QED –PL2 OWNERS

MANUAL

Proudly made in Ballarat, Victoria, Australia

QED image is for illustration purposes only

QED–PL2 INTRODUCTION

Congratulations on your purchase of the QED-PL2 Pulse Induction metal

detector. The QED has been engineered specifically to make your

prospecting experience more rewarding.

Whenever you purchase any new technology, there is no point in just

looking at it, or putting it away in the wardrobe. You need to explore

all the new functions and settings to maximize your understanding and

the potential of the device.

If you are an experienced operator, you may find the settings to be

different to anything you have previously used. Whether you are a first

timer or an experienced operator, your confidence will develop as you

master the QED.

Read these instructions carefully to master the QED’s full potential. Be

confident to alter and adjust your settings over known targets until you

have a working understanding of the detector’s potential and character.

This detector has an expansive range of possible settings, and as you

become familiar with all the functions you will maximize your potential

to find gold or relics in even the harshest ground.

Happy hunting

CHANGE CONTROL

Date Revised

Version

Nov 2018

QED –PL2 OWNERS MANUAL V 2.0

Dec 2018

QED –PL2 OWNERS MANUAL V 3.0

Dec 2018

QED –PL2 OWNERS MANUAL V 4.0

Jan 2019

QED –PL2 OWNERS MANUAL V 5.0

Jan 2019

QED –PL2 OWNERS MANUAL V 6.0

TABLE OF CONTENTS

QED–PL2 INTRODUCTION ............................................................................ 2

CHANGE CONTROL ................................................................................................. 3

TABLE OF CONTENTS .............................................................................................. 3

NAVIGATING THE CONTROL INTERFACE ................................................................ 6

START UP ................................................................................................................ 7

MENU OPTIONS...................................................................................................... 8

FACTORY DEFAULTS................................................................................................ 8

QUICK START GUIDE............................................................................................... 9

CONTROL COMMANDS......................................................................................... 10

MENU CONTROLS................................................................................................. 11

1: MANUAL GND BAL (MGB) ........................................................................... 11

Description ................................................................................................... 11

YouTube Reference.................................................................................. 12

Unable to Ground Balance........................................................................... 12

Rechecking Ground Balance whilst detecting............................................. 12

YouTube Reference.................................................................................. 12

Notes ............................................................................................................ 12

ADVANCED GND BAL (MGB) TECHNIQUE ....................................................... 13

Description ................................................................................................... 13

Notes ............................................................................................................ 13

AUTO GND BAL (AGB)...................................................................................... 14

Description ................................................................................................... 14

4
YouTube Reference...................................................................................... 14
Notes ............................................................................................................ 14
2. THRESHOLD B –(THS-B) (BIAS).................................................................... 15
Description ................................................................................................... 15
Navigating to Threshold B ........................................................................... 16
YouTube Reference.................................................................................. 16
Threshold B Neutral Position....................................................................... 16
YouTube Reference.................................................................................. 16
Small Search Coils ........................................................................................ 17
Medium Search Coils ................................................................................... 17
Large Search Coils ........................................................................................ 17
Notes ............................................................................................................ 18
3: THRESHOLD A –(THS-A) (VOLUME) ............................................................ 19
Description ................................................................................................... 19
Adjusting ...................................................................................................... 19
Threshold A .................................................................................................. 19
YouTube Reference...................................................................................... 19
Notes ............................................................................................................ 19
4: GAIN ............................................................................................................. 20
Description ................................................................................................... 20
Adjusting Gain.............................................................................................. 20
YouTube Reference...................................................................................... 20
Notes ............................................................................................................ 20
5: MODE ........................................................................................................... 21
Description ................................................................................................... 21
Beach Mode ................................................................................................. 21
Adjusting Mode............................................................................................ 22
Youtube Reference ...................................................................................... 22
Notes ............................................................................................................ 22
6: SMF (STATIC MAGNETIC FIELDS) ................................................................. 23
Description ................................................................................................... 23
Adjusting SMF .............................................................................................. 23
YouTube Reference...................................................................................... 23
Notes ............................................................................................................ 23
7: BATTERY ....................................................................................................... 24
Description ................................................................................................... 24

5
Lithium (li ion) Battery Care ........................................................................ 24
Notes ............................................................................................................ 24
8: PITCH ............................................................................................................ 25
Description ................................................................................................... 25
Adjusting Pitch ............................................................................................. 25
YouTube Reference...................................................................................... 25
Notes ............................................................................................................ 25
9: SMR (SYNCHRONOUS MAINS REJECTION).................................................. 26
Description ................................................................................................... 26
YouTube Reference...................................................................................... 26
Notes ............................................................................................................ 26
FERRITE EMI SUPPRESSORS.................................................................................. 27
SEARCH COIL TYPES .............................................................................................. 27
ADVANCED SETUP GUIDE..................................................................................... 28
HOW TO SEARCH THE GROUND........................................................................... 29
FINE TUNING EXERCISE......................................................................................... 30
ADDITIONAL INSTRUCTIONAL VIDEOS ................................................................. 31
Effects of adjusting Gain, Threshold A and Threshold B ................................ 31
Effects of adjusting Threshold B for selected target size ............................... 31
TECHNICAL SPECIFICATIONS................................................................................. 32
MANUFACTURER’S WARRANTY ........................................................................... 33
NOTES................................................................................................................... 34






NAVIGATING THE CONTROL INTERFACE

The button Triangle image on the control box is the TURN ON BUTTON and INCREASE

ADJUSTMENT button.

The button Triangle image on the control box is the DECREASE ADJUSTMENT button.

Use the button to TOGGLE between menu Item Select and Menu Item Adjustment.

Press and hold the button to TURN OFF the detector.

