1Determine a secure and suitable moun ng loca on for your camera. The camera should be installed so that the
area you are trying to view is clearly seen on the display and a cri cal reference (leading edge) of the vehicle is also
visible. For example: Rear mounted cameras should be installed to give you the maximum viewing area behind the
vehicle while s ll seeing the rear most part of the vehicle, typically the rear bumper, or the leading edge at the
bo om of the displayed image.
Quality First For Performance That Lasts
CVC600HC Series
Quick Installation Guide
Included in the box:
1 - CVC600HC Series - Camera
1 - Moun ng Bracket Kit
1 - Moun ng Bolt Set
! Please include this Quick Installa on Guide with the
other vehicle documenta on provided to the end user.
2 Install the camera bracket and gasket with the hardware provided. The gasket is placed between the camera
bracket and vehicle surface. Use the bracket as a template for drilling the required holes. The recommended mount-
ing bolt torque specifi ca on is between 20 and 22 inch pounds.
Use only INTEC supplied camera brackets. The INTEC
camera bracket provides the necessary required isola on
from the vehicle body. Failure to do so could result in a fi re
if shor ng occurs.
Be certain that all items are secure. Items that are not
secure or mounted in an unstable manner can come loose
and cause damage or personal injury.
Do NOT install the camera in any area that allows it to
extend out past the vehicle, as this can cause injury if it
were to come in contact with people walking around the
vehicle.
Always verify the area being drilled into is of suffi cient
strength and is clear of all wires and other items around or
underneath so as not to cause damage.
Always confi rm proper image orienta on before driving or
opera ng your vehicle. The orienta on of the image
displayed is cri cal to safe vehicle opera on. An object on
the right side of your vehicle needs to be seen on the right
side of the display screen.
Before you begin driving, be sure the display controls are
adjusted properly. This will avoid unnecessary distrac ons
while driving.
For more detailed installa on instruc ons, please visit www.intecvideo.com/support.html
You may also call us toll free at 800-468-3254 (West) or 800-522-5989 (East) or e-mail support@intecvideo.com with any ques ons. Rev A 05/2019
Bracket
Gasket
For more detailed installa on instruc ons, please visit www.intecvideo.com/support.html
You may also call us toll free at 800-468-3254 (West) or 800-522-5989 (East) or e-mail support@intecvideo.com with any ques ons. Rev A 05/2019
4 Assemble the camera to the bracket.3 Connect the camera to the main cable by aligning the
keys and pushing together un l fi rmly seated.
Note: The Molex connec on is not waterproof and
should not be exposed to the environment. It is recom-
mended that the connec on be made inside the vehicles
body.
If exposed to the environment, the Molex connectors
must be weatherproofed. A simple means is to use
1-inch diameter gum interior heat shrink tubing (INTEC
part # CVST10) to cover the whole connector assembly.
This will seal and protect the connector from direct
moisture due to rain, snow, vehicle washing, etc.
Alignment Marks
Alignment Marks
NOR MIR
Changing the Camera Image: Some monitors like INTEC’s
CVMHDVR706 allow for image rota on via the moni-
tors so ware in either the ver cal or horizontal plain or
both. However other monitors do not have this capabil-
ity. If you need to change the camera image at the cam-
era , you can do so by using a fl at screwdriver. Remove
the screw from its current posi on and place it in the
opposite one. Refer to the camera enclosure bo om
diagram below.
Moun ng Op ons: In addi on to the typical rear camera
mount there are four side and two ceiling moun ng op-
ons. They include the:
CVC600HCS-1 le front viewing rearward
CVC600HCS-2 right front viewing rearward
CVC600HCS-3 right rear viewing forward
CVC600HCS-4 le rear viewing forward
CVC600HCC-1 ceiling front viewing rearward
CVC600HCC-2 ceiling rear viewing forward
Installa on Op on: Some installa on may require rout-
ing the cable along the vehicle body. If this becomes
necessary cut the gasket as shown below allowing the
cable to exit the rear of the camera enclosure.
S-1
S-3
S-4
S-2
