ProMill 8000 Milling Center

USER'S GUIDE

Catalog # 200066 Rev C

ProMill 8000 Milling Center User's Guide

Catalog #200066 Rev C

August 2016

website: http://www.intelitek.com

email: [email protected]

Tel: (603) 625-8600

Fax: (603) 437-2137

including but not limited to photocopy, photography, magnetic or other recording, without the prior agreement and

written permission of the publisher. Program listings may be entered, stored and executed in a computer system,

but not reproduced for publication.

Every effort has been made to make this book as complete and accurate as possible. However, no warranty of

suitability, purpose, or fitness is made or implied. Intelitek is not liable or responsible to any person or entity for loss

or damage in connection with or stemming from the use of the software, hardware and/or the information

contained in this publication.

Intelitek bears no responsibility for errors that may appear in this publication and retains the right to make changes

to the software, hardware and manual without prior notice.

Warnings

The operation of rotating machinery should only be attempted by experienced, knowledgeable

individuals.

Read the entire contents of this guide before running the ProMill 8000 Milling Center.

To avoid possible injury always observe the safety precautions described in this User's Guide.

The following icons indicate important information throughout this User’s Guide.

Safety

Provides essential safety instructions that must be followed to prevent operator injury or

death.

Product Care

Provides recommendations for reducing the chance of machine damage.

Take Note

Provides important information about your product.

Table of Contents

Using this Guide............................................................................................................................................................iv

1. Safety Guidelines ..................................................................................................................................................1

1.1. Detailed Safety Guidelines............................................................................................................................................. 1

1.2. Safety Checklist ............................................................................................................................................................. 5

2. Introducing the ProMill 8000 ................................................................................................................................6

2.1. Overview of Standard Features ..................................................................................................................................... 6

2.2. ProMill 8000 Components............................................................................................................................................. 8

2.3. Overview of CNCBase/Motion Control Software ........................................................................................................ 12

2.4. Standard Accessories................................................................................................................................................... 12

2.5. Optional Accessories ................................................................................................................................................... 13

3. Installing the Hardware and Software ................................................................................................................14

3.1. Preparing for Installation............................................................................................................................................. 14

3.2. Installing the Hardware ............................................................................................................................................... 18

3.3. Installing the Software................................................................................................................................................. 20

3.4. Contacting Technical Support...................................................................................................................................... 33

3.5. Returning Defective Products...................................................................................................................................... 33

4. Maintaining the ProMill 8000 .............................................................................................................................35

4.1. Cleaning the Milling Center ......................................................................................................................................... 35

4.2. Maintaining Individual Milling Machine Components................................................................................................. 36

4.3. Maintenance Schedule Summary................................................................................................................................ 38

4.4. Adjusting and Maintaining the Pneumatic Systems .................................................................................................... 39

4.5. Maintaining the PC in a Shop Environment ................................................................................................................. 41

5. Using the Control Software.................................................................................................................................42

5.1. Launching the Control Software.................................................................................................................................. 42

5.2. Selecting Online or Simulation Mode .......................................................................................................................... 44

5.3. Software Interface....................................................................................................................................................... 45

5.4. Homing ........................................................................................................................................................................ 61

5.5. Opening an NC File ...................................................................................................................................................... 62

5.6. Verifying an NC Program ............................................................................................................................................. 64

5.7. Running an NC Program .............................................................................................................................................. 71

5.8. Accessing Help............................................................................................................................................................. 72

6. Installing a Tool ...................................................................................................................................................73

Table of Contents

6.1. Removing the Tool Holder from the Spindle ............................................................................................................... 74

6.2. Inserting the Tool into the Tool Holder ....................................................................................................................... 74

6.3. Inserting the Tool Holder into the Spindle .................................................................................................................. 75

7. Tutorial: Milling a Sample Part............................................................................................................................77

7.1. Reviewing Safety Procedures ...................................................................................................................................... 78

