ISAFE MOBILE M53A01 Manuel utilisateur

I S 5 3 0 .1

OPERATING MANUAL

MODEL M53A01

Document No. 1029MM10REV00

Version: 2021-12-06

i.safe MOBILE GmbH

i_Park Tauberfranken 10

97922 Lauda-Koenigshofen

Germany

Tel. +49 9343 60148-0

[email protected]

www.isafe-mobile.com Template: TEMPMM01REV10

CONTENTS

English.............................................................................. 4

Deutsch............................................................................ 18

Česky .............................................................................. 32

Dansk.............................................................................. 46

Español ............................................................................60

Suomi.............................................................................. 74

Français............................................................................88

Magyar ...........................................................................102

Italiano ...........................................................................116

Nederlands .......................................................................130

Norsk .............................................................................144

Polski .............................................................................158

Português (BR) ....................................................................172

Svenska...........................................................................186

Hrvatski.......................................................................... 200

Slovenská.........................................................................214

Српски ...........................................................................228

Korean ...........................................................................242

Japanese ........................................................................256

Chinese...........................................................................270

Arabic ........................................................................... 284

This Operating Manual complies with these standards:

IEC 60079, IEC 82079, ANSI Z535.6

Diese Bedienungsanleitung erfüllt die Anforderungen der folgenden Normen:

IEC 60079, IEC 82079, ANSI Z535.6

ENGLISH

READ AND UNDERSTAND THE INSTRUCTIONS

PROTECT YOUR LIFE AND READ THE OPERATING MANUAL

This Operating Manual is part of the device IS530.1 (model M53A01). This Operating Manual

provides important information for safe use of the device.

Before using the device, read this Operating Manual carefully and pay particular attention

to the “Safety” section and the warnings highlighted with the warning symbol.

Also read the Safety Instructions before using the device.

You can nd these at www.isafe-mobile.com/en/support/downloads.

Make sure you have access to this Operating Manual when you need it. You can nd the

current Operating Manual at www.isafe-mobile.com/en/support/downloads.

Follow all instructions given on the device and on the packaging.

Follow local safety regulations.

INTENDED USE

The IS530.1 is an Internet-capable communication device for industrial use in explosion

hazardous areas of Zone 1/21 and 2/22, in accordance with Directives 2014/34/EU,

1999/92/EC and the IECEx system, among others.

Only use the device as described in this Operating Manual. Any other use is considered impro-

per and can lead to death, severe injuries and damage to the device.

The manufacturer i.safe MOBILE GmbH does not assume any liability for damage caused by

improper use. The warranty expires in the event of improper use.

EN 5

WARRANTY

You can nd the warranty conditions at www.isafe-mobile.com/en/support/service.

For any damage caused by computer viruses that you download while using the Internet

functions responsibility is at your hand.

There is no right of recourse against i.safe MOBILE GmbH.

EU DECLARATION OF CONFORMITY

You will nd the EU declaration of conformity at

www.isafe-mobile.com/en/support/downloads.

FCC/IC STATEMENT

The FCC/IC declaration can be found at www.isafe-mobile.com/en/support/downloads.

EX MARKINGS

ATEX:

II 2G Ex ib IIC T4 Gb

II 2D Ex ib IIIC T135°C Db IP6X

EU Type Examination Certicate:

EPS 19 ATEX 1 037 X

CE-designation: 2004

IECEx:

Ex ib IIC T4 Gb

Ex ib IIIC T135°C Db IP6X

IECEx Certicate: IECEx EPS 19.0014X

SANS:

Ex ib IIC T4 Gb

Ex ib IIIC T135°C Db IP6X

North America:

Class I Div 1 Groups A, B, C, D, T4

Class II Div 1 Groups E, F, G , T135˚C

Class III Div 1

CSA19CA70220251

Temperature range:

-20°C … +60°C (EN/IEC 60079-0)

-10°C … +50°C (EN/IEC 62368-1)

Manufactured by:

i.safe MOBILE GmbH

i_Park Tauberfranken 10

97922 Lauda-Koenigshofen

Germany

DEVICE OVERVIEW/FUNCTIONS

12 1011

17 18 19

EN 7

1 STATUS LED: Display for notications and charging status.

2 SOS KEY: A long press of the SOS key sends an emergency call to a pre-saved emer-

gency number (only in connection with a Lone Worker Protection app).

