Intel SSR212CC Manuel utilisateur

Intel® Storage System

SSR212CC

Tested Hardware and Operating

System List (THOL)

Revision 1.5

Aug, 2007

Server Platform Grou Technical Marketing

Revision History Intel® Storage System SSR212CC

Revision 1.5

Revision History

Date

Revision

Number Modifications

May 19, 2006 1.0 Release copy.

July 20, 2006 1.1 Added updates for RoHS ECO: IOS 10. Added Enclosure Management

SW revisions.

November 6,

2006

1.2 Added SuSE 9.3 Professional OS support (Chapters 2 & 6), added

Western Digital 250 & 320 G hard disk drives (Chapter 6), added 3

Party

Software Application Support note (Chapter 3).

February 6,

2007

1.3 Added several new hard disk drives (Chapter 6).

March 8, 2007 1.4 Added several new hard disk drives (Chapter 6).

August 20, 2007 1.5 Added several new hard disk drives (Chapter 6).

Intel® Storage System SSR212CC Disclaimers

Revision 1.5

iii

Disclaimers

THE INFORMATION IN THIS DOCUMENT IS PROVIDED "AS IS" WITH NO WARRANTIES WHATSOEVER, INCLUDING ANY

WARRANTY OF MERCHANTA ILITY, FITNESS FOR ANY PARTICULAR PURPOSE, OR ANY WARRANTY OTHERWISE

ARISING OUT OF ANY PROPOSAL, SPECIFICATION, OR SAMPLE.

Information in this document is provided in connection with Intel

products. No license, express or implied, by estoppel or

otherwise, to any intellectual property rights is granted by this document. Except as provided in Intel's Terms and Conditions of Sale

for such products, Intel assumes no liability whatsoever, and Intel disclaims any express or implied warranty, relating to sale and/or

use of Intel products including liability or warranties relating to fitness for a particular purpose, merchantability, or infringement of

any patent, copyright or other intellectual property right. Intel products are not intended for use in medical, life saving, or life

sustaining applications.

Intel retains the right to make changes to its test specifications at any time, without notice.

The hardware vendor remains solely responsible for the design, sale and functionality of its product, including any liability arising

from product infringement or product warranty.

Intel, the Intel logo, and EtherExpress are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United

States and other countries.

*Other names or brands may be claimed as the property of others.

Table of Contents Intel® Storage System SSR212CC

Revision 1.5

Table of Contents

1. Introduction ........................................................................................................................5

1.1 Test Overview ........................................................................................................5

1.1.1 Adapter / Peripheral Compatibility and Stress Testing ...........................................5

1.2 Pass/Fail Test Criteria............................................................................................6

2. Su orted O erating Systems ..........................................................................................8

3. Su orted Software A lications .....................................................................................9

4. Su orted Client Systems ...............................................................................................10

5. Ada ters and Peri herals ................................................................................................11

5.1 SATA Host us Adapter.......................................................................................11

5.2 PCI NIC................................................................................................................11

5.3 Disk On Module™ (DOM) ....................................................................................11

5.4 US CD/DVD Drives............................................................................................11

5.5 US Floppy Drives ...............................................................................................11

5.6 US Flash Drive (Key) .........................................................................................12

5.7 US Hub ..............................................................................................................12

5.8 Keyboard..............................................................................................................12

5.9 Mouse ..................................................................................................................12

5.10 Keyboard, Video and Mouse (KVM) Switch..........................................................13

6. Hard Disk Drives...............................................................................................................14

7. Network Switches.............................................................................................................17

Intel® Storage System SSR212CC Introduction

Revision 1.5

1. Introduction

This document is intended to provide users of the Intel® Storage System SSR212CC with a

guide to the different operating systems, adapter cards, and peripherals tested by Intel on this

platform.

This document will continue to be updated as new adapters, peripherals, and operating

systems are tested or until the Intel® Storage System SSR212CC is no longer in production.

Each new release of the document will present updated information as well as continue to

provide the information from previous releases.

Intel will only provide support for those adapters and peripherals under the specified system

configuration (System IOS and Firmware revisions) and operating systems versions with

which they were tested.

1.1 Test Overview

Testing performed on the Intel® Storage System SSR212CC is classified as Adapter /

Peripheral Compatibility and Stress Testing.



The latest version of the

operating system signifies the latest supported version

at the time of the actual test run.

Each new release of this document may have

a newly supported release of a given operating system. Previous releases of a

supported operating system may not be tested beyond the basic installation

test process.

1.1.1 Ada ter / Peri heral Com atibility and Stress Testing

Adapter / Peripheral Compatibility and Stress testing is performed only on the most current

release of the supported operating systems at the time of a given validation run. The Adapter /

Peripheral Compatibility and Stress testing process consists of three areas: Platform, Adapter

Compatibility, and Stress.

