Interacoustics AC40 Manuel utilisateur

Clinical Audiometer AC40

Part number 8100837 Rev. 2

Valid from 10/2013

Service Manual

AC40 Service Manual Page 2

Contents

Contents 1

General information 2

Survey of reference and max hearing level Tone Audiometer 3

ANSI Free Field 7

IEC Free Field 7

Survey of reference and max hearing level Speech Audiometer 8

Swedish Speech calibration 10

Norwegian Speech Calibration 11

Equivalent free field 12

General properties for earphones 12

Accessories and Parts 14

Accessories 14

Consumables and Parts 17

Schematics 19

Block Diagram 19

Disassembly 20

Open the Cabinet 20

Remove the PCA Back Board and Side Board 21

Remove the Power Supply 22

Remove the Display 23

Adjusting the knobs after reassembly – 24

Calibration Procedure 26

Service, adjustment and repair 26

Phasing of headphones 27

Calibration of test equipment 27

Calibration Mode Entering 27

Checklist for calibration 28

Calibration standard for Audiometer 29

Selecting TDH39 headset 30

Selecting DD45 headset 33

Selecting HDA200 headset 36

Selecting HDA280 headset 39

Selecting EAR3A Insert phone 42

Selecting EAR5A Insert phone 45

Selecting CIR22/CIR33 Insert masking transducer 48

Selecting B71 Bone transducer 51

Calibration procedure Free Field and Custom Max 54

Select Free field setup 55

Custom max. 56

Transducer calibration 57

Update procedure - Firmware 58

Installing MHA (Master Hearing Aid) wave files: 58

AC40 Stand Alone Unit, Print Logo Update 58

Appendix A Update News 1

AC40 Service Manual Page 3

General information

Interacoustics continuously strives to improve its products and their performance, therefore the specifications can be

subject to change without notice.

The performance and specifications of the instrument can only be guaranteed if it is subject to technical maintenance

at least once a year. This should be done by a workshop authorized by Interacoustics (refer to calibration procedure on

page 26).

Questions about representatives and products may be sent to:

Interacoustics A/S Phone: +45 63713555

Drejervaenget 8 Fax: +45 63713522

DK 5610 Assens e-mail: [email protected]

Denmark http: www.interacoustics.com

AC40 Service Manual Page 4

Survey of reference and max hearing level Tone Audiometer

ANSI TDH39

Coupler: ANSI S3.7-1995 (NBS-9A) /

IEC 60318-3 1998 (6ccm)

Tone Audiometer

Tone Narrow Band Noise

ANSI S3.6-2010 ANSI S3.6-2010

Frequency RETSPL MaxHL RETSPL MaxHL

125 45.0 90 49.0 75

160

37.5

41.5

200¹31.5 100 35.5 90

250 25.5 110 29.5 95

315¹20.0 115 24.0 100

400¹15.0 120 19.0 105

500 11.5 120 15.5 110

630¹8.5 120 13.5 110

750 8.0 120 13.0 110

800¹7.0 120 12.0 110

1000 7.0 120 13.0 110

1250¹6.5 120 12.5 110

1500 6.5 120 12.5 110

1600¹7.0 120 13.0 110

2000 9.0 120 15.0 110

2500¹9.5 120 15.5 110

3000 10.0 120 16.0 110

3150¹10.0 120 16.0 110

4000 9.5 120 14.5 110

5000¹13.0 120 18.0 110

6000 15.5 120 20.5 110

6300¹15.0 120 20.0 110

8000 13.0 110 18.0 100

WhiteNoise 0.0 120

TEN Noise 25.0 110

¹ The RETSPL is copy from ISO389-1 1998

ANSI HDA 280

Coupler ANSI S3.7-1995 (NBS-9A) /

IEC 60318-3 1998 (6ccm)

