Operators Manual
2
Warnings
Throughout this manual these symbols and notes are used to indicate the following:
Danger
Imminent Danger that is likely to cause serious injury or loss of life
Warning
Safety situations that may cause serious injury or loss of life
Caution
Safety situations that may cause problems or damage to the equipment.
Note
To draw attention to procedures which are essential to observe
for correct operation
Electrical Hazard
Electrical equipment that is likely to cause serious injury or loss of life
CO2 Hazard
CO2 Hazard that is likely to cause serious injury or loss of life
Noise Levels
The noise level produced from the equipment is low level
The Reach & Wash™ System has been crash-tested at the Thatcham to the Federal Motor Vehicle Safety
Standard 208. The equipment must only be installed into motor vehicles by Ionic Systems approved installers. It
is recommended that annual safety inspections are carried out by an approved Ionic Systems Limited agent.
3
Contents Page Page
Introduction ……………….. 4
The Zero™ System
Dimensions ……………….. 5
Component Identification
- Machine Overview ……………….. 7
- Control Panel ……………….. 8
- System Housing ……………….. 10
- Holding Tank ……………….. 12
- Filter Function ……………….. 13
- Filter Function ……………….. 14
- Filter ID Discs ……………….. 15
Water Connection ……………….. 16
Effects of Low Pressure &
Temperature on Water Production……. 17
Electrical Connection ……………….. 18
General Guidance for Static Systems ... 19
Machine Warning Labels ……… 20
Zero Water Softening ……………….. 21
Zero Operation (Vehicle Mounted Machine) 22
Maintenance Procedures
General Maintenance ……………….. 31
Filter Replacement ……………….. 32
Cleaning your RO ……………….. 38
Salt Replenishment ……………….. 39
Battery Charging ……………….. 39
UV Filter Maintenance ……………….. 41
Winterisation & Storage ……………….. 44
Operational Procedure:
Cleaning Windows ……………….. 46
Warranty ……………….. 53
Annual Servicing ……………….. 54
About Ionic Systems
In 1997 Ionic Systems Ltd introduced the very first
vehicle mounted waterfed pole system, known as
the Reach & Wash™ system. Since then Ionic
Systems has continued to lead the field with its
proven designs. Ionic’s customers can be
reassured by the company’s commitment to quality
and testing of its products.
Window Cleaning has become a safety driven
industry. Ionic Systems focus is to provide up to the
minute products that are proven to be safe.
Ionic Systems Ltd manufactures the Reach & Wash™ ionic window cleaning system as well as a wide range of
other ionic cleaning products. We specialise in making the tools that do the job in the safest, most effective,
efficient and economical way. We offer the largest range of mobile water treatment systems and Waterfed Poles
in the World and are sure you’ll find our great range of ionic cleaning products to be the solutions that prove to be
immediate benefit to your business.
Zero PPM and PPB System
4
Welcome
Congratulations you are the proud owner of the Worlds most advanced yet user-friendly water
fed pole system for window and solar panel cleaning.
When it comes to everyday electronic products that we are all used too, most people manage
to get by without ever reading the ‘Instructions’ past the first few lines. But if you have read
this far then you are strongly advised to read on.
Generally, there are those who read instructions and follow simple maintenance procedures,
and those who do not. Those who take the time to follow these instructions usually enjoy
many years of service and avoid unexpected repair bills. For the other group the opposite is
true. The machine you have purchased is a water filtration system with multiple filters that
work together as a team to produce ultra pure water from any suitable potable water supply
anywhere in the World. Each and every Reach & Wash™ machine is thoroughly tested before
it leaves our manufacturing facility. Unlike electricity however, water differs from place to
place. Certainly water is water however, its delivery pressure, flow and quality changes
sometimes significantly within short distances and even at different times of the day.
Furthermore water density changes with the seasons, water is at its most dense at 4 degrees.
In winter the performance of a filter system will be different to the summer.
Ionic Systems is not responsible for your local water supply; we have no control over its
quality, delivery pressure or flow rate. Further we have no control over how you use the
machine or whether it is operated, serviced or maintained correctly. The following pages
provide guidance as well as instruction. There is a solution (usually simple) to each and every
problem that you may encounter and we have done our best to advise you well in the pages
that follow.
If you have read this far then you are encouraged to read to the end and follow the guidance
and simple maintenance procedures. If you will not be the routine operator of the machine
and you have purchased it for your staff to operate then you are encouraged to put ‘standard
operating procedures’ in place for your staff to follow.
The automated filtration system of the Zero™ PPB Reach & Wash™ System produces pure
water that is 1,000 times purer than machines that produce water of 0ppm quality. Although
the Zero™ PPB Reach & Wash™ System has 1,000 times more cleaning power than
conventional water fed pole cleaning systems, it is still important to follow the correct cleaning
procedure set out on pages 46-51.
The machines ability to produce 0ppb water is wholly dependent on the timely replacement of
filters. Failure to replace filters as necessary will reduce the machines ability to produce 0ppb
water leading to a poor window cleaning finish, customer complaints, lost profits and higher
maintenance costs. Information about filter replacement can be found on page 32.
Zero Weights & Dimensions
5
Dimensions
Zero Weights & Dimensions
6
Weights
Zero™&
System&
Weight&(Dry)&
Weight&(Wet)&
1000 Ltr
205 – 222kg
1225 – 1242 kg
900 Ltr
200 – 212kg
1112 – 1129 kg
800 Ltr
195 – 212kg
1015 – 1032 kg
700 Ltr
190 – 207kg
910 – 927 kg
600 Ltr
185 – 202kg
810 – 827 kg
500 Ltr
180 – 197kg
705 722 kg
400 Ltr
169 – 186kg
594 – 511kg
300 Ltr
164 – 190kg
489 – 506 kg
Note: Weights are given as a guide only. Actual weight may vary
Machine Component Identification
7
Component Identification
Machine Component Identification
8
Control Panel
Machine Component Identification
9
System Fuse
Box
The fuse-box holds all the fuses for the 12v side of the system. Depending upon the
specification, up to five fuses may be installed. The position, application and value are
depicted in the table below.
Fuse Box Diagram
(Fuse box positions 6-8 are not used)
Function
Amps
Position
Supply
15 A
1
Pump 1
15 A
2
Pump 2 (Hot pump on ThermoPure™ system)
15 A
3
Thermopure™ Heating Unit
20 A
4
Thermopure™ Switch
5 A
5
Machine Component Identification
10
Zero™ System
(Filters Removed)
