Preface

This document is intended to assist the service technician in the operation, maintenance and

repair of the ION Audio device. Together with the User Reference Manual, this document

provides a complete description of the functionality and serviceability of the Device. Any

comments or suggestions you may have pertaining to the document are welcome and

encouraged.

Read This!

In addition to any purchase price that ION Audio may charge as consideration for ION Audio

selling or otherwise transferring this service manual (“Manual”) to you, if you are not a service

and repair facility (“Service Center”) authorized by ION Audio in writing to be an authorized

Service Center, ION Audio sells or transfers the Manual to you on the following terms and

conditions:

Only Service Centers authorized by ION Audio in writing are authorized to perform service and

repairs covered by an ION Audio warranty (if any), and transfer of the Manual to you does not

authorize you to be an authorized Service Center. Therefore, if you perform, or if the Manual

is used to perform, any service or repairs on any ION Audio product or part thereof, any

and all warranties of ION Audio as to that product and any service contract with ION Audio

for that product shall be voided and shall no longer apply for such product, even if your

services or repairs were done in accordance with the Manual.

All service or repairs done by you or with reference to the Manual shall be solely your

responsibility, and ION Audio shall have no liability for any such repairs or service work. All such

service or repairs are performed at the sole risk of the person performing the service or

repairs. You agree that all such work will be performed in a competent, professional and safe

manner at all times and to indemnify and fully hold ION Audio and its successors and assigns

harmless in the event of any failure to so perform.

Your purchase of the Manual shall be for your own ultimate use and shall not be for purposes of

resale or other transfer.

As the owner of the copyright to the Manual, ION Audio does not give you the right to copy the

Manual, and you agree not to copy the Manual without the written authorization of ION Audio.

ION Audio has no obligation to provide to you any correction of, or supplement to, the Manual,

or any new or superseding version thereof.

ION Audio shall have the right to refuse to sell or otherwise transfer repair parts or materials to

you in its sole discretion. You shall not use, sell or otherwise transfer spare or replacement parts

supplied by ION Audio to you (i) to repair or be used in products manufactured for or by third

parties or (ii) to any third parties for any purpose.

You shall not make any warranties or guarantees with respect to the products of ION Audio or

the use thereof on behalf of ION Audio or in your own name.

The foregoing describes the entire understanding related to sale or transfer of the Manual to you,

and no other terms shall apply unless in a writing signed by an authorized representative of ION

Audio.

All Trademarks are property of their respective companies.

Confidential ION Audio Service Manual

Warnings

TO REDUCE THE RISK OF ELECTRIC SHOCK OR FIRE, DO NOT EXPOSE

THIS PRODUCT TO WATER OR MOISTURE.

The arrowhead symbol on a lightning flash inside a triangle is

intended to alert the user to the presence of uninsulated

“dangerous voltage” within the enclosed product which may be of

sufficient magnitude to constitute a risk of electric shock to

persons.

The exclamation point inside a triangle is intended to alert the user

to the presence of important operating, maintenance and servicing

instructions in the literature which accompanies the product.

REPAIR BY ANY PERSON OR ENTITY OTHER THAN AN AUTHORIZED ION

AUDIO SERVICE CENTER WILL VOID THE ION AUDIO WARRANTY.

PROVISION OF THIS MANUAL DOES NOT AUTHORIZE THE RECIPIENT TO

COMPETE WITH ANY ION AUDIO DISTRIBUTOR OR AUTHORIZED REPAIR

SERVICE CENTER IN THE PROVISION OF REPAIR SERVICES OR TO BE OR

MAKE REPAIRS AS AN AUTHORIZED SERVICE CENTER.

ALL REPAIRS DONE BY ANY ENTITY OTHER THAN AN AUTHORIZED ION

AUDIO SERVICE CENTER SHALL BE SOLELY THE RESPONSIBILITY OF

THAT ENTITY, AND ION AUDIO SHALL HAVE NO LIABILITY TO THAT

ENTITY OR TO ANY OTHER PARTY FOR ANY REPAIRS BY THAT ENTITY.

Regarding the Power Supply Fuse

Caution: The product under service may employ the use of a

replaceable fuse. Danger of fire or electrocution if fuse is incorrectly

replaced. Replace with only the same type or equivalent type

recommended by the equipment manufacturer.

Regarding the Internal Battery

Caution: The product under service may employ the use of a

internal battery. Danger of explosion if battery is incorrectly

replaced. Replace only with the same or equivalent type

recommended by the manufacturer. Dispose of used batteries

according to the manufacturer’s instruction.