Tone Audiometer

Tone Narrow Band Noise

PTB PTB

Frequency RETSPL MaxHL RETSPL MaxHL

125 38.5 105 42.5 75

160¹33.5 110 37.5 80

200¹29.5 115 33.5 85

250 25.0 120 29.0 90

315¹21.0 120 25.0 95

400¹17.0 120 21.0 95

500 13.0 120 17.0 100

630¹10.5 120 15.5 100

750 9.0 120 14.0 105

800¹8.5 120 13.5 105

1000 7.5 120 13.5 105

1250¹8.5 120 14.5 105

1500

9.5

120

15.5

105

1600¹9.0 120 15.0 105

2000 8.0 120 14.0 105

2500¹7.0 120 13.0 105

3000 6.5 120 12.5 105

3150¹7.0 120 13.0 105

4000 9.5 120 14.5 105

5000¹12.0 120 17.0 105

6000 19.0 115 24.0 95

6300¹19.0 115 24.0 95

8000 18.0 105 23.0 90

WhiteNoise 0.0 120

¹ This value is interpolated on Interacoustics

IEC TDH39

Coupler: IEC 60318-3 1998 (6ccm)

Tone Audiometer

Tone Narrow Band Noise

ISO 389-1 1998 ISO 389-4 1994

Frequency RETSPL MaxHL RETSPL MaxHL

125 45.0 90 49.0 75

160 37.5 95 41.5 85

200 31.5 100 35.5 90

250 25.5 110 29.5 95

315 20.0 115 24.0 100

400 15.0 120 19.0 105

500 11.5 120 15.5 110

630 8.5 120 13.5 110

750 7.5 120 12.5 110

800 7.0 120 12.0 110

1000 7.0 120 13.0 110

1250 6.5 120 12.5 110

1500

6.5

120

12.5

110

1600 7.0 120 13.0 110

2000 9.0 120 15.0 110

2500 9.5 120 15.5 110

3000 10.0 120 16.0 110

3150 10.0 120 16.0 110

4000 9.5 120 14.5 110

5000 13.0 120 18.0 110

6000 15.5 120 20.5 110

6300 15.0 120 20.0 110

8000 13.0 110 18.0 100

WhiteNoise 0.0 120

TEN Noise 25.0 110

IEC HDA 280

Coupler IEC 60318-3 1998 (6ccm)

