isel-CNC Compact Equipment CPM
ca. 1200 mm
ca. 1200 mm*
ca. 1100 mm**
710 mm
610 mm*
515 mm**
ca. 1270 mm
ca. 1200 mm*
ca. 1200 mm**
CPM 4030
CPM 3020*
CPM 2018**
3 Set up and connecting
The machine is provided completely mounted on a palette.
Contained in scope of delivery of the CPM are:
• machine case with three linear axes included
- complete controller electronics
- drilling and milling machine with 3 mm split chuck - as a standard
• key for split chuck, spanner SW 17
• clamping set (hand lever, stop bars, 5 mm socket spanner)
• triangular wrench for unlocking the hood switch
• AC power cable, PC - machine data cable
• 4-fold socket outlet with illuminated mains switch
• software according equipment package
• and these service and maintenance instructions
• the parts of the scope of delivery can be variant by special systems
The space requirement of the machine is limited to the external measurements and to
sufficient room in front of the machine in order to operate and arrange the processing, plus
approx. 10 cm behind the machine to allow for connectors. The hood of the housing opens
upwards. Thus, the required total height is approx. 1,2 meters.
Dimensions and space requirement
Remove the sheet steels of the feet of the machine with which it is secured on the palette.
Then, set up the machine horizontally onto a flat, fixed face.
You can compensate for small unevenness of the base area at the feet.
During transportation, please pay attention to the supply and connection cables (remove if
needed) so that they are not damaged. Use only suitable lifting devices.
