you enter Programming Mode the app automatically requests to add the
smartphone as credential to open the Libra. Insert phone name then touch Done in the
upper right corner.
Type the phone name.
Enable Login to enter Programming mode the
next time by phone (without Master Card).
5. Present again the Master Card to the Libra: the button in the app will turn red, and pressing
it you will enter in Programming mode.
8
8. Touch Door Info and then Door name to give a name to the Libra.
Touch to change the name.
7. The phone is now stored in the Libra’s User List.
Enrolled Phone
9
9. Go back to the home screen, then touch “Libra Smart” to test the opening.
Touch the button with the Libra name and icon to
test the opening.
Write the new name then touch Done.
10
11. Touch Events to show the Libra history log.
Libra opening previously performed.
10. Enter Programming mode by phone (without Master Card).
Tap and hold “Libra Smart” to show Login
functionality.
Then touch Login.
