IOGear GHPB21 Manuel utilisateur
HomePlug to Ethernet Bridge
User Manual (GHPB21)
Thank you for purchasing one of the most user-friendly networking devices on the market. IOGEAR’s HomePlug
to Ethernet Bridges are first-class networking devices designed to network your computers at home (or in your
small office). This device allows you to set up your home network via the most pervasive medium in your house
– the home power lines. It is easy to set up, and it doesn’t require any additional wiring in the house.
To better serve you, IOGEAR offers an array of additional USB 2.0, USB 1.1, FireWire, KVM, and other
peripheral products. For more information or to purchase additional IOGEAR products, visit us at
www.IOGEAR.com
We hope you enjoy using your IOGEAR HomePlug to Ethernet Bridge, another first-rate connectivity solution
from IOGEAR.
©2003IOGEAR. AllRightsReserved. PKG-M0066
IOGEAR, the IOGEAR logo, MiniView, VSE are trademarks or registered trademarks of IOGEAR, Inc. Microsoft and
Windows are registered trademarks of Microsoft Corporation. IBM is a registered trademark of International Business
Machines, Inc. Macintosh, G3/G4 and iMac are registered trademarks of Apple Computer, Inc. IOGEAR makes no
warranty of any kind with regards to the information presented in this document. All information furnished here is for
informational purposes only and is subject to change without notice. IOGEAR, Inc. assumes no responsibility for any
inaccuracies or errors that may appear in this document.
Welcome
Table of Contents
Overview
Features
Requirements
Introduction
Installation
NetworkConfiguration
NetworkingBasics
-NetworkSetup Wizard
-CheckingIPAddress
-AssignaStaticIPaddress
-Sharing Disks/Folders
-SharingPrinters
-AccessingtheInternet
Troubleshooting
02
03
04
05
07
14
27
27
38
40
43
48
59
63
TechnicalSupport
Product Specifications
LimitedWarranty
67
69
70
○○○○○○○○○○○○○
○○○○○○○○○○○○○
○○○○○○○○○○○○○
○○○○○○○○○○○○
○○○○○○○○○○○○○
○○○○○○○○
○○○○○○○○○○
○○ ○○○○○○○
○○ ○○○○○○
○○○○○○○○○
○○○○○○○○○○
○○ ○○○○○○○○○
○○○○○○○○○○
○○ ○○○○○○
○○○○○○○○○○○
○○○○○○○○○○○
○○○○○○○○○
Overview
IOGEAR's HomePlug Powerline Network Ethernet Bridge allows you to network your home comput-
ers through the electric power lines in the house. Setting up a home network has never been so
simple, just connect your computer to the HomePlug Bridge via the CAT5 patch cable provided in the
package, and then plug the power end to your AC power outlet, you are connected!
This unit is compliant to HomePlug Powerline Specification 1.0 and offers up to 14 Mbps bandwidth
while being less prone to interference. By offering 56-bit DES encryption, it is also much more
secure than other home networking technologies such as wireless Ethernet.
2
Features
• No extra wires, using the most pervasive medium in your home - power lines
• Allows multiple computers to share Internet access, printers, and other resources through the
power lines
• Very easy and intuitive to set up and install
• HomePlug Powerline Specification 1.0 compliant
• Up to 14 Mbps bandwidth
• Up to 990' distance through the power lines, far enough for most households
• Worldwide compatibility
• Low risk of interference by other RF sources
• 56-bit DES encryption assures data security
• Signal will not pass power meter, thus keeping the data safe in the house
• Encryption done by hardware, with no sacrifice on bandwidth
• Most reliable home networking technology
3
• Available AC power outlets in the room.
• Standard home power line wiring.
• Computers with 10/100Base-T adapters, or 10/100Base-T switch/hub.
• When used as a node: Windows 98SE, ME, 2000, XP.
• When used as a bridge: any operating system (OS transparent).
Requirements
4
System Requirements
IOGEAR's HomePlug to Ethernet Bridge allows you to network your computers via your existing
home power lines. It offers a data transmission speed of up to 14 Mbps, and reaches up to 990 feet
through standard power lines.
Package contents:
1. HomePlug to Ethernet Bridge
2. CAT5 patch cable
3.Powercable
4.UserManual
5.WarrantyRegistrationCard
Introduction
5
1. 2. 3.
Introduction
6
FrontView:(Drawing)
1. Power LED - lights up in green when plugged into
a power outlet
2. Collision LED - lights up in green whenever there
is collision
3. Link LED - lights up in green after plugged into a
poweroutlet
4. ACT LED - blinks in green when there is network
activity
5. LINK/ACT LED - blinks when data is sent through
Homeplug Connection
6. Ethernet port - connecting to the computer
BackView:
1. Power port - connecting to the wall outlet
BackView
FrontView
1. 2. 3. 4. 5. 6.
1.
Installation
There are several ways to network your computers using the HomePlug Bridge. Before we get
started, please NOTE:
Do not place HomePlug devices under direct sunlight or near high heat emitting devices;
Do not place HomePlug devices near water or wet surfaces to avoid electric hazards;
Do not place HomePlug devices on any moving or unstable surfaces;
It is recommended that you plug the HomePlug devices directly into the wall outlets, not to any power
adapters, surge protectors or any device that filters signals.
If you plan to use this unit as a BRIDGE, not as a NODE; there is a limitation of having sixteen
BRIDGES PER NETWORK,(refer to the NetworkTerms for details):
1. Remove the HomePlug Bridge, the power cord, the CAT5 cable and the installation CD from the package.
2. Allocate a space for the adapter's placement. Make sure you avoid the places mentioned above.
3. Plug one end of the CAT5 cable into the Ethernet port on the computer, and the other end into the Ethernet port
of the bridge.
4. Plug the power cord into the HomePlug bridge and wall outlet.
5. At this point, the Power and Link LED should be on, and you should see the ACT (Activity) LED start blinking.
6. Turn on your computer and set up your networks (refer to Network Basics for more information).
7
