DV1201A & DV1221A

Seismic Detectors Installation Manual

Figure 2: Two ways to test the seismic detectors

1/2. 12 Vdc 7. Common (C)

3. LED indication 8/9. Tamper

4. Integrator level 10. Test control

5. Normaly Closed (NC) 11. Spare

6. Normaly Open (NO)

Test disabled (ex-factory setting)

Internal test of detector’s electronics =

Position jumper between 1 and 2 .

Function test of the detector and its physical contact

with the protected object = Position connector from

test transmitter DV1215A between 2 and 3.



Connecting terminal 10 to 0 V activates both tests.

1. Cover

2. Cover screw

3. Base plate

4. Mounting holes

5. Clamp

6. Area for mounting the

DV1215A test transmitter

7. Potentiometer for adjusting

the detector’s sensitivity

8. Connection block

9. Anti-tamper micro-switch

10. Mounting plate DV1202A

11. Fixing bolt

12. Expander bolt

13. Test transmitter DV1215A

Figure 3: General characteristics of the DV1201A / DV1221A

Using the mounting plate DV1202A as a template

A. Holes for DV1201A / DV1221A

B. Hole for expansion plug or recess mounting box

C. Template and mounting holes for test transmitter DV1215A

D. Holes for accessories.

Figure 4: Mounting the detector directly on a metal surface without using a mounting plate

Figure 1: Wiring diagram

Sentrol

24-04-'02

Manual DV1201A / DV1221A 14 999-

5620

Form: Letter (bookshape)

Formaat: Letter (boekvorm)

G. Manders

110-01

White paper: 70gr/m² progresso; overprint black. If P.O.D.: use 80gr/m².

Wit papier: 70gr/m² progresso; opdruk zwart. Wanneer P.O.D.: gebruik 80gr/m². 1 A 24-04-'02 10423-10424

- 1 -

DV1201A & DV1221A

Seismic Detectors Installation Manual

Figure 2: Two ways to test the seismic detectors

1/2. 12 VDC 7. Common (C)

3. LED indication 8/9. Tamper

4. Integrator level 10. Test control

5. Normaly Closed (NC) 11. Spare

6. Normaly Open (NO)

!Test disabled (ex-factory setting)

"Internal test of detector’s electronics =

Position jumper between 1 and 2 .

#Function test of the detector and its physical contact

with the protected object = Position connector from

test transmitter DV1215A between 2 and 3.

Connecting terminal 10 to 0 V activates both tests.

1. Cover

2. Cover screw

3. Base plate

4. Mounting holes

5. Clamp

6. Area for mounting the

DV1215A test transmitter

7. Potentiometer for adjusting

the detector’s sensitivity

8. Connection block

9. Anti-tamper micro-switch

10. Mounting plate DV1202A

11. Fixing bolt

12. Expander bolt

13. Test transmitter DV1215A

Figure 3: General characteristics of the DV1201A / DV1221A

Using the mounting plate DV1202A as a template

A. Holes for DV1201A / DV1221A

B. Hole for expansion plug or recess mounting box

C. Template and mounting holes for test transmitter DV1215A

D. Holes for accessories.

Figure 4: Mounting the detector directly on a metal surface without using a mounting plate

Figure 1: Wiring diagram

Sentrol

- 2 -

Figure 5: Mounting on concrete

Always use a DV1202A mounting plate. The expansion plug must

penetrate at least 50 mm into the concrete. Please follow the steps

shownin Figure 6 ifyouareinstallingthetest transmitter DV1215A.

For the equipment to conform to CEI standard 79-2, the

DV1215A test transmitter must be installed.

Figure 6: Control and function test

Usingavoltmeter,checkthe background signal levelinthedetector

to prevent nuisance alarms. Set the sensitivity to Gmax during the

test.

DV1201A DV1221A Measure

0.7 V 0 V None

1.4 V 2 V Reduce range/remove source

Try to remove the source of ambient noise instead of

reducing the range.

Functional testing with hand tester DV1230 !and mechanical

tool ":

DV1201A DV1221A

Alarm in 30 sec. Alarm in 45 sec.

Alarm after 5 blows NA

Detection range (in foot): Technical specifications:

Input power: 9-15 VDC

2 V max. ripple pp

Current consumption: Nom. 8.6 mA

Alarm output: Form C solid state relay, max. series

resistance 35 Ohm

Alarm indication: LED-ind. output 3

Sensitivity: 5 steps of 6 dB each

Range: See Table “Detection range”

Sabotage protection: Temp. 183.2 °F

drill shield,

opening/pry-off contact,

Low voltage alarm: 7.5 V

Temperature limits: -4 °F to + 131 °F

Dimensions: 3.93 x 3.15 x 1.30 inches

Colour: Grey, RAL 7035

Weight: 0.86 lb

Concrete 13.12 45.93 45.93

Steel 1/Gmax 26.25 45.93 45.93

Brick 9.84 26.25 26.25

Concrete 9.84 29.53 29.53

Steel 2/Gref 13.12 29.53 29.53

Brick 3.28 19.69 19.69

Concrete 6.56 19.69 19.69

Steel 3/Gmin 6.56 19.69 19.69

Brick - 13.12 13.12

Concrete 3.28 16.40 16.40

Steel 4 3.28 16.40 16.40

Brick - 9.84 9.84

Concrete - 13.12 13.12

Steel 5 - 13.12 13.12

Brick - 6.56 6.56

Sensitivity

setting

Material Thermal

lance Diamond

disk Drilling

- 3 -

Figure 7: Wiring the DV1201A/DV1221A into Most Security Systems

Figure 8: Connecting the DV1201A to a Four-wire Circuit

Type Control in an UL Complete Mercantile Safe System Figure 9: Connecting the DV1201A to a Two-wire Balanced

Loop Type Control in an UL Complete Mercantile Safe

System

Figure 10: Wire Diagram DV1208A

Figure 11