7.2. Preparing Tools and Materials..................................................................................................................................... 78

7.3. Opening the Sample NC File ........................................................................................................................................ 78

7.4. Determining the Stock Size.......................................................................................................................................... 79

7.5. Configuring the Verify Settings.................................................................................................................................... 80

7.6. Defining the Tool ......................................................................................................................................................... 84

7.7. Verifying the Program ................................................................................................................................................. 86

7.8. Turning On and Homing the Machine ......................................................................................................................... 87

7.9. Mounting the Workpiece ............................................................................................................................................ 88

7.10. Setting the Axes Zero Positions ................................................................................................................................... 88

7.11. Performing a Dry Run .................................................................................................................................................. 93

7.12. Running the Program................................................................................................................................................... 94

8. Basic CNC Programming......................................................................................................................................96

8.1. Elements of an NC Part Program ................................................................................................................................. 96

8.2. General Programming Suggestions ............................................................................................................................. 97

8.3. Reviewing an NC Program ........................................................................................................................................... 98

8.4. NC Codes ..................................................................................................................................................................... 98

9. NC Programming Routines................................................................................................................................129

9.1. Linear Interpolation Programming ............................................................................................................................ 129

9.2. Circular Interpolation Programming in the XY Plane ................................................................................................. 130

9.3. Circular Interpolation Programming in Other Planes ................................................................................................ 132

9.4. Rapid Traverse Programming .................................................................................................................................... 133

9.5. Helical Interpolation Programming ........................................................................................................................... 134

9.6. Canned Cycle Programming ...................................................................................................................................... 135

9.7. Subprogram Programming ....................................................................................................................................... 143

10. Multiple Tool Programming ..............................................................................................................................145

10.1. Specifying the Tools................................................................................................................................................... 146

10.2. Configuring the ATC................................................................................................................................................... 146

10.3. Writing an NC Program for Multiple Tools ................................................................................................................ 147

10.4. Establishing the Reference Tool ................................................................................................................................ 148

10.5. Setting Tool Offsets ................................................................................................................................................... 149

10.6. Testing the Multi-tool Program ................................................................................................................................. 152

Table of Contents

iii

10.7. Tutorial: Running a Multi-tool Program .................................................................................................................... 153

11. An Introduction to CNC Milling .........................................................................................................................158

11.1. Understanding Coordinate Systems .......................................................................................................................... 158

11.2. Setting Spindle Speeds .............................................................................................................................................. 161

11.3. Setting Feed Rate and Depth of Cut .......................................................................................................................... 162

11.4. Selecting Lubricants and Coolants............................................................................................................................. 163

11.5. Tool Types ................................................................................................................................................................. 163

11.6. Sharpening the Tools................................................................................................................................................. 165

12. Automation lntegration ....................................................................................................................................166

12.1. Integration Instructions............................................................................................................................................. 166

12.2. CNC Programming for Robotic Communication ........................................................................................................ 169

12.3. Sample Robot - CNC Communication Sequence........................................................................................................ 171

12.4. Sample Robotic - CNC lntegration Programs ............................................................................................................. 179

Using this Guide

Welcome to the ProMill 8000 User’s Guide.

This guide is designed to help you install and begin using the ProMill 8000 hardware and software. The

later chapters provide an NC programming reference.

We recommend that you use the guide as follows.

1. Read chapter 1 Safety Guidelines. Review this chapter often.

2. Read chapter 2 Introducing the ProMill 8000.

3. Install the hardware and software as described in chapter 3 Installing the Hardware and

Software.