Tone Audiometer

Tone Narrow Band Noise

PTB ISO 389-4 1994

Frequency RETSPL MaxHL RETSPL MaxHL

125 38.5 105 42.5 75

160¹33.5 110 37.5 80

200¹29.5 115 33.5 85

250 25.0 120 29.0 90

315¹21.0 120 25.0 95

400¹17.0 120 21.0 95

500 13.0 120 17.0 100

630¹10.5 120 15.5 100

750 9.0 120 14.0 105

800¹8.5 120 13.5 105

1000 7.5 120 13.5 105

1250¹8.5 120 14.5 105

1500 9.5 120 15.5 105

1600¹9.0 120 15.0 105

2000 8.0 120 14.0 105

2500¹7.0 120 13.0 105

3000 6.5 120 12.5 105

3150¹7.0 120 13.0 105

4000 9.5 120 14.5 105

5000¹12.0 120 17.0 105

6000 19.0 115 24.0 95

6300¹19.0 115 24.0 95

8000 18.0 105 23.0 90

AC40 Service Manual Page 5

WhiteNoise 0.0 120

¹ This value is interpolated on Interacoustics

IEC EAR 3A

Coupler: IEC 60318-5 2006 2ccm

Tone Audiometer

Tone Narrow Band Noise

ISO 389-2 1994 ISO 389-4 1994

Frequency RETSPL MaxH

RETSPL MaxHL

125 26.0 90 30.0 90

160 22.0 95 26.0 95

200 18.0 100 22.0 100

250 14.0 105 18.0 105

315 12.0 105 16.0 105

400 9.0 110 13.0 105

500 5.5 110 9.5 110

630 4.0 115 9.0 110

750 2.0 115 7.0 110

800 1.5 115 6.5 110

1000 0.0 120 6.0 110

1250 2.0 120 8.0 110

1500

2.0

120

8.0

110

1600 2.0 120 8.0 110

2000 3.0 120 9.0 110

2500 5.0 120 11.0 110

3000 3.5 120 9.5 110

3150 4.0 120 10.0 110

4000 5.5 115 10.5 110

5000 5.0 105 10.0 105

6000 2.0 100 7.0 100

6300 2.0 100 7.0 100

8000 0.0 95 5.0 95

WhiteNoise 0.0 110

AC40 Service Manual Page 6

ANSI HDA 200

Coupler: IEC60318-2 with type 1 adaptor

Tone Audiometer

Tone Narrow Band Noise

ANSI S3.6-2010 ANSI S3.6-2010

Frequency RETSPL MaxHL RETSPL 1/3 MaxHL

125 30.5 100 34.5 75

160¹26.0 105 30.0 80

200

105

250 18.0 110 22.0 85

315¹15.5 115 19.5 90

400¹13.5 115 17.5 95

500 11.0 115 15.0 95

630¹ 8.0 120 13.0 95

750 6.0 120 11.0 100

800¹ 6.0 120 11.0 100

1000 5.5 120 11.5 100

1250¹ 6.0 110 12.0 95

1500 5.5 115 11.5 100

1600¹5.5 115 11.5 100

2000 4.5 115 10.5 100

2500¹ 3.0 115 9.0 100

3000 2.5 115 8.5 100

3150¹ 4.0 115 10.0 100

4000 9.5 115 14.5 100

5000¹14.0 105 19.0 95

6000 17.0 105 22.0 90

6300¹17.5 105 22.5 90

8000 17.5 105 22.5 90

9000 19.0 100 24.0 85

10000 22.0 100 27.0 85

11200 23.0 95 28.0 80

12500 27.5 90 32.5 75

14000 35.0 80 40.0 70

16000 56.0 60 61.0 50

18000²83.0 30 88.0 20

20000²105.0 15 110.0 0

WhiteNoise 0.0 115

¹ The RETSPL is copy from ISO389-8 2001.

²numbers have been established and accepted in the industry

ANSI EAR 3A

Coupler: ANSI S3.7-1995 (HA-2 with 5mm rigid Tube)

Tone Audiometer

Tone Narrow Band Noise

ANSI S3.6-2010 ANSI S3.6-2010

Frequency RETSPL MaxHL RETSPL MaxHL

125 26.0 90 30.0 90

160 22.0 95 26.0 95

200 18.0 100 22.0 100

250 14.0 105 18.0 105

315 12.0 105 16.0 105

400 9.0 110 13.0 105

500 5.5 110 9.5 110

630 4.0 115 9.0 110

750 2.0 115 7.0 110

800 1.5 115 6.5 110

1000 0.0 120 6.0 110

1250 2.0 120 8.0 110

1500 2.0 120 8.0 110

1600 2.0 120 8.0 110

2000 3.0 120 9.0 110

2500 5.0 120 11.0 110

3000 3.5 120 9.5 110

3150 4.0 120 10.0 110

4000 5.5 115 10.5 110

5000 5.0 105 10.0 105

6000 2.0 100 7.0 100

6300 2.0 100 7.0 100

8000 0.0 95 5.0 95

WhiteNoise 0.0 110

IEC HDA 200

Coupler: IEC60318-1 with type 1 adaptor

Tone Audiometer

Tone Narrow Band Noise

ISO 389-8 2004ISO 389-4 1994

Frequency RETSPL MaxHL RETSPL 1/3 MaxHL

125 30.5 100 34.5 75

160 26.0 105 30.0 80

200 22.0 105 26.0 80

250 18.0 110 22.0 85

315 15.5 115 19.5 90

400 13.5 115 17.5 95

500 11.0 115 15.0 95

630 8.0 120 13.0 95

750 6.0 120 11.0 100

800

6.0

120

11.0

100

1000 5.5 120 11.5 100

1250 6.0 110 12.0 95

1500 5.5 115 11.5 100

1600 5.5 115 11.5 100

2000 4.5 115 10.5 100

2500 3.0 115 9.0 100

3000 2.5 115 8.5 100

3150 4.0 115 10.0 100

4000 9.5 115 14.5 100

5000 14.0 105 19.095

6000 17.0 105 22.0 90

6300 17.5 105 22.5 90

8000 17.5 105 22.5 90

ISO 389-5 2006ISO 389-5 2006 + 5 dB

8000 17.5 105 22.5 90

9000 19.0 100 24.0 85

10000 22.0 100 27.0 85

11200 23.0 95 28.0 80

12500 27.5 90 32.5 75

14000 35.0 80 40.0 70

16000 56.0 60 61.0 50

18000²83.0 30 88.0 20

20000²105.0 15 110.0 0

WhiteNoise 0.0 115

²numbers have been established and accepted in the industry

AC40 Service Manual Page 7

ANSI Ear 5A

Coupler ANSI S3.7-1995 (HA-2 with 5mm rigid Tube)