Confidential ION Audio Service Manual

Safety Instructions

Carefully read the applicable items of the operating instructions and these safety suggestions

before using this product. Use extra care to follow the warnings written on the product itself and

in the operating instructions. Keep the operating instructions and safety suggestions for

reference in the future.

1. Power Source. The product should only be connected to a power supply which is

described either in the operating instructions or in markings on the product.

2. Power Cord Protection. AC power supply cords should be placed such that no one is likely

to step on the cords and such that nothing will be placed on or against them.

3. Periods of Non-use. If the product is not used for any significant period of time, the

product’s AC power supply cord should be unplugged from the AC outlet.

4. Foreign Objects and Liquids. Take care not to allow liquids to spill or objects to fall into

any openings of the product.

5. Water or Moisture. The product should not be used near any water or in moisture.

6. Heat. Do not place the product near heat sources such as stoves, heat registers, radiators

or other heat producing equipment.

7. Ventilation. When installing the product, make sure that the product has adequate

ventilation. Improperly ventilating the product may cause overheating, which may damage

the product.

8. Mounting. The product should only be used with a rack which the manufacturer

recommends. The combination of the product and rack should be moved carefully. Quick

movements, excessive force or uneven surfaces may overturn the combination which may

damage the product and rack combination.

9. Cleaning. The product should only be cleaned as the manufacturer recommends.

10. Service. The user should only attempt the limited service or upkeep specifically described in

the operating instructions for the user. For any other service required, the product should be

taken to an authorized service center as described in the operating instructions.

11. Damage to the Product. Qualified service personnel should service the unit in certain

situations including without limitation when:

a. Liquid has spilled or objects have fallen into the product,

b. The product is exposed to water or excessive moisture,

c. The AC power supply plug or cord is damaged,

d. The product shows an inappropriate change in performance or does not operate

normally, or

e. The enclosure of the product has been damaged.

Level Code Name Descri

tion unit

location

+ 2050100285 WOODEN TURNTABLE IT61

(

TT15015

)

