iQ Power Tools
Repair Manual
iQMS362
888-274-7744 iQMS362
www.iqpowertools.com Repair Manual
Table of Contents
IQMS362 DISASSEMBLY 3
Blade Removal 3
Blade Guard Removal 5
Arbor Assembly Removal 9
Control Module Disassembly 11
Saw Motor Disassembly and Removal 15
Saw Motor Stator Disassembly and Removal (Original Stator) 17
Saw Motor Stator Disassembly and Removal (Updated Stator) 19
Saw Mount Disassembly and Removal 23
Support Arm Disassembly and Removal 29
Support Arm Removal and Disassembly 31
Vacuum Motor Removal 33
Vacuum Brushes Removal (Original Version) 35
Vacuum Brushes Removal (Updated Version) 39
Vacuum Suction Inlet Removal 41
Filter Removal 43
Table Shock Removal 45
IQ362 ASSEMBLY 49
Table Shock Installation 49
Vacuum filter Installation 53
Vacuum suction Installation 55
Vacuum Motor brushes Installation/Replacement (Early Version) 57
Vacuum Brushes Installation (New Version) 61
Support Arm Assembly and Installation 63
Pivot Arm Assembly and Installation 67
Saw Motor Armature Installation 75
Saw Motor Stator Assembly (Original Version) 77
SAW STATOR ASSEMBLY AND INSTALLATION 81
Control Module Installation and Assembly 85
Arbor Assembly Installation 89
Guard Guide Rail Assembly and Installation 93
Blade Installation 99
IQMS362 ADJUSTMENTS 101
Sliding Table Upper and Lower Roller Check and Adjustments 101
Sliding Table Travel Check and Adjustments 109
Pivot Arm Squareness Check and Adjustments 115
Table Louver and Vacuum Suction Clearance Check and Adjustment 121
Vacuum and Seal Check 123
WIRING DIAGRAM 125