Tone Audiometer

Tone Narrow Band Noise

ANSI S3.6-2010 ANSI S3.6-2010

Frequency RETSPL MaxHL RETSPL MaxHL

125 26.0 95 30.0 85

160 22.0 95 26.0 90

200

18.0

100

22.0

250 14.0 100 18.0 100

315 12.0 105 16.0 100

400 9.0 105 13.0 105

500 5.5 110 9.5 110

630 4.0 115 9.0 110

750 2.0 120 7.0 110

800 1.5 120 6.5 110

1000 0.0 120 6.0 110

1250 2.0 120 8.0 110

1500 2.0 120 8.0 110

1600 2.0 120 8.0 110

2000 3.0 120 9.0 110

2500 5.0 120 11.0 110

3000 3.5 120 9.5 110

3150 4.0 120 10.0 110

4000 5.5 120 10.5 110

5000 5.0 110 10.0 110

6000 2.0 105 7.0 105

6300 2.0 105 7.0 105

8000 0.0 100 5.0 100

WhiteNoise 0.0 110

ANSI CIR 22/CIR33

Coupler ANSI S3.7-1995 (HA-2)

Tone Audiometer

Tone Narrow Band Noise

ANSI S3.6-2010 ANSI S3.6-2010

Frequency RETSPL MaxHL RETSPL MaxHL

125 26.0 90 30.0 90

160 22.0 95 26.0 95

200 18.0 100 22.0 100

250 14.0 105 18.0 105

315 12.0 105 16.0 105

400 9.0 110 13.0 105

500 5.5 110 9.5 110

630 4.0 115 9.0 110

750

2.0

115

7.0

110

800 1.5 115 6.5 110

1000 0.0 120 6.0 110

1250 2.0 120 8.0 110

1500 2.0 120 8.0 110

1600 2.0 120 8.0 110

2000 3.0 120 9.0 110

2500 5.0 120 11.0 110

3000 3.5 120 9.5 110

3150 4.0 120 10.0 110

4000 5.5 115 10.5 105

5000 5.0 105 10.0 95

6000 2.0 100 7.0 95

6300 2.0 100 7.0 95

8000 0.0 90 5.0 90

WhiteNoise 0.0 110

IEC Ear 5A

Coupler IEC 60318-5 2006 2ccm

Tone Audiometer

Tone Narrow Band Noise

ISO 389-2 1994 ISO 389-4 1994

Frequency RETSPL MaxHL RETSPL MaxHL

125 26.0 95 30.0 85

160 22.0 95 26.0 90

200 18.0 100 22.0 95

250 14.0 100 18.0 100

315 12.0 105 16.0 100

400 9.0 105 13.0 105

500 5.5 110 9.5 110

630 4.0 115 9.0 110

750 2.0 120 7.0 110

800 1.5 120 6.5 110

1000 0.0 120 6.0 110

1250 2.0 120 8.0 110

1500 2.0 120 8.0 110

1600 2.0 120 8.0 110

2000 3.0 120 9.0 110

2500 5.0 120 11.0 110

3000

3.5

120

9.5

110

3150 4.0 120 10.0 110

4000 5.5 120 10.5 110

5000 5.0 110 10.0 110

6000 2.0 105 7.0 105

6300 2.0 105 7.0 105

8000 0.0 100 5.0 100

WhiteNoise 0.0 110

IEC CIR 22/CIR33

Coupler IEC 60318-5 2006 2ccm

Tone Audiometer

Tone Narrow Band Noise

ISO 389-2 1994 ISO 389-4 1994

Frequency RETSPL MaxHL RETSPL MaxHL

125 26.0 90 30.0 90

160 22.0 95 26.0 95

200 18.0 100 22.0 100

250 14.0 105 18.0 105

315 12.0 105 16.0 105

400 9.0 110 13.0 105

500 5.5 110 9.5 110

630 4.0 115 9.0 110

750 2.0 115 7.0 110

800 1.5 115 6.5 110