，ION, NC-D03 PCS 1.00

++ 2010100399 MAIN PCB BOARD TT15015 MAIN LCD-V1.0 Dual side,

half finish

PCS 1.00 half finished

+++ 1010120148 PCB board TT15015 MAIN LCD-V1.0

336×58×1.2MM FR4 with tin, dual

side

PCS 1.00 wooden panel

+++ 1010260050 SMD PRECISION

RESISTANCE

SMT0603,470R,±1% PCS 3.00 R24,R25,R30

+++ 1010260016 SMD PRECISION

RESISTANCE

SMT0603,1K,±1% PCS 2.00 R1,R9

+++ 1010260004 SMD PRECISION

RESISTANCE

SMT0603,1.2K,±1% PCS 2.00 R2,R10

+++ 1010260006 SMD PRECISION

RESISTANCE

SMT0603,1.8K,±1% PCS 4.00 R3,R4,R11,R12

+++ 1010260020 SMD PRECISION

RESISTANCE

SMT0603,2.7K,±1% PCS 2.00 R5,R13

+++ 1010220108 SMD RESISTOR SMT0603,15R,±5% PCS 1.00 R77

+++ 1010220016 SMD RESISTOR SMT0603,1K,±5% PCS 29.00 R14,R15,R16,R18,R1

9,R20,R23,R27,R29,

R31,R35,R39,R40,R4

1,R42,R43,R44,R45,

R48,R51,R52,R53,R5

4,R76,R79,R81,R83,

R86,R87

+++ 1010220018 SMD RESISTOR SMT0603,2.2K,±5% PCS 2.00 R72,R69

+++ 1010220099 SMD RESISTOR SMT0603,10K,±5% PCS 30.00 R17,R21,R22,R32,R3

3,R36,R37,R38,R46,

R47,R49,R50,R55,R5

6,R57,R58,R59,R60,

R61,R62,R63,R65,R6

6,R67,R70,R71,R75,

R80,R82,R85

+++ 1010220043 SMD RESISTOR SMT0603,30K,±5% PCS 2.00 R73,R74

+++ 1010220058 SMD RESISTOR SMT0603,47K,±5% PCS 1.00 R34

+++ 1010220063 SMD RESISTOR SMT0603,51K,±5% PCS 2.00 R68,R64

+++ 1010220007 SMD RESISTOR SMT0603,100K,±5% PCS 2.00 R78,R8

+++ 1010220112 SMD RESISTOR SMT0603,10M,±5% PCS 1.00 R84

+++ 1010303026 MLCC SMT0603,20pF,±5% PCS 2.00 C6,C2

+++ 1010303032 MLCC SMT0603,22pF,±5% PCS 2.00 C38,C37

+++ 1010303001 MLCC SMT0603,100PF,±5% PCS 2.00 C29,C11

+++ 1010303103 MLCC SMT0603,331,±10% PCS 1.00 C14

+++ 1010303003 MLCC SMT0603,102,±10% PCS 5.00 FC3,C18,C24,C32,C

+++ 1010303004 MLCC SMT0603,103,±10% PCS 6.00 C7,C8,C9,C10,C30,C

+++ 1010303006 MLCC SMT0603,104,±10% PCS 10.00 FC1,FC2,FC4,C5,C1

9,C21,C22,,C34,C35,

C36

+++ 1010303030 MLCC SMT0603,224,±10% PCS 6.00 C12,C16,C17,C23,C2

5,C27

+++ 1010303050 MLCC SMT0603,474,±10% PCS 1.00 C13

Bill of Materials (BOM)

+++ 1010303007 MLCC SMT0603,105,±20% PCS 3.00 C1,C26,C28

+++ 1010303068 MLCC SMT0805,106,+80%-20% PCS 2.00 C3,C4

+++ 1010401004 SMD diode IN4148 LL-34 PCS 2.00 D6,D7

+++ 1010401001 SMD diode M1 IN4001 DO-214AC PCS 1.00 D2

+++ 1010306036 electrol

tic capacito

4×7MM,22uF/16V,+80%-20% PCS 1.00 E3

+++ 1010306098 electrol

tic capacito

4×7MM,47uF/16V,+80%-20% PCS 1.00 E4

+++ 1010306024 electrolytic capacitor 5×7MM,100uF/16V,+80%-20% PCS 7.00 E1,E2,E5,E6,E7,E9,E

+++ 1010306053 insertion inductance 6×7MM,220uF/16V,+80%-20% PCS 1.00 E8

+++ 1010620155 SMD IC CA69F32L3 LQFP-64 TEST CODE：

(1316-V09-20150704(EU))

PCS 1.00 U5

+++ 1010620019 SMD IC C9630 OPT-24 PCS 1.00 U6

+++ 1010620156 SMD IC WB6332A SOT-23-5 PCS 1.00 U1

+++ 1010620065 SMD IC JRC4558 SOP-8 PCS 1.00 U4

+++ 1010620006 SMD IC LM7805 TO-252

(

Stabilivolt IC

)

PCS 1.00 U3

+++ 1010520027 SMD Triode SOT-23 S8050 PCS 4.00 Q1,Q2,Q3,Q6

+++ 1010620060 SMD IC 7533 SOT-89 PCS 1.00 Q4

+++ 1010520023 SMD Triode SOT-23 S8550 PCS 1.00 Q5

+++ 1010904006 TOUCH SWITCH 贴片 6×6×5MM PCS 12.00 SW1-SW12

+++ 1012600024 needle file 3P/2.0MM strai

ht pin PCS 2.00 CN1,CN3

+++ 1012600025 needle file 4P/2.0MM strai

ht pin PCS 1.00 CN4

+++ 1012600026 needle file 5P/2.0MM strai

ht pin PCS 1.00 CN6

+++ 1013800004 ENCODER RE11309O-H1-20T20-KQ20A10-02

L=27MM 18齿

PCS 2.00 SW14,SW13

+++ 1011010004 Crystal Oscillator plug in Ø3×8MM 32.768KHZ±20ppm PCS 2.00 Y1,Y4

+++ 1010403002 insertion LED plug in Ø3MM GREEN , Long feet PCS 1.00 D8

+++ 1010403001 insertion LED plu

in Ø3MM RED , Lon

fee

PCS 1.00 D1

+++ 1061300001 Besswax Huizhou B

5.00

M LOOP

+++ 1060600001 YELLOW GLUE QC-883 g 6.00 Magnetic Bar stand

+++ 1012710001 Magnetic Bar Ø10×60MM PCS 1.00 Magnetic Bar stand

+++ 2020500006 Ma

netic Bar stand 10×30MM PCS 2.00 main PCB board

+++ 1010711005 AM loop Ø10.2M7 80T(lead wire 50MM) JiaDi PCS 1.00 fixed by Besswax

