IRobot Roomba 4100 Manuel utilisateur

roomba_knowledge_4100.qxp 7/6/2004 8:43 PM Page 1

Roomba Anatomy

Cliff Sensor Openings

Edge-Cleaning

Side Brush

Main Cleaning Brushes Vacuum Inlet

Brush Guard

Release Buttons

Contact Points for

Drive-on-Charger/ Charging

Wall Mount

Bin Release Button

Main Power Button

Battery Charger Socket

Battery Indicator

roomba_knowledge_4100.qxp 7/6/2004 8:43 PM Page 3

Roomba Set-up

Charge for 7 hours —while

you’re waiting, load batteries

into your Virtual Wall.

1Place battery into Roomba Robotic

Floorvac.

(press down on both ends)

Clean the floor of loose

stuff like you would before

using a traditonal vacuum.

If you don’t vacuum over it,

don’t use Roomba over it

(e.g., rug tassels, power

and blind cords).

Set up your Virtual Wall

to keep Roomba where

you want it and away

from where you don’t.

roomba_knowledge_4100.qxp 7/6/2004 8:44 PM Page 4

Roomba Set-up

clean!

Battery

indicator

Power

roomba_knowledge_4100.qxp 7/6/2004 8:44 PM Page 5

Works

great on spills or in

high traffic areas.

Roomba at Work

1Place Roomba in the center of the room and press

“Clean.” Roomba will automatically calculate how long it

needs to clean your entire room.

4To pause Roomba, hit any button on the panel. To stop, pick it up.

3“Dirt Alert” will illuminate when Roomba has detected dirt

that requires special attention. When the dirt is gone,

Roomba will continue in its standard cleaning

mode.

Use “Spot” to intensively clean a 3 ft. diameter area.

In dirtier

areas, I increase my

cleaning intensity.

roomba_knowledge_4100.qxp 7/6/2004 8:45 PM Page 6

When Roomba stops, check the indicator light.

6When Roomba is not cleaning it is recommended that you keep it plugged in. That

will help the battery stay in peak condition.

Roomba at Work

Roomba stops for 3 reasons

Mission Complete Mission Abandoned Battery Depleted

If my mission is

abandoned, pick me up

and examine my brushes.

Remove any obstructions

before restarting.

Green Yellow Yellow

Red

roomba_knowledge_4100.qxp 7/6/2004 8:45 PM Page 7

Keep Roomba Running

Keep

Dispose

Inspect the vacuum inlet

and clean debris as

needed.

12Remove and clean the brushes

every 10 uses.

Inspect and wipe the sensors clean.

(when you clean brushes) Cotton swabs

work great!

Empty the bin over a trash barrel after each

use. Don’t forget to remove the filter

assembly and empty the 2nd chamber.

I recommend

you do this every 2

months.

Change filters.

roomba_knowledge_4100.qxp 7/6/2004 8:46 PM Page 8

Roomba Last Thoughts

The Roomba Robotic Floorvac is easy to use,

but under the hood it’s a complex robot. We’re

Roboticists, the retailer is not. If you have

questions or comments, we’re anxious to help.

Please visit us at

www.irobot.com

call 877-855-8593

iRobot, Roomba, Roomba Red, Virtual Wall and “if it’s down there, we’ll get it” are trademarks of iRobot Corporation.

US Pat Nos 6,594,844 and 6,690,134. Additional Patents Pending

Burlington, MA 01803 Version: 4100-V1

roomba_knowledge_4100.qxp 7/6/2004 8:46 PM Page 9

Model 4100