1000 0.0 120 6.0 110

1250 2.0 120 8.0 110

1500 2.0 120 8.0 110

1600 2.0 120 8.0 110

2000 3.0 120 9.0 110

2500 5.0 120 11.0 110

3000 3.5 120 9.5 110

3150 4.0 120 10.0 110

4000 5.5 115 10.5 105

5000 5.0 105 10.0 95

6000 2.0 100 7.0 95

6300 2.0 100 7.0 95

8000

0.0

5.0

WhiteNoise0.0 110

AC40 Service Manual Page 8

ANSI B71

Coupler ANSI S3.13

Tone Audiometer

Tone Narrow Band Noise

ANSI S3.6 -2010 ANSI S3.6 - 2010

Frequency RETSPL MaxHL RETSPL MaxHL

125 - - - -

160 - - - -

200

250 67.0 45 71.0 35

315 64.0 50 68.0 40

400 61.0 65 65.0 55

500 58.0 65 62.0 55

630 52.5 70 57.5 60

750 48.5 70 53.5 60

800 47.0 70 52.0 60

1000 42.5 70 48.5 60

1250 39.0 70 45.0 60

1500 36.5 70 42.5 60

1600 35.5 70 41.5 60

2000 31.0 75 37.0 65

2500 29.5 80 35.5 65

3000 30.0 80 36.0 65

3150 31.0 80 37.0 65

4000 35.5 80 40.5 65

5000 40.0 60 45.0 50

6000 40.0 50 45.0 45

6300 40.0 50 45.0 40

8000 40.0 50 45.0 40

WhiteNoise 42.5 70

ANSI DD45

Coupler: IEC 60318-3 1998 (6ccm)

Tone Audiometer

Tone Narrow Band Noise

PTB – DTU 2010 ISO 389-4 1994

Frequency RETSPL MaxHL RETSPL MaxHL

125 47.5 90 51.5 75

160¹40.5 95 44.5 80

200¹33.5 100 37.5 90

250 27.0 110 31.0 95

315¹22.5 115 26.5 100

400¹17.5 120 21.5 105

500 13.0 120 17.0 110

630¹9.0 120 14.0 110

750 6.5 120 11.5 110

800¹6.5 120 11.5 110

1000 6.0 120 12.0 110

1250¹ 7.0 120 13.0 110

1500 8.0 120 14.0 110

1600¹ 8.0 120 14.0 110

2000 8.0 120 14.0 110

2500¹ 8.0 120 14.0 110

3000 8.0 120 14.0 110

3150¹ 8.0 120 14.0 110

4000 9.0 120 14.0 110

5000¹13.0 120 18.0 110

6000 20.5 115 25.5 105

6300¹19.0 115 24.0 105

8000 12.0 110 17.0 100

WhiteNoise 0120

TEN Noise 25.0 110

¹ This value is interpolated on Interacoustics

IEC B71

Coupler 60318-6 2007

Tone Audiometer

Tone Narrow Band Noise

ISO 389-3 1994 ISO 389-4 1994

Frequency RETSPL MaxHL RETSPL MaxHL

125 - - - -

160 - - - -

200 - - - -

250 67.0 45 71.0 35

315 64.0 50 68.0 40

400 61.0 65 65.0 55

500 58.0 65 62.0 55

630 52.5 70 57.5 60

750 48.5 70 53.5 60

800

47.0

52.0

1000 42.5 70 48.5 60

1250 39.0 70 45.0 60

1500 36.5 70 42.5 60

1600 35.5 70 41.5 60

2000 31.0 75 37.0 65

2500 29.5 80 35.5 65

3000 30.0 80 36.0 65

3150 31.0 80 37.0 65

4000 35.5 80 40.5 65

5000 40.0 60 45.0 50

6000 40.0 50 45.0 45

6300 40.0 50 45.0 40

8000 40.0 50 45.0 40

WhiteNoise 42.5 70

IEC DD45

Coupler: IEC 60318-3 1998 (6ccm)