+++ 2010100407 BT MODULE BT1213H CSR4.0 BT

name：Complete LP

PCS 1.00 U2

+++ 1010402007 LED backli

ht BL-73056 backli

ht 94×28×2.8MM PCS 1.00 BL1

+++ 1011402012 LCD DISPLAY RXK73056 HTN Negative full

penetration 80×30/28×1.1MM 38PIN

PCS 1.00 LCD1

+++ 1011702549 LINES 24# 10P2H P=2.0MM L=270MM PCS 1.00 CN2

++ 1011704009 sin

le line 26# 1P L=1800MM 370MM blac

PCS 1.00 LCD board FM1

++ 2010100400 AMPLIFIER BOARD TT15015 AMP-V1.0 dual side , half

finished

PCS 1.00 half finished

+++ 1010120149 PCB board TT15015 AMP-V1.0 160×58×1.2MM

FR4 with tin , dual side

PCS 1.00

+++ 1010220084 SMD RESISTOR SMT1206,0R,±5% PCS 1.00 R56

+++ 1010220003 SMD RESISTOR SMT0603,0R,±5% PCS 5.00 R1,R2,R52 R62 R63

+++ 1010220019 SMD RESISTOR SMT0603,2.2R,±5% PCS 2.00 R115,R104

+++ 1010220008 SMD RESISTOR SMT0603,100R,±5% PCS 8.00 R19,R21,R22,R25,R6

7,R73,R100,R101

+++ 1010220026 SMD RESISTOR SMT0603,220R,±5% PCS 1.00 R89

+++ 1010220046 SMD RESISTOR SMT0603,330R,±5% PCS 1.00 R46

+++ 1010220122 SMD RESISTOR SMT0603,390R,±5% PCS 2.00 R116,R99

+++ 1010220016 SMD RESISTOR SMT0603,1K,±5% PCS 12.00 R14,R20,R31,R37,R1

11,R113,R109,R112,

R121,R134 R7 R8

+++ 1010220034 SMD RESISTOR SMT0603,2K,±5% PCS 3.00 R26,R64 R47

+++ 1010220018 SMD RESISTOR SMT0603,2.2K,±5% PCS 2.00 R40,R42

+++ 1010220037 SMD RESISTOR SMT0603,3.3K,±5% PCS 1.00 R34

+++ 1010220053 SMD RESISTOR SMT0603,4.7K,±5% PCS 3.00 R28,R33,R54

+++ 1010220060 SMD RESISTOR SMT0603,5.1K,±5% PCS 2.00 R6,R5

+++ 1010220061 SMD RESISTOR SMT0603,5.6K,±5% PCS 4.00 R17,R24,R102,R103

+++ 1010220069 SMD RESISTOR SMT0603,6.8K,±5% PCS 4.00 R44,R45,R59,R60

+++ 1010220099 SMD RESISTOR SMT0603,10K,±5% PCS 21.00 R3,R4,R11,R12,R13,

R16,R35,R36,R38,R4

9,R71,R76,R77,R110

,R118,R131,R136,R1

08,R107,R105,R106

+++ 1010220027 SMD RESISTOR SMT0603,22K,±5% PCS 2.00 R15,R114

+++ 1010220030 SMD RESISTOR SMT0603,24K,±5% PCS 2.00 R72,R66

+++ 1010220033 SMD RESISTOR SMT0603,27K,±5% PCS 2.00 R9,R10

+++ 1010220058 SMD RESISTOR SMT0603,47K,±5% PCS 2.00 R32,R125

+++ 1010220066 SMD RESISTOR SMT0603,56K,±5% PCS 2.00 R48,R70

+++ 1010220007 SMD RESISTOR SMT0603,100K,±5% PCS 10.00 R30,R39,R50,R55,R6

8,R69,R74,R75,R122

,R133

+++ 1010220010 SMD RESISTOR SMT0603,120K,±5% PCS 2.00 R23,R18

+++ 1010220025 SMD RESISTOR SMT0603,220K,±5% PCS 4.00 R41,R43,R51,R53

+++ 1010220017 SMD RESISTOR SMT0603,1M,±5% PCS 2.00 R27,R29

+++ 1010303053 MLCC SMT0603,47pF,±5% PCS 2.00 C13,C11

+++ 1010303013 MLCC SMT0603,151,±10% PCS 2.00 C21,C16