4. Read chapter 4 Maintaining the ProMill 8000.

5. Read chapter 5 Using the Control Software.

6. Read chapter 6 Installing a Tool

7. Follow the instructions in the tutorial presented in chapter 7 Tutorial: Milling a Sample Part.

8. Use the remaining chapters as a reference guide for NC programming.

a. Chapter 8 Basic CNC Programming presents guidelines for writing basic NC programs, and lists

and describes the use of all codes available for use with the ProMill 8000.

b. Chapter 9 NC Programming Routines provides instructions with examples for advanced NC

programming routines.

c. Chapter 10 Multiple Tool Programming provides instructions for configuring the control

software and writing NC code for programs that require the use of more than one cutting

tool. The chapter also presents step-by-step instructions for milling a sample part using

multiple tools.

d. Chapter 11 An Introduction to CNC Milling provides a basic introduction to the theory of CNC

milling.

e. Chapter 12 Automation lntegration provides instructions for integrating the ProMill 8000 in a

robotic environment.

1 Safety Guidelines

1.1 Detailed Safety Guidelines

1. Safety Guidelines

The safety rules presented here should be reviewed and practiced by all operators of the ProMill 8000

milling center.

This section presents the following information:

Section Contents: Safety Guidelines

Section

Name

Page

1.1

Detailed Safety Guidelines

1.2

Safety Checklist

1.1. DETAILED SAFETY GUIDELINES

The table below provides detailed safety instructions.

Info Table: Safety Guidelines

Category

Guideline

Comment

Operator knowledge

and authorization

Review the User’s

Guide.

Read this guide carefully before you use the milling center and

keep it readily accessible for quick reference. Know the intended

applications and limitations of the milling center as well as its

hazards.

Keep untrained visitors

away from the

equipment.

Children and visitors unfamiliar with the hazards of rotating

machinery should always be kept away from the work area.

Behavior

Do not overreach.

Keep your footing and balance at all times so you won’t fall

against or clutch at the moving machine.

Do not operate the

machine under the

influence of alcohol or

drugs.

Alcohol or drugs may impair your judgment and reaction time,

which could contribute to an on-the-job accident.

Avoid distractions

while running the

machine.

Use simple common sense and pay attention while operating

any piece of machinery.

1 Safety Guidelines

1.1 Detailed Safety Guidelines

Work Area

Keep the work area

clean.

Cluttered work areas and bench tops invite accidents.

Avoid a dangerous

environment.

Don’t use the milling center in damp or wet locations. Never

operate electrical equipment in the presence of volatile and

flammable petroleum-based solvents and lubricants.

Keep coolant away

from electrical

components.

Do not allow coolant to splash into or near the computer.

Clothing and Hair

Avoid loose hair and

clothing.

Don't wear loose clothing or jewelry that can get caught in

moving parts. Wear a hat or hair net, or tie your hair back to

keep it away from moving parts.

Safety Equipment

Wear safety glasses.

During operation any power tool can throw foreign objects and

harmful chemicals into your eyes. Always put on safety glasses

or eye shields before starting up the milling center. Safety

glasses or shields should provide full protection at the sides, as

well as the front of the eyes.

Ground all tools.

The milling center has an AC power cord terminated by a three-

prong plug. The power cord should be plugged into a three-

hole, grounded receptacle. If a grounding adapter is used to

accommodate a two-prong receptacle, the adapter wire must

be attached to a known ground. Never remove the third prong

from the plug on the AC power cord.

Keep the safety door

closed while machine

is in motion.

The safety door should remain in place whenever the spindle

motor is on or the cross slide is moving.

Remove adjusting keys

and wrenches.

Make it a habit to check that keys and adjusting wrenches are

removed from the milling center before using the machine.

Emergency Stop

Stopping the machine.

Before you run the ProMill 8000 for the first time, you should

know how to stop the machine should an emergency situation

arise.

To initiate an emergency stop on the milling center, either:

Press the Emergency Stop button, or

Turn the machine off at the power switch.

In non-emergency situations, the machine can be stopped in the

following ways:

Simultaneously press the Control and Space Bar keys

on the computer keyboard

Activate one of the limit switches

Activate the safety door interlock switch.

When to use the

Emergency Stop.