Tone Audiometer

Tone Narrow Band Noise

PTB – DTU 2010 ISO 389-4 1994

Frequency RETSPL MaxHL RETSPL MaxHL

125 47.5 90 51.5 75

160¹40.5 95 44.5 80

200¹33.5 100 37.5 90

250 27.0 110 31.0 95

315¹22.5 115 26.5 100

400¹17.5 120 21.5 105

500 13.0 120 17.0 110

630¹9.0 120 14.0 110

750 6.5 120 11.5 110

800¹6.5 120 11.5 110

1000 6.0 120 12.0 110

1250¹ 7.0 120 13.0 110

1500 8.0 120 14.0 110

1600¹ 8.0 120 14.0 110

2000 8.0 120 14.0 110

2500¹ 8.0 120 14.0 110

3000 8.0 120 14.0 110

3150¹ 8.0 120 14.0 110

4000 9.0 120 14.0 110

5000¹ 13.0 120 18.0 110

6000 20.5 115 25.5 105

6300¹19.0 115 24.0 105

8000 12.0 110 17.0 100

WhiteNoise 0120

TEN Noise 25.0 110

¹ This value is interpolated on Interacoustics

AC40 Service Manual Page 9

ANSI Free Field

ANSI S3.6-2010 Free Field max SPL

Free Field max HL is found by subtracting the selected RETSPL value

Binaural Monaural Free Field Power Free Field Line

0° 45° 90° 0° 45° 90° Tone NB Tone NB

Frequency RETSPL RETSPL RETSPL RETSPL RETSPL RETSPL Max SPL Max SPL Max SPL Max SPL

125

22.0

21.5

21.0

24.0

23.5

23.0

102

160 18.0 17.0 16.5 20.0 19.0 18.5 93 83 98 93

200 14.5 13.5 13.0 16.5 15.5 15.0 94.5 84.5 104.5 99.5

250 11.5 10.5 9.5 13.5 12.5 11.5 96.5 86.5 106.5 101.5

315 8.5 7.0 6.0 10.5 9.0 8.0 93.5 83.5 103.5 98.5

400 6.0 3.5 2.5 8.0 5.5 4.5 96 86 106 101

500 4.5 1.5 0.0 6.5 3.5 2.0 94.5 84.5 104.5 99.5

630 3.0 -0.5 -2.0 5.0 1.5 0.0 93 83 103 98

750 2.5 -1.0 -2.5 4.5 1.0 -0.5 92.5 82.5 102.5 97.5

800 2.0 -1.5 -3.0 4.0 0.5 -1.0 92 87 107 102

1000 2.5 -1.5 -3.0 4.5 0.5 -1.0 92.5 82.5 102.5 97.5

1250 3.5 -0.5 -2.5 5.5 1.5 -0.5 93.5 83.5 103.5 98.5

1500 2.5 -1.0 -2.5 4.5 1.0 -0.5 92.5 82.5 102.5 97.5

1600 1.5 -2.0 -3.0 3.5 0.0 -1.0 96.5 86.5 106.5 101.5

2000 -1.5 -4.5 -3.5 0.5 -2.5 -1.5 93.5 83.5 103.5 98.5

2500 -4.0 -7.5 -6.0 -2.0 -5.5 -4.0 91 81 101 96

3000 -6.0 -11.0 -8.5 -4.0 -9.0 -6.5 94 84 104 94

3150 -6.0 -11.0 -8.0 -4.0 -9.0 -6.0 94 84 104 94

4000 -5.5 -9.5 -5.0 -3.5 -7.5 -3.0 94.5 84.5 104.5 99.5

5000 -1.5 -7.5 -5.5 0.5 -5.5 -3.5 93.5 83.5 108.5 98.5

6000 4.5 -3.0 -5.0 6.5 -1.0 -3.0 94.5 84.5 104.5 99.5

6300 6.0 -1.5 -4.0 8.0 0.5 -2.0 96 86 106 96

8000 12.5 7.0 4.0 14.5 9.0 6.0 87.5 72.5 92.5 87.5

WhiteNoise 0.0 0.0 0.0 0.0 0.0 0.0 90 100

IEC Free Field

ISO 389-7 2005 Free Field max SPL

Free Field max HL is found by subtracting the selected RETSPL value

Binaural Monaural Free Field Power Free Field Line

0° 45° 90° 0° 45°90°Tone NB Tone NB

Frequency RETSPL RETSPL RETSPL RETSPL RETSPL RETSPL Max SPL Max SPL Max SPL Max SPL