+++ 1010303047 MLCC SMT0603,470pF,±10% PCS 4.00 C12,C14,C71,C77

+++ 1010303019 MLCC SMT0603,182,±10% PCS 2.00 C18,C19

+++ 1010303028 MLCC SMT0603,222,±10% PCS 4.00 C4,C6,C51,C52

+++ 1010303048 MLCC SMT0603,472,±10% PCS 2.00 C3,C5

+++ 1010303025 MLCC SMT0603,203,±10% PCS 1.00 C60

+++ 1010303035 MLCC SMT0603,273,±10% PCS 2.00 C22,C15

+++ 1010303006 MLCC SMT0603,104,±10% PCS 18.00 C24,C25,C32,C33,C3

4,C44,C48,C49,C64,

C65,C66,C67,C75,C7

8,C80,C82,C83,C92

+++ 1010303030 MLCC SMT0603,224,±10% PCS 2.00 C76,C73

+++ 1010303007 MLCC SMT0603,105,±20% PCS 22.00 C7,C8,C9,C10,C17,C

20,C23,C26,C27,C28

,C29,C30,C31,C39,C

40,C45,C46,C50,C57

,C58,C59,C63

+++ 1010303031 MLCC SMT0603,225,±20% PCS 8.00 C35,C36,C37,C38,C6

8,C69,C72,C74

+++ 1010406005 brid

e SMD DB107S 1A1000

PCS 1.00 DB1

+++ 1010401004 SMD diode IN4148 LL-34 PCS 3.00 D1,D11,D12

+++ 1010401001 SMD diode M1 IN4001 DO-214AC PCS 1.00 D13

+++ 1010405002 SMD Stabilivolt Diode

5.1V 1/2W LL-34 PCS 1.00 ZD1

+++ 1010520009 SMD Triode SOT-23 9014C PCS 4.00 Q1,Q12,Q15,Q22

+++ 1010520027 SMD Triode SOT-23 S8050 PCS 9.00 Q10,Q11,Q14,Q17,Q

18,Q20,Q21,Q24,Q2

+++ 1010520010 SMD Triode SOT-23 A03401 PCS 4.00 Q13,Q16,Q19,Q23

+++ 1011810011 SMD Fuse SMT1206 2A 250V PCS 1.00 F1

+++ 1010708012 SMD beads SMT0603 31R/100MHZ,±25% PCS 2.00 L1,L3

+++ 1010702018 SMD INDUCTOR SMT0805 100uH/600MA,±20% PCS 1.00 L2

+++ 1010306031 electrolytic capacitor Plug in 5×11MM,22uF/16V,+80%-

20%

PCS 1.00 EC13

+++ 1010306034 electrolytic capacitor plug in 5×11MM,47uF/16V,+80%-

20%

PCS 6.00 EC7,EC8,EC9,EC10,

EC12,EC16

+++ 1010306028 electrolytic capacitor Plug in 5×11MM,100uF/16V,+80%-

20%

PCS 11.00 E1,EC2,E2,EC3,EC1

1,EC18,EC19,EC25,

EC26,EC27,EC28

+++ 1010306169 insertion inductance Plug in 6×12MM,100uF/25V,+80%-

20%

PCS 1.00 EC22

+++ 1010306045 electrolytic capacitor Plug in 6×12MM,220uF/16V,+80%-

20%

PCS 3.00 EC1,EC14,EC15

+++ 1010306050 electrolytic capacitor Plug in 8×12MM,220uF/25V,+80%-

20%

PCS 1.00 EC17

+++ 1010306086 electrolytic capacitor Plug in 8×16MM,1000uF/16V,+80%-

20%

PCS 2.00 E24,EC20

+++ 1010306165 insertion inductance Plug in 10×17MM,1000uF/25V,+80%

20%

PCS 1.00 EC23

+++ 1010306087 electrolytic capacitor Plug in 13×25MM,3300uF/25V,+80%

20%

PCS 1.00 EC21

+++ 1010620065 SMD IC JRC4558 SOP-8 PCS 1.00 U5

+++ 1010620045 SMD IC PT2314 SOP-28 PCS 1.00 U2

+++ 1010610041 insertion IC UTC7805 I≧1.5A TO-220(stabilvolt

)