Platform: Each platform will successfully install the operating system, successfully run a disk

stress test, and successfully run a network stress test.

Ada ter Com atibility: Adapter compatibility validation (CV) testing uses test suites to gain an

accurate view of how the platform performs with adapters under the operating system. These

tests are designed to show hardware compatibility between the cards and the server platform

and include functional testing only. No heavy stressing of the systems or the cards is

performed for CV testing.

Stress Testing: This test sequence uses configurations that include Ethernet add-in adapters

in the one available slot, or a minimum 24-hour test run without injecting errors. Each

configuration passes an installation test, a Network/Disk Stress test. Any fatal errors that occur

will require a complete test restart.

Introduction Intel® Storage System SSR212CC

Revision 1.5

1.1.1.1 Su ort Commitment for Ada ter / Peri heral Com atibility and Stress

Testing

Intel commits to provide the following level of customer support for operating systems that

receive Adapter / Peripheral Compatibility and Stress testing:

•

Intel will provide support for customer issues with the operating system involving

installation and/or functionality of the server board with or without the adapters and

peripherals listed in this document as having been tested under the particular operating

system.

•

Support is defined as assistance in root causing issues, and determining a customer

acceptable resolution to the issue associated with the operating system. The resolution

may include, but is not limited to, on-board controller driver changes, engaging the

vendor for resolution, IOS changes, firmware changes, or determining a customer

acceptable workaround for the issue.

•

Intel will go through some of the steps to achieve certification to ensure its customers do

not run across any problems, but the actual certification is the responsibility of the

individual customer.



For operating systems, adapter cards, and peripherals not listed in this

document, there is no support commitment. Intel will consider support

requests on a case-by-case basis.

1.2 Pass/Fail Test Criteria

For each operating system, adapter, and peripheral configuration, a test passes if specific

criteria are met. Specific configurations may have had particular characteristics that were

addressed on a case-by-case basis. In general, a configuration passes testing if the following

conditions are met:

• The operating system installed without error.

• Manufacturer’s installation instructions or Intel’s best-known methods were used for the

operating system installation.

• No extraordinary workarounds were required during the operating system installation.

• The SSR212CC behaved as expected during and after the operating system

installation.

• Application software installed and executed normally.

• Hardware compatibility tests ran to completion without error.

• Test software suites executed successfully

• Test and data files were created in the correct directories without error.

• Files copied from client to server and back compare to the original with zero errors

reported.

• Clients remain connected to the server system.

• Industry standard test suites run to completion with zero errors reported.

All Intel® Storage System SSR212CC testing was performed using its 2U rail mount chassis.

Intel® Storage System SSR212CC Introduction

Revision 1.5

Intel® Storage System SSR212CC System Configuration 1

The following table lists the base system configuration tested. Each base system configuration

is assigned an identifier number that is referenced in the tables throughout this document. New

base system configurations are added with each new release of this document.



Intel will only provide support for adapters and peripherals under the specified

system configuration and operating system versions with which they were

tested.

SE7501JR2

BIOS

Revision

SE7501JR2

BMC/IMM

Firmware

Revision

SE7501JR2

mBMC

Firmware

Revision

SE7501JR2

FRU/SDR

Back lane

Firmware

SRCS28X

Firmware

Revision

7.40

10.0 0.48

2.40 0.0.6 2.00 814G

Windows* Server 2003

based Enclosure

Management

Windows* Storage

Server based

Enclosure

Management

Linux* based

Enclosure

Management

Intel Server

Management

V 1.0.0-20 V 1.0.0-17 V 1.0.0-48 8.4

Su orted O erating Systems Intel® Storage System SSR212CC

Revision 1.5

2. Su orted O erating Systems

The following table provides a list of supported operating systems compatible with the Intel®

Storage System SSR212CC. Each of the listed operating systems was tested for compatibility

with Intel® Storage System SSR212CC system configuration listed in Section 1 of this

document.

Identifier

number

O erating System

Base System Configuration

Tested & Ty e of Testing

1 Microsoft* Windows* Server 2003 Enterprise Edition, SP1. Configuration 1 – Compatibility &

Stress

2 Microsoft* Windows* Storage Server 2003. Configuration 1 – Compatibility &

Stress

Microsoft* Windows* Storage Server 2003, R2. (No

Enclousre Management Softwware GUI available for this

platform! Interface available in the form of a MMC plug-in

on support.intel.com.)