125 22.0 21.5 21.0 24.0 23.5 23.0 97 82 102 97

160 18.0 17.0 16.5 20.0 19.0 18.5 93 83 98 93

200 14.5 13.5 13.0 16.5 15.5 15.0 94.5 84.5 104.5 99.5

250 11.5 10.5 9.5 13.5 12.5 11.5 96.5 86.5 106.5 101.5

315 8.5 7.0 6.0 10.5 9.0 8.0 93.5 83.5 103.5 98.5

400 6.0 3.5 2.5 8.0 5.5 4.5 96 86 106 101

500 4.5 1.5 0.0 6.5 3.5 2.0 94.5 84.5 104.5 99.5

630 3.0 -0.5 -2.0 5.0 1.5 0.0 93 83 103 98

750 2.5 -1.0 -2.5 4.5 1.0 -0.5 92.5 82.5 102.5 97.5

800 2.0 -1.5 -3.0 4.0 0.5 -1.0 92 87 107 102

1000 2.5 -1.5 -3.0 4.5 0.5 -1.0 92.5 82.5 102.5 97.5

1250 3.5 -0.5 -2.5 5.5 1.5 -0.5 93.5 83.5 103.5 98.5

1500 2.5 -1.0 -2.5 4.5 1.0 -0.5 92.5 82.5 102.5 97.5

1600 1.5 -2.0 -3.0 3.5 0.0 -1.0 96.5 86.5 106.5 101.5

2000 -1.5 -4.5 -3.5 0.5 -2.5 -1.5 93.5 83.5 103.5 98.5

2500 -4.0 -7.5 -6.0 -2.0 -5.5 -4.0 91 81 101 96

3000 -6.0 -11.0 -8.5 -4.0 -9.0 -6.5 94 84 104 94

3150 -6.0 -11.0 -8.0 -4.0 -9.0 -6.0 94 84 104 94

4000 -5.5 -9.5 -5.0 -3.5 -7.5 -3.0 94.5 84.5 104.5 99.5

5000 -1.5 -7.5 -5.5 0.5 -5.5 -3.5 93.5 83.5 108.5 98.5

6000 4.5 -3.0 -5.0 6.5 -1.0 -3.0 94.5 84.5 104.5 99.5

6300 6.0 -1.5 -4.0 8.0 0.5 -2.0 96 86 106 96

8000 12.5 7.0 4.0 14.5 9.0 6.0 87.5 72.5 92.5 87.5

WhiteNoise 0.0 0.0 0.0 0.0 0.0 0.0 90 100

¹The Binaural to Monaural correction on +2dB come from ANSI S3.6 -2004

The difference between 0° - 45° - 90° come from ISO 8253-2 1998.

The maximum free field levels depend on the amplifier, speaker and the acoustic conditions of the room. The actual maximum levels are found

using the Custom Max function in the calibration software.

AC40 Service Manual Page 10

Survey of reference and max hearing level Speech Audiometer

ANSI Speech

ANSI TDH39

Coupler: ANSI S3.7-1995 (NBS-9A) / IEC 60318-3 1998 (6ccm)

Speech Audiometer

Speech Speech Noise

ANSI S3.6-2010 ANSI S3.6-2010

RETSPL MaxHL RETSPL MaxHL

Linear Type A 19.5 110 19.5 100

Equ. FF Type A-E 15.5105 15.5100

Not Linear¹7.0 120 7.0 115

Speech WN22.0 95

ANSI HDA 280

Coupler: ANSI S3.7-1995 (NBS-9A) / IEC 60318-3 1998 (6ccm)

Speech Audiometer

Speech Speech Noise

RETSPL MaxHL RETSPL MaxHL

Linear Type A 20.0 100 20.0 95

Equ. FF Type A-E 21.595 21.590

Not Linear¹7.5 120 7.5 120

Speech WN 22.5 95

ANSI HDA 200

Coupler: IEC60318-2 with type 1 adaptor

Speech Audiometer

Speech Speech Noise

ANSI S3.6-2010 ANSI S3.6-2010

Frequency RETSPL MaxHL RETSPL MaxHL

Linear Type A 19.0 90 19.0 85

Equ. FF Type A-E 18.5 85 18.5 80

Not Linear¹ 5.5 110 5.5 105

Speech WN21.5 90

ANSI DD45

Coupler: ANSI S3.7-1995 (NBS-9A) / IEC 60318-3 1998 (6ccm)