3 LOUDSPEAKER

4 POWER KEY: A long press switches the device on/o. A short press switches the stand-

by mode on/o.

5 FRONT CAMERA

ISM INTERFACE: Connection for approved accessories. Also see section “Connecting

approved accessories”.

7 MAGNETIC CHARGER PORT: Connection for the i.safe PROTECTOR3.0 Magnetic

Charger Cable.

Also see section

“Charging”.

8 SIDE KEY RIGHT: Optional function, e.g. camera - function can be assigned via Button

App (system integrated).

9 CURRENT APPLICATION: Shows all open applications.

10 HOME KEY: Switch to the main screen.

11 BACK KEY: Go to the previous screen.

12 USB INTERFACE:

Connection for the i.safe PROTECTOR2.0 TypeC USB Cable or for

connection to other devices. Also see sections “Charging” and “Connecting approved

accessories”.

13 MICROPHONE

14 LOUDNESS CONTROL: Volume up/Volume down.

15 SIDE KEY LEFT: Optional function - function can be assigned via Button App (system

integrated).

16 SENSORS: Proximity sensor, light sensor.

17 LED FLASH

18 NOISE CANCELLING: Noise cancelling microphone.

19 LOUDSPEAKER: Loudspeaker for hands-free function.

20 BACK CAMERA

21 BATTERY

SAFETY

Read the “Safety” section of this Operating Manual carefully before using the device. If you

do not follow these instructions or do not understand them, this could lead to death, severe

injuries and damage to the device.

USER

Only trained users who are qualied in the use of Ex devices in explosion hazardous areas and

who have read and understood this Operating Manual may use this device.

USE IN EXPLOSION HAZARDOUS AREAS

DANGER

Improper use can result in death or severe injuries!

Only use the device in explosion hazardous areas of zones1/21 and2/22 or outside of

explosion hazardous areas.

Before entering an explosion hazardous area with the device,

•make sure that only approved accessories are connected to the device, see section

“Connecting approved accessories”,

•make sure that no gap can be seen between the two halves of the device,

•make sure the device is not damaged,

•make sure that all the labels on the device are readable,

•make sure the battery is screwed tight.

If you use the device in an explosion hazardous area,

read and follow the instructions in the “Possible User Errors” section.

Switch o the device immediately and leave the explosion hazardous area without delay if

•malfunctions occur on the device,

•you have damaged the housing of the device,

•you have exposed the device to excessive loads,

•the labels on the device are no longer readable.

USE OUTSIDE OF EXPLOSION HAZARDOUS AREAS

DANGER

Improper use can result in death or severe injuries!

Do not use the device in places where its use is prohibited.

Turn o the device in clinics or other medical facilities.

Always keep a safety distance of at least 15cm between the device and a pacemaker or

hearing aid. The device can aect the functioning of medical devices such as pacemakers and

hearing aids.

When using the device while driving a motor vehicle, be sure to comply with applicable

national laws.

Make sure you prevent the user errors described in the section entitled “Possible User Errors”.

Only charge the device as described in the “Charging” section.

EN 9

CAUTION

When using earphones or headsets at the maximum volume setting, you can

damage your hearing.

First set the volume control on the device to 50% of the maximum volume.

Gradually adjust the volume.

NOTICE

Incorrect use can damage the device.

Only use accessories approved by i.safe MOBILE, as described in the section on

“Connecting approved accessories”.

Protect the device and the Power Adapter from strong electrical magnetic elds as for examp-

le those emitted by induction cookers or microwave ovens, for example.

Do not touch the display with sharp objects.

POSSIBLE USER ERRORS

DANGER

Improper use can result in death or severe injuries! Follow the instructions below:

Do not modify the device structurally.

Do not expose the device to high temperatures.

Do not expose the device to strong UV radiation.

Do not expose the device to processes with high electrical charges.

Do not expose the device to aggressive acids or bases.

When working in explosion hazardous areas, please note:

Do not loosen the screws on the device.

Do not connect any accessories to the device.

Do not open any interface cover.

Do not charge the device.

Do not open the device.

Do not damage the device.

SCOPE OF DELIVERY

Your device packaging contains the following:

1 x IS530.1

1 x Battery

1 x Quick Start Manual

1 x Safety Instructions

1 x Display Protection Foil

1 x i.safe PROTECTOR2.0 TypeC USB Cable

1 x i.safe PROTECTOR3.0 Magnetic Charger Cable

1 x Power Adapter universal (power supply unit and various country-specic adapters)

1 x Torx Screwdriver

1 x Display cleaning cloth

CELL BROADCAST

The device supports cell broadcast. Cell broadcast is a cellular service for sending messages to

all recipients within a cell.