PCS 1.00 U1

+++ 1010610022 insertion IC UTC8227 HDIP-12 PCS 1.00 U3

+++ 1010610013 insertion IC UTC22241 DIP-9 PCS 1.00 U4

+++ 1012600023 needle file 2P/2.0MM strai

ht pin PCS 1.00 CN14

+++ 1012600022 needle file 2P/2.5MM strai

ht pin PCS 1.00 CN15

+++ 1012600024 needle file 3P/2.0MM strai

ht pin PCS 3.00 CN3,CN5,CN7

+++ 1012600025 needle file 4P/2.0MM strai

ht pin PCS 2.00 CN11,CN8

+++ 1012600018 needle file 4P/2.5MM strai

ht pin PCS 1.00 CN4

+++ 1012600027 needle file 6P/2.0MM strai

ht pin PCS 1.00 CN12

+++ 1012600026 needle file 5P/2.0MM strai

ht pin PCS 1.00 CN6

+++ 1012600019 needle file 5P/2.5MM strai

ht pin PCS 1.00 CN1

+++ 1012600033 needle file 10P/2.0MM strai

ht pin PCS 1.00 CN10

+++ 1022500004 heatsink 35×20×8MM PCS 1.00 U3 UTC8227

+++ 1022500003 heatsink 15×10×25MM(pin 2MM) PCS 1.00 U1(UTC7805 TO220)

+++ 1020100219 screw 3×6BM PCS 1.00 headsink and U1

+++ 1011701080 shield line 24# 6P2H P=2.5MM L=300MM with

PCS 1.00 AMP CW1 TO

mechanism

++ 2010100410 PHONE board TT15015 PHONE-V1.0 single board PCS 1.00 half finished

+++ 1010110187 PCB board TT15015 PHONE-V1.0

26×17×1.6MM 94V0 sin

le board

PCS 1.00

+++ 1010220085 SMD RESISTOR SMT1206,100R,±5% PCS 2.00 R4 R60

+++ 1012507006 headphone

ack ST-413-06W SHENJIU PCS 1.00 JK2

+++ 1011702550 lines 26# 5P1H P=2.5MM L=390MM PCS 1.00 AMP CN1 TO

PHONE BOARD

CW2

++ 2010100411

UX board TT15015 AUX-V1.0 sin

le board PCS 1.00 half finished

+++ 1010110188 PCB board TT15015 AUX-V1.0 26×17×1.6MM

94V0 sin

le board

PCS 1.00

+++ 1012507006 headphone

ack ST-413-06W SHENJIU PCS 1.00 JK1

+++ 1010220005 SMD RESISTOR SMT0603,1.5K,±5% PCS 2.00 R5 R6

+++ 1011701081 shield line 24# 5P1H P=2.0MM L=140MM PCS 1.00 Main CN6 to AUX

boardCW3

++ 2010100412 USB board TT15015 USB-V1.0 sin

le board PCS 1.00 half finished

+++ 1010110189 PCB board TT15015 USB-V1.0 28×17×1.5MM

94V0 sin

le board

PCS 1.00

+++ 1010702028 SMD INDUCTOR SMT0603 600R/100MHZ PCS 2.00 L1，L2

+++ 1012506004 USB

ack USB-LT-001-02 PCS 1.00

+++ 1011702558 LINES 24# 4P2H P=2.0MM L=240MM with

PCS 1.00

++ 2010100413 ERP2 PCB BOARD H9287-ERP2 V1.0 single board

TT15015

PCS 1.00 half finished

+++ 1010110172 PCB board H9287 75×29×1.6MM FR-1 single

board

PCS 1.00

+++ 1020600001 connect line for antenna 2×4MM PCS 4.00

+++ 1010610038 insertion IC EL817C DIP-4

(

Optocoupler

)

PCS 1.00 IC1

+++ 1010510007 plug in Silicon controlled

tube

TO-92 BT131 PCS 1.00 TR1

+++ 1011820010 plug in fuse 2A250V 3.6×10MM glass packaging PCS 1.00 F1

+++ 1010306054 electrolytic capacitor plug in 5×11MM,47uF/25V,+80%-

20%

PCS 1.00 C9

+++ 1010306023 electrolytic capacitor plug in 5×7MM,47uF/16V,+80%-20% PCS 1.00 C5