Speech Audiometer

Speech Speech Noise

ANSI S3.6-2010 ANSI S3.6-2010

RETSPL MaxHL RETSPL MaxHL

Linear Type A 18.5 110 18.5 100

Equ. FF Type A-E 18.5 100 18.5 100

Not Linear¹ 6.0 120 6.0 115

Speech WN21.0 95

¹ This value come from pure tone 1kHz RETSPL value. (Not linear describe

there is no equalizing of the signal flat electrical response)

ANSI Ear 3A

Coupler: ANSI S3.7-1995 (HA-2 with 5mm rigid Tube)

Speech Audiometer

Speech Speech Noise

ANSI S3.6-2010 ANSI S3.6-2010

RETSPL MaxHL RETSPL MaxHL

Speech 12.5 110 12.5 100

Speech WN 15.0 95

ANSI Ear 5A

Coupler: IEC 60318-5 2006

Speech Audiometer

Speech Speech Noise

ANSI S3.6-2010 ANSI S3.6-2010

RETSPL MaxHL RETSPL MaxHL

Speech 12.5 110 12.5 100

Speech WN 15.0 95

ANSI CIR 22/CIR33

Coupler: ANSI S3.7-1995 (HA-2)

Speech Audiometer

Speech Speech Noise

ANSI S3.6-2010 ANSI S3.6-2010

RETSPL MaxHL RETSPL MaxHL

Speech 12.5 100 12.5 100

Speech WN 15.0 95

ANSI B71

Coupler: ANSI S3.13-1987 (R2002)

Speech Audiometer

Speech Speech Noise

ANSI S3.6-2010 ANSI S3.6-2010

RETSPL MaxHL RETSPL MaxHL

Speech 55.0 60 55.0 50

Speech WN 57.5 55

ANSI Free Field

ANSI S3.6-2010 Free Field max SPL

Free Field max HL is found by subtracting the

selected RETSPL value

Binaural Monaural Free Field Power Free Field Line

0° 45° 90° 0° 45° 90° 0° - 45° - 90° 0° - 45° - 90°

RETSPL RETSPL RETSPL RETSPL RETSPL RETSPL Max SPL Max SPL

Speech 15.0 11.0 9.5 17.0 13.0 11.590 100

Speech Noise 15.0 11.0 9.5 17.0 13.0 11.585 100

Speech WN17.5 13.5 12.0 19.5 15.5 14.0 87.5 97.5

Autres manuels pour AC40

Table des matières

Autres manuels Interacoustics Instrument de mesure

Interacoustics

Interacoustics ad226 Manuel utilisateur

Interacoustics

Interacoustics Callisto Manuel utilisateur

Interacoustics

Interacoustics ad226 Manuel utilisateur

Interacoustics

Interacoustics Affinity2.0 Manuel utilisateur

Interacoustics

Interacoustics AA222 Manuel d'installation

Interacoustics

Interacoustics AC40 Manuel utilisateur

Interacoustics

Interacoustics Luna Manuel utilisateur

Interacoustics

Interacoustics AD629 Manuel utilisateur

Interacoustics

Interacoustics PA5 Manuel utilisateur

Interacoustics

Interacoustics Titan Manuel utilisateur

Interacoustics

Interacoustics AT235 Manuel utilisateur

Interacoustics

Interacoustics AS608 Manuel utilisateur

Interacoustics

Interacoustics AC40 Manuel utilisateur

Interacoustics

Interacoustics Callisto Manuel utilisateur

Interacoustics

Interacoustics AT235 Manuel utilisateur

Interacoustics

Interacoustics AC40 Manuel utilisateur

Interacoustics

Interacoustics ad226 Manuel utilisateur

Interacoustics

Interacoustics AD629 Manuel utilisateur

Interacoustics

Interacoustics AC40 Manuel utilisateur

Interacoustics

Interacoustics AT235 Manuel utilisateur

Interacoustics

Interacoustics AD629 Manuel utilisateur

Interacoustics

Interacoustics Luna Manuel utilisateur

Interacoustics

Interacoustics Sera Manuel utilisateur

Interacoustics

Interacoustics Titan Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