Configuration 1 – Compatibility &

Stress

4 Red Hat* Enterprise Linux* Server Edition 4, Update 2. Configuration 1 – Compatibility &

Stress

5 SuSE* Linux 9.3 Professional (32-bit and 64-bit). Configuration 1 – Compatibility &

Stress

Intel® Storage System SSR212CC Su orted Software A lications

Revision 1.5

3. Su orted Software A lications

The following table provides a list of software applications compatible with the Intel® Storage

System SSR212CC. Each of the listed applications was tested for compatibility with Intel®

Storage System SSR212CC system configuration listed in Section 2 of this document.

Software A lication

Base System Configuration Tested &

Ty e of Testing

O erating

System

Microsoft* SQL Server 2000 with SP4 Configuration 1 – Compatibility 1

Microsoft* SQL Server 2005 Configuration 1 – Compatibility 1, 2

Oracle* 10G Enterprise Server Configuration 1 – Compatibility 4

NOTE: Several 3

party independent software vendors (ISV’s) have performed their own

software application validation. Please contact the ISV’s directly for product information and

support. The current list of ISV’s can be found at

http://www.intel.com/design/servers/storage/ssr212cc/index.htm

Su orted Client Systems Intel® Storage System SSR212CC

Revision 1.5

4. Su orted Client Systems

The following table provides a list of supported client systems* compatible with the Intel®

Storage System SSR212CC

* based on the Intel server board or system listed below.

Manuf

Model

O erating System

Notes

Intel SE7520 D2 1, 2, 4.

Intel SE7221 K1-E 1, 2, 4.

Intel SE7525GP2 1, 2, 4.

Intel SE7320SP2 1, 2, 4.

Intel SE7210TP1-E 1, 2, 4.

Intel SSR212MA 1, 2, 4. iSCSI connectivity

Intel SS4000-E 1, 2, 4. CIFS connectivity

Autres manuels pour SSR212CC

Table des matières

Autres manuels Intel Stockage

Intel

Intel SSR316MJ2 Manuel utilisateur

Intel

Intel JBOD2312S3SP Instructions d'installation

Intel

Intel SSR316MJ2 Manuel utilisateur

Intel

Intel SSR212MA Manuel utilisateur

Intel

Intel SSR212MA Manuel utilisateur

Intel

Intel SS4200-EHW Mode d’emploi

Intel

Intel SSR316MJ2 Manuel utilisateur

Intel

Intel SSR212MA Manuel utilisateur

Intel

Intel SS4000-E - Entry Storage System NAS Server Guide de configuration

Intel

Intel SSR212CC Guide de configuration

Intel

Intel Solid-State Drive 320 Series Manuel du propriétaire

Intel

Intel SS4200-E - Entry Storage System NAS Server Guide de configuration

Intel

Intel SSDSC2BW120A4K5 Manuel utilisateur

Intel

Intel PowerEdge External Media System 1434 Manuel d'utilisation

Intel

Intel X25-E Extreme Guide de référence

Intel

Intel JBOD 2000 Family Instructions d'installation

Intel

Intel SSDPAMM0004G1 Manuel utilisateur

Intel

Intel SSR316MJ2 Manuel utilisateur

Intel

Intel SS4000-E - Entry Storage System NAS Server Manuel utilisateur

Intel

Intel Solid State Drive 750 Series Manuel utilisateur

Intel

Intel SSR212PPi500 Mode d’emploi

Intel

Intel SS4200-E - Entry Storage System NAS Server Manuel utilisateur

Intel

Intel 910 Series Manuel utilisateur

Intel

Intel SSR316MJ2 Mode d’emploi

Manuels Stockage populaires d'autres marques

QNAP

QNAP TS 32PXU Series Manuel utilisateur

LaCie

LaCie RUGGED RAID Manuel utilisateur

Freecom

Freecom CLS DOCK Manuel utilisateur

PNY

PNY Attache P-FD64MBATT3 Manuel utilisateur

HP StorageWorks MSL2024 Manuel utilisateur

OLT

OLT 6x6 Maximizer Manuel utilisateur

Transcend

Transcend JetFlash 160 Manuel utilisateur

LaCie

LaCie RUGGED MINI Manuel utilisateur

Thunderbolt

Thunderbolt 600 Manuel utilisateur

Panasonic

Panasonic LB-DH8 series Manuel

LaCie

LaCie 12big Thunderbolt 3 Manuel utilisateur

Spectra Logic

Spectra Logic T-Series Spectra T50e Manuel utilisateur

Panasonic

Panasonic LKM-F931-1 Manuel utilisateur

Tabernus

Tabernus Enterprise Erase E2400 Manuel utilisateur

Rocstor

Rocstor COMMANDER 3F series Manuel utilisateur

HP P9000 Manuel utilisateur

Western Digital

Western Digital Ultrastar Data60 Manuel utilisateur

Dell

Dell PowerVault MD3600f Series Manuel utilisateur