+++ 1010307021 MYLAR CAP plug in , pin distance 10MM

103J/630V

PCS 1.00 C7

+++ 1010307022 MYLAR CAP plug in , pin distance 10MM

563J/630V

PCS 1.00 C8

+++ 1012600022 needle file 2P/2.5MM strai

ht pin PCS 1.00 S1

+++ 1012600019 needle file 5P/2.5MM strai

ht pin PCS 1.00 J2

+++ 1010620140 inte

rated circui

H9287 SOP-8 test code：

1FB PCS 1.00 U1

+++ 1010520027 SMD Triode SOT-23 S8050 PCS 2.00 Q2 Q3

+++ 1010520009 SMD Triode SOT-23 9014C PCS 2.00 Q4 Q5

+++ 1010520010 SMD Triode SOT-23 A03401 PCS 1.00 Q1

+++ 1010220046 SMD RESISTOR SMT0603,330R,±5% PCS 2.00 R11 R12

+++ 1010220065 SMD RESISTOR SMT0603,560R,±5% PCS 1.00 R23

+++ 1010220016 SMD RESISTOR SMT0603,1K,±5% PCS 4.00 R1 R2 R3 R4

+++ 1010220021 SMD RESISTOR SMT0603,2.7K,±5% PCS 1.00 R13

+++ 1010220053 SMD RESISTOR SMT0603,4.7K,±5% PCS 1.00 R17

+++ 1010220099 SMD RESISTOR SMT0603,10K,±5% PCS 1.00 R16

+++ 1010220027 SMD RESISTOR SMT0603,22K,±5% PCS 1.00 R15

+++ 1010220007 SMD RESISTOR SMT0603,100K,±5% PCS 3.00 R5 R6 R7

+++ 1010220072 SMD RESISTOR SMT0603,680K,±5% PCS 1.00 R14

+++ 1010220017 SMD RESISTOR SMT0603,1M,±5% PCS 2.00 R18 R19

+++ 1010401004 SMD diode IN4148 LL-34 PCS 2.00 D3 D4

+++ 1010405002 SMD Stabilivolt Diode

5.1V 1/2W LL-34 PCS 1.00 D2

+++ 1010405025 SMD Stabilivolt Diode

4.3V 1/2W LL-34 PCS 1.00 D1

+++ 1010401034 SMD diode IN4007 DO-214AC PCS 2.00 D5 D6

+++ 1010303004 MLCC SMT0603,103,±10% PCS 2.00 C11 C12

+++ 1010303006 MLCC SMT0603,104,±10% PCS 2.00 C2 C10

+++ 1010303007 MLCC SMT0603,105,±20% PCS 2.00 C3 C4

+++ 1010303051 MLCC SMT0603,475,±20% PCS 1.00 C6

+++ 1010220133 SMD RESISTOR SMT1206,30R±5% PCS 1.00 R24

+++ 1010220087 SMD RESISTOR SMT1206,220R,±5% PCS 1.00 R10

+++ 1010220144 SMD RESISTOR SMT1206,150K,±5% PCS 4.00 R8 R9 R20 R21

+++ 1010303067 MLCC SMT1206,106,+80%-20% PCS 1.00 C1

2010100396 mechanism JW-30-1 ABS black

+ 2010100384 switch board of the

mechanism

JW-30 SK REV1.0 switch board PCS 1.00

++ 1010110185 PCB board JW-30 SK REV1.0 60×20×1.6MM

94V0-KB sin

le board

PCS 1.00

++ 1010210038 Plug in resistance pin distance 5MM 470R,±5% 1/8W PCS 1.00 R1

++ 1012600030 needle file 6P/2.5MM 90 de

ree PCS 1.00 CN2

++ 1010902038 to

le switch SS-12F46-G8 3×3 PCS 1.00 SW1

++ 1010902039 to

le switch SS-13E05-G8 3×5 PCS 1.00 SW2

++ 1010250010 ad

ustable resistance SR-085 500R PCS 1.00 VR2

++ 1011709003 mechanism line 26# 5P2.5+7P2.0 pin distance +2P

with tin 3MM L=100MM

PCS 1.00 CN1

+ 1013200004 Cartrid

e JP , CZ-800-10 PCS 1.00

+ 1011703024 cartrid

e line 1P L=310MM white PCS 1.00 cartrid

+ 1011703025 cartrid

e line 1P L=310MM red PCS 1.00 cartrid

+ 1011703026 cartridge line 2P L=310/50MM black with ground PCS 1.00 cartridge

+ 1010908002 leaf switch SJ-SW-115-2

(

soft

)

PCS 1.00 panel

+ 1014000022 MOTOR 3 spped EG-530SD-

(

33/45/78

)

