IOGear M1190 Manuel utilisateur
Installation
Installation Guide
2-Port USB KVM with File Management
GCS642U
PART NO. M1190
3
Table of Contents
System Requirements 6
Overview 7
LED Display Status 9
Hardware Setup 10
Basic KVM Operations 13
Hotkeys Summary Table 14
File Management 16
File Transfer 18
File Sync 20
Keyboard Emulation 23
Troubleshooting 25
Factory Default Settings 27
Specications 28
CE Statement 30
Federal Communications Commission (FCC)
Statement 31
Contact 32
Limited Warranty 33
4
This manual uses the following conventions: Monospaced Indicates text that you should key in.
[ ] Indicates keys you should press. For example, [Enter] means to press the Enter key. If keys need
to be chorded, they appear together in the same bracket with a plus sign between them: [Ctrl+Alt].
1. Numbered lists represent procedures with sequential steps.
• Bullet lists provide information, but do not involve sequential steps.
–> Indicates selecting the option (on a menu or dialog box, for example), that comes next. For
example, Start ––> Run means to open the Start menu, and then select Run.
Indicates critical information.
5
Package Contents
• 1 x 2 port USB KVM with File Transfer
• 1 x User Manual
• 1 x Warranty Card
Verify all the components are present and that nothing was damaged in shipping. If you encounter a
problem, contact your dealer, or IOGEAR.
Read this manual thoroughly and follow the installation and operation procedures carefully to prevent any
damage to the unit, and / or any of the devices connected to it
6
System Requirements
Console
• A VGA, SVGA, or multisync monitor capable of the highest resolution that you will be using on any com-
puter in the installation
• A USB keyboard and a USB mouse
• Microphone and speakers (optional)
Computers
The following equipment must be installed on each computer that is to be connected to the system:
• A VGA, SVGA, or multisync video port
• USB Type A ports
• Microphone and speaker ports (optional)
Operating System
• Windows XP, Windows Vista (32-bit / 64-bit)
• Windows 7 (32-bit / 64-bit)*
Note: File management AP is supported by Windows OS only
7
Overview
1. Port LEDs
A port LED lights to indicate that the computer
attached to its corresponding port has the
KVM focus.
2. KVM Cables
These cables attach to the computers in your
installation.
3. Console Ports
The cables from your USB mouse, monitor,
and USB keyboard plug in here. The ports are
marked with an icon on the bottom panel to
indicate which is which.
4. Speaker Jack
Your console speakers plug in here.
5. Microphone Jack
Your console microphone plugs in here.
4
2
3
1
5
8
4
2
3
15
1. Speaker (Green)
Plugs into the computer’s speaker port
2. Keyboard/Mouse (Purple)
Plugs into any available Type A USB port onthe
computer
3. Video
Plugs into the computer’s VGA port
4. File Transfer (Black)
Plugs into any available Type A USB port onthe
computer. Note: If there is only one USB port
on the computer, you can connect a USB
hub tothe computer, then plug the Keyboard/
Mouse cable (purple) and then the File Transfer
cable (black) into the USB hub
5. Microphone (Pink)
Plugs into the computer’s speaker port
9
LED Display Status
Status Indication
Orange On/Off Port is selected / Port is not selected
Green On Port is connected to an active computer
Flashing (one) Port is connected to an active computer and is being
accessed in Auto Scan Mode orunder Keyboard/ Mouse
USB Sync
Flasing (all) File transfer/sync is in operation
10
Please Make sure that power to all the devices you will be installing has been turned off. You must
unplug the power cords of any computers that have the Keyboard Power On function
Hardware Setup
Step1
Plug your USB keyboard, USB mouse, and
monitor into their respective ports on the
GCS642U.
Note: If your are using a wireless keyboard and mouse combo, the receiver must plug into the GCS642U’s
keyboard port in order for the hotkeys to function.
