InWin 305 Manuel utilisateur

User Manual

The IN WIN team presents

the 305, a simple, yet elegant

computer chassis crafted from

steel and tempered glass.

While the 305 is a stunning

visual display, it’s because

of the quality and skilled

engineering that pieced

together such a 󽗉ne piece

of computer hardware.

Product Story

Speci󽗉cations

* In Win products comply with RoHS regulation.

* Speci󽗉cations may vary based on di󽗈erent regions.

* Pre-installed glass panel. Extra fee for closed panel.

Model 305

Color Black, White

Case Type Mid Tower

Case Material Tempered Glass, SECC

M/B Compatibility 12" x 10.7" ATX, Micro-ATX, Mini-ITX

Expansion Slots PCI-E X 7

Maximum

Compatibility

VGA Card Length:350mm

CPU Heatsink Height :160mm

Front Ports

2 x USB 3.0

2 x USB 2.0

HD Audio

Internal Drive Bays 2 x 3.5"

2 x 2.5" Pre-installed (Max. up to 3 bays)

Thermal Solution

Compatibility

1 x 120mm Rear Fan / 120mm Radiator

3 x 120mm Top Fan / 360mm Radiator

3 x 120mm Bottom Fan

Power Supply

Compatibility

PSII: ATX12V

-Length: 200mm Maximum

Product Dimension

(H x W x D)

500mm x 248mm x 484mm

19.6" x 9.7" x 19"

500mm x 248mm x 485mm

19.6" x 9.7" x 19"

Package Dimension

(H x W x D)

335mm x 610mm x 572mm

13.1" x 24" x 22.5"

Net Weight 11.53kg / 25lb

Gross Weight 13.42kg / 29lb

305 Chassis

QR Code Card

Accessories Bag

Motherboard Stand-o󽗈 x 7

Motherboard Stand-o󽗈 Socket x 1

Hexagon Head Screws x 18

2.5" HDD Screws x 18

3.5" HDD Screws x 10

Cable Tie x 10

Water-cooling System Washer x 8

Graphics Card Holder x 1

Package Content

d e g

b c

Case Structure

Power Button

USB 3.0 Ports

USB 2.0 Ports

Audio Ports

(Earphone and Microphone)

HDD/Power

LED Indicator

Power Supply Mounting Area

3.5” Drive Bay

2.5" Drive Bay

Top Fan/ Radiator Mounting Area

Rear Fan/ Radiator Mounting Area

Bottom Fan Mounting Area

Motherboard Mounting Area

CPU Cooler Installation Cut-Out Hole

PCI-E Expansion Slot

Extra PCI-E Supporting Mounting Hole

Fan Dust Filter

Shock-Proof Stand

Case Structure

Opening the Chassis

For Tempered Glass side panel,

please remove by pressing the

handle on top of panel.

Power Supply

Installation

Parts Required:

Hexagon Head Screw.

Power supply can be

mounted on the top

bracket.

Motherboard

Installation

Parts Required:

Motherboard Stand-

Off, Motherboard Stand-

Off Socket, Hexagon Head

Screws

Installation Guide

(Please follow the related chapters to assemble)

Expansion Card Installation

Parts Required: Hexagon Head Screws,

Graphics Card Holder

Installation Guide

(Please follow the related chapters to assemble)

PORT2_2 Blue 10

SENSE_SEND Purple 8

PORT2_R Yellow 6

PORT1_R White 4

PORT1_L Red 2

9 Brown SENCE2_R

7 Key

5 Green SENSE1_R

3 Orange PRESENCE#

1 Black GND

HD AUDIO

I/O Wires Installation

USB3.0 Header

USB2.0 Header

HD Audio Header

POWER LED

(Depend On Motherboard)

POWER SW H.D.D LED

Installation Guide

(Please follow the related chapters to assemble)