+5P2.5

PCS 1.00

+ 2020100061 middle panel JW-30-1 ABS black PCS 1.00

+ 2020500039 platte

JW-20 ABS black PCS 1.00

+ 2020500029 1.5inch platte

JW-20 ABS black PCS 1.00

+ 2020500030 tonearm lift level JW-20 ABS black PCS 1.00

+ 2020500031 tonetube socket JW-20 ABS black PCS 1.00

+ 2020500032 tonearm shaft JW-20 ABS black PCS 1.00

+ 2020500033 arm clip JW-20 ABS black PCS 1.00

+ 2020500034 tonetube buckle JW-20 ABS black PCS 1.00

+ 2020500035 wafe

JW-20 ABS black PCS 1.00

+ 2020500036 switch film JW-20 ABS black PCS 1.00

+ 2020500037 switch protective film JW-20 ABS black PCS 1.00

+ 2020500038 screw for motor JW-20 ABS black PCS 3.00

+ 1021200024 PVC pad Ø12.5×7.5×0.3MM PCS 1.00

+ 1013401001 Motor shockproof rubber Ø9×Ø4×5MM

(

45 de

ree

)

PCS 3.00

+ 1061600001 bel

Ø128×0.5×4.7MM PCS 1.00

+ 1021500002 copper tube Ø6×133×0.25MM silver PCS 1.00

+ 1021400003 E shape sprin

pad Ø6 black PCS 1.00

+ 1021200034 Sprin

(

)

Ø5×7×6T×0.6 PCS 1.00 metal shaft

+ 1020400010 sprin

(

)

Ø0.25×OD5.0×14T×15L PCS 1.00 switch film

+ 1020400030 metal shaft

(

)

Ø2×33MM chrome PCS 1.00 tonearm lift level

+ 1021600006 metal shaft 7.88mm for platter PCS 1.00

+ 1021600003 SCREW 2.6×8.5PM PCS 1.00 middle panel

Autres manuels pour Complete LP

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels ION Intervenants

ION

ION TOTAL PA GLOW Manuel utilisateur

ION

ION patio mate Manuel utilisateur

ION

ION PRO GLOW EXPRESS Manuel utilisateur

ION

ION Uber Boom Ultra Manuel utilisateur

ION

ION Aquaboom Manuel utilisateur

ION

ION Mustang LP Manuel utilisateur

ION

ION TOTAL PA ULTIMATE Manuel utilisateur

ION

ION PARTY ROCKER Manuel utilisateur

ION

ION patio mate Manuel utilisateur

ION

ION ISP75A Manuel utilisateur

ION

ION Pathfinder 280 Manuel utilisateur

ION

ION Pro Glow 8 Manuel utilisateur

ION

ION Tailgater Flash Manuel utilisateur

ION

ION WATER ROCKER Manuel utilisateur

ION

ION BLOCK ROCKER BLUETOOTH Manuel utilisateur

ION

ION SOUND SPLASH Manuel utilisateur

ION

ION SURVIVAL SCOUT Manuel utilisateur

ION

ION Pro Glow 8 Manuel utilisateur

ION

ION TAILGATER BLUETOOTH Manuel utilisateur

ION

ION Block Rocker Max iPA76C2 Manuel utilisateur

ION

ION PARTY BOOM PLUS Manuel utilisateur

ION

ION PATHFINDER 320 Manuel utilisateur

ION

ION Block Rocker Bluetooth M5 Manuel utilisateur

ION

ION Bright Max Plus Manuel utilisateur

Manuels Intervenants populaires d'autres marques

argon audio

argon audio IE20 Manuel utilisateur

Denon

Denon SC-N7 Manuel utilisateur

Gemline

Gemline Ace 3952 Manuel utilisateur

Focal

Focal ON WALL 300 Mode d’emploi

HEADRUSH

HEADRUSH Maximus HRSP 5024 Manuel utilisateur

SoundLogic

SoundLogic BCCS-6/6395 Manuel utilisateur

Peavey

Peavey DTH 218 Manuel utilisateur

Avantree

Avantree Pluto Air Manuel utilisateur

Morel

Morel Integra Series INTEGRA OVATION 4 Manuel utilisateur

Oppo

Oppo SONICA Manuel utilisateur

Bose

Bose SoundLink Wireless Music System Manuel utilisateur

Rocksteady

Rocksteady Stadium Manuel utilisateur

Bowers & Wilkins

Bowers & Wilkins 4 Manuel utilisateur

Sonance

Sonance SONOS OUTDOOR Series Manuel utilisateur

Electro-Voice

Electro-Voice EVID FM4.2 Manuel utilisateur

Pioneer

Pioneer XW-HTD630 Manuel utilisateur

Onn

Onn BWA16AA002 Manuel utilisateur

HP GL313AA - USB Speakers PC Multimedia Manuel utilisateur