Click on this YouTube link to view an explanation of the QED Control Panel functions.

The display is an all

lighting conditions

3-digit LED backlit

LCD display.

START UP

Note: As the QED is marketed in various configurations, these steps are indicative only.

Step 1

Connect a suitable coil.

Step 2

Insert Batteries or connect Battery Pack

Step 3

Turn Detector ON by pressing the BUTTON.

Turn ON the remote SPEAKER pressing the button at side of the speaker housing.

Step 4

Scroll through adjustment menu item numbers by pressing either buttons.

When on the required adjustment menu item number press the button

Step 5

INCREASE variable using or DECREASE using

Step 6

To return to variable menu press the button.

Step 7

To turn detector OFF, press and hold the button and current adjustment settings will be

saved.

Step 8

To reload Factory Default Settings, turn the detector OFF, then PRESS and HOLD

the button while pressing the button.

MENU OPTIONS

1: Manual Ground Balance

2: Threshold B (Bias)

3: Threshold A (Volume)

4: Gain

5: Mode

6: Static Magnetic Fields (SMF)

7: Battery

8: Pitch

9: Synchronous Mains Rejection (SMR)

FACTORY DEFAULTS

Setting

Range

Factory

Default

Manual Ground Balance

1 - 200

100

Threshold B (Bias)

1 –99

Threshold A (Volume)

1 –90

Gain

1 –10

Mode

Gold Detecting in

Mineralised Ground

1 –15

Beach Mode

Static Magnetic Fields (SMF)

1 –100

Battery

Displays:

~5.98v –9.99v

Pitch

1 –50

Synchronous Mains Rejection (SMR)

1 –200

107

QUICK START GUIDE

For people new to the QED, use the following Quick Start Guide to start detecting as quickly

as possible without having to understand all of the available settings and when/why to use

them.

When you feel confident in using the QED and wish to adjust the various QED settings

based on coil size, ground conditions, and target type (small; all; large) to name a few, then

refer to the Advanced Setup Guide.

Step

Description

Turn the detector ON by performing a Factory

Reset

Mode

Factory Default (3)

Ground Balance

•MGB, or

•AGB

THS B

Factory Default (50)

THS A

Start at Factory Default (30) and increase until

a (slight) threshold is heard

GAIN

Start at Factory Default (1) and increase GAIN

as high as prevailing EMI conditions and

Ground Type will allow.

Re-Ground Balance

•MGB, or

•AGB

Notes

Tip:

Once you have adjusted the detector to suit, leave the detector in the MGB adjustment

setting so that you can quickly adjust the GB whilst you are detecting.

CONTROL COMMANDS

TURN THE DETECTOR ON

Ensure the battery power lead is connected to the lead socket on

the control box

PRESS the once to turn the detector on.

Click on this YouTube link to see how to turn the QED on.

Note: The detector serial Number appears on the screen for a fraction of

a second after switch on

CYCLE THROUGH MAIN

MENU OPTIONS

PRESS either the Button or the button to toggle through the

Main Menu options (1-9)

TOGGLE BETWEEN A MENU

ITEM NUMBER OR ADJUST

VARIABLE

Pressing the button toggles between displaying the menu

item number or a variable adjustment.

Note:

•A single digit is the menu item number

•Three digits indicates variable adjust mode

Click on this YouTube link to view an explanation of the QED

Control Panel functions.

INCREASE OR DECREASE A

VARIABLE (e.g. GRD BAL)

Press the button to increase a variable number

Press the button to decrease a variable number

TURN THE DETECTOR OFF

PRESS and HOLD the button for three seconds

Click on this YouTube link to see how to turn the QED off.

FACTORY RESET

Note: The factory reset can only be performed with the detector switched

OFF

PRESS and HOLD the button, then press the button for 2

seconds, then release the button.

Click on this YouTube link to see how to perform a Factory reset

Tip:

Before doing a Factory Default

Reset (FDR) set the MGB to

anything but 100 before the

detector is turned off.

Once the detector has been

reset, if MGB is 100 then the

FDR has been done correctly.

Tip:

To quickly get back to the MGB

adjustment screen from any

setting, push the AGB button

momentarily.

Autres manuels pour QED-PL2

Table des matières

Autres manuels Interfacion Détecteur de métaux

Interfacion

Interfacion QED-PL2 Manuel utilisateur

Interfacion

Interfacion QED Manuel utilisateur

Manuels Détecteur de métaux populaires d'autres marques

Garrett

Garrett MAGNASCANNER CS 5000 Manuel utilisateur

Valex

Valex 1800200 Manuel utilisateur

Gauss

Gauss MIL MD Manuel utilisateur

Velleman

Velleman CS130 Manuel utilisateur

Sears

Sears 321.596370 Manuel utilisateur

Eriez

Eriez X8 Manuel utilisateur

Steinberg Systems

Steinberg Systems SBS-MD-22 Manuel utilisateur

Zircon

Zircon MetalliScanner m60c Manuel utilisateur

nalanda

nalanda MD027 Manuel utilisateur

REV Ritter

REV Ritter CB-7005 Manuel utilisateur

Minelab

Minelab F1A4 Manuel utilisateur

Fisher Research Labs

Fisher Research Labs F70 Manuel utilisateur

Steinberg Systems

Steinberg Systems SBS-MD-12 Manuel utilisateur

GOLDEN MASK

GOLDEN MASK 5 Manuel utilisateur

Grizzly

Grizzly YM 203 Manuel utilisateur

Fisher Research Labs

Fisher Research Labs 1280-X Aquanaut Manuel utilisateur

Treasure Cove

Treasure Cove Vibra-Probe 560 Manuel utilisateur

Accurate Locators

Accurate Locators XL16 IMAGER Manuel utilisateur