INSTALLING THE BATTERY

DANGER

Installing the wrong battery in the device, poses a risk of explosion, which could result in

death or serious injuries! Only t the battery supplied or an approved replacement battery in

the device outside of explosion hazardous areas. The approved replacement battery can be

found on the website www.isafe-mobile.com/en/products.

Place the battery in the battery compartment as shown.

Hand-tighten the screws using the Torx Screwdriver provided.

Check that the battery is seated correctly and securely.

Autres manuels pour M53A01

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels ISAFE MOBILE Téléphone portable

ISAFE MOBILE

ISAFE MOBILE IS910.1 Manuel d'instructions

ISAFE MOBILE

ISAFE MOBILE IS540.M1 Manuel d'instructions

ISAFE MOBILE

ISAFE MOBILE IS530.2 Manuel d'instructions

ISAFE MOBILE

ISAFE MOBILE M53A01 Manuel d'instructions

ISAFE MOBILE

ISAFE MOBILE IS330.RG Manuel d'instructions

ISAFE MOBILE

ISAFE MOBILE IS330.1 Manuel d'instructions

ISAFE MOBILE

ISAFE MOBILE IS655.2 Manuel d'instructions

ISAFE MOBILE

ISAFE MOBILE M120A01 Manuel utilisateur

ISAFE MOBILE

ISAFE MOBILE IS330.1 Manuel d'instructions

ISAFE MOBILE

ISAFE MOBILE IS330.2 Manuel d'instructions

ISAFE MOBILE

ISAFE MOBILE IS730.2 Manuel de l'opérateur

ISAFE MOBILE

ISAFE MOBILE CHALLENGER 2.0 Manuel d'instructions

ISAFE MOBILE

ISAFE MOBILE IS725.2 Manuel d'instructions

ISAFE MOBILE

ISAFE MOBILE ADVANTAGE 1.X Manuel de l'opérateur

ISAFE MOBILE

ISAFE MOBILE IS655.2 Manuel utilisateur

ISAFE MOBILE

ISAFE MOBILE IS740.2 Manuel d'instructions

ISAFE MOBILE

ISAFE MOBILE IS170.2 i Manuel de l'opérateur

ISAFE MOBILE

ISAFE MOBILE IS330.RG Manuel utilisateur

ISAFE MOBILE

ISAFE MOBILE M360A01 Manuel utilisateur

ISAFE MOBILE

ISAFE MOBILE IS930.2 Manuel d'instructions

ISAFE MOBILE

ISAFE MOBILE IS530.M1 Mining Plus GD Manuel utilisateur

ISAFE MOBILE

ISAFE MOBILE IS310.2 Manuel de l'opérateur

ISAFE MOBILE

ISAFE MOBILE innovation 2.0 Manuel de l'opérateur

ISAFE MOBILE

ISAFE MOBILE Challenger 1.0 Manuel d'instructions

Manuels Téléphone portable populaires d'autres marques

Zte

Zte BLADE A520 Manuel utilisateur

Nokia

Nokia Lumia 620 Manuel utilisateur

Blackbe;rry

Blackbe;rry KEYone Manuel utilisateur

Bea-fon

Bea-fon X5 Premium Manuel utilisateur

Blackbe;rry

Blackbe;rry 8707 Series Manuel utilisateur

Blackbe;rry

Blackbe;rry Storm Mode d'emploi

LG LM-X420QN Manuel utilisateur

LifeWatch

LifeWatch V Manuel utilisateur

Bea-fon

Bea-fon SILVER LINE SL860 Manuel utilisateur

IKI Mobile

IKI Mobile KF4.5i Manuel utilisateur

Hitech

Hitech HT-850 Manuel utilisateur

Yezz

Yezz Fashion F10 Manuel utilisateur

Point Mobile

Point Mobile PM60 Manuel utilisateur

Blackbe;rry

Blackbe;rry Q10 Manuel utilisateur

Blackbe;rry

Blackbe;rry Bold 9900 Manuel utilisateur

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Manuel utilisateur

LG LM-K420EMW Manuel utilisateur

LG Thrive Manuel utilisateur
