Quick Start Guide

1Power On

• Locate the key switch, insert key

and turn clockwise from o to on

• Adjust slit lamp illumination

intensity, width and height

2Slit Lamp Illumination

3Slit Lamp Controls

Micromanipulator

• Adjusts the aiming beam for both

single spot and patterns

Power Knob

• Allows surgeon to easily adjust

laser power without sitting back

from binoculars

• Locate the single functional

LIO port

• Slide LIO Port cover down to

expose LIO port

Connect LIO

Iridex PASCAL (532/577)

• Raise PASCAL table up or down

with arrow button on left side

of the table

Table Adjustment

Height Adjustment Controls

Micromanipulator

• Press the red button on

the front of the laser console to

quickly cease laser function

Emergency Shut-o

Power Knob

Iridex Corporation

1212 Terra Bella Avenue

Mountain View, California 94043-1824 USA

Telephone: (650) 940-4700

(800) 388-4747 (US only)

Fax: (650) 962-0486

Technical Support: (650) 962-8100

[email protected]

The symbols glossary is provided in the Symbols section of the Operator Manual of the

Laser console.

This Quick Start guide is a summary document for user convenience, but this quick start

guide does not replace the operator manual provided with the Laser System. Do not use

or operate the Laser System until you have read and understood the operator manual.

88332-EN Rev A 07.2022

C US

RX ONLY