You should use the Emergency Stop button to disconnect power

to the milling center when faced with a problem such as a tool

breaking or a collision occurring, and while performing routing

operations, such as when changing tools or mounting or

removing a workpiece.

1 Safety Guidelines

1.1 Detailed Safety Guidelines

Using the machine-

mounted emergency

stop button.

There is an Emergency Stop button located on the front panel of

the milling center; it has an oversized red cap.

To engage: Press the button in.

To release: Turn the button clockwise, it will pop out on its own.

Using the software

stop button.

The execution of the part program can be interrupted by

pressing the Control and Spacebar buttons on the computer

keyboard. Unlike using the Emergency Stop button, this method

of stopping the milling center does not cause the software to

lose track of the tool position.

Operation Rules

General

Proper setup of the milling center is essential for safe milling.

These procedures must be followed each time a new tool is

mounted. General setup requirements for the milling center

include checking components for cleanliness and lubrication,

mounting the cutting tool, mounting the workpiece, and setting

the spindle rotation speed.

Avoid accidental

starting.

Make sure the power switch is off before plugging in the milling

center power cord.

Check milling machine

components.

Always examine the machine to be sure that the work area is

free of shavings and particles from previous operations. Remove

such debris from the milling machine to avoid possible binding

of components which may result in possible damage to the

milling machine, the workpiece, or the operator.

Always make sure the machine is properly lubricated.

Do not force a tool.

Select the feed rate and depth of cut that are best suited to the

design, construction, and purpose of the cutting tool. It is

always better to take too light a cut than too heavy a cut.

Use the right tool.

Select the type of cutting tool best suited to the milling

operation. Don't force a tool or attachment to do a job it wasn't

designed for.

Maintain cutting tools

in good condition.

Keep cutting tools sharp and clean. Lubricate and clean milling

center components on a regular basis.

Mount the cutting tool

correctly.

Each cutting tool used in the milling operation must be sharp

and properly installed in the spindle. The cutting edge of the

tool must be on the centerline or just below the centerline

(0.004 inch or 0.1 mm maximum) of the axis of rotation of the

milling machine

Secure the workpiece.

Be certain that the workpiece is firmly clamped to the table or

secured in a vice.

Tighten all holding,

locking and driving

devices.

Tighten the work holders and tool holders. Do not over tighten

these devices. Over tightening may damage threads or warp

parts, thereby reducing accuracy and effectiveness.

Turn the spindle by

hand before starting.

Manually turning the spindle allows you to safely determine

that the tool will not hit the milling center bed, cross slide, or

stock on start up.

Table des matières

Autres manuels Intelitek Outils électriques

Intelitek

Intelitek SCORA-ER 14 Manuel utilisateur

Manuels Outils électriques populaires d'autres marques

AEG

AEG OMNI-JS Manuel utilisateur

SIP

SIP 01533 Manuel utilisateur

Ribimex

Ribimex PRS499 Manuel utilisateur

3M Fiber Optic Connector Crimp Tool Manuel utilisateur

Ryobi

Ryobi P524 Manuel utilisateur

ROJEK

ROJEK FSN 300A Manuel utilisateur

Kemper

Kemper 1740PRO Manuel utilisateur

WABCO

WABCO OptiTire Manuel utilisateur

EINHELL

EINHELL TE-MS 18/210 Li Manuel utilisateur

Orgapack

Orgapack OR-T 85 Guide rapide

TOUGHCUT

TOUGHCUT Diamond 400 Manuel utilisateur

Yaros

Yaros PB-3603 Manuel utilisateur

Fein

Fein BSS 2.0 E Guide de configuration

Baileigh Industrial

Baileigh Industrial SS-2725 Manuel utilisateur

Milwaukee

Milwaukee 2674-20 Manuel utilisateur

Fein

Fein BLs 1.6 Manuel utilisateur

Princess

Princess Electric Multi Sharpener Manuel utilisateur

FOREDOM

FOREDOM K.1050 Manuel
