User Guide for NUC8i3CYSM, NUC8i3CYSN

Intel® NUC8 Home, a Mini PC with Windows® 10 –NUC8i3CYSM

Intel® NUC8 Home, a Mini PC with Windows® 10 –NUC8i3CYSN

User Guide

User Guide for NUC8i3CYSM, NUC8i3CYSN

Before You Begin

CAUTIONS

The procedures in this guide assume familiarity with the general terminology associated with

personal computers and with the safety practices and regulatory compliance required for using

and modifying electronic equipment.

Always disconnect the computer from its power source and from any network before performing any

of the procedures described in this guide.

Failure to disconnect power or networks before you open the computer or perform any procedures can

result in personal injury and/or equipment damage. Some circuitry on the board can continue to

operate even though the front panel power button is off.

Follow these guidelines before you begin:

•Always follow the steps in each procedure in the correct order.

•Create a log to record information about your computer, such as model, serial numbers,

installed options, and configuration information.

•Electrostatic discharge (ESD) can damage components. Perform the procedures described in

this chapter only at an ESD workstation using an antistatic wrist strap and a conductive foam

pad. If such a station is not available, you can provide some ESD protection by wearing an

antistatic wrist strap and attaching it to a metal part of the computer chassis.

Installation Precautions

When you install and test the Intel NUC, observe all warnings and cautions in the installation

instructions.

To avoid injury, be careful of:

•Sharp pins on connectors

•Sharp pins on circuit boards

•Rough edges and sharp corners on the chassis

•Hot components (such as SSDs, processors, voltage regulators, and heat sinks)

•Damage to wires that could cause a short circuit

Observe Safety and Regulatory Requirements

If you do not follow these instructions, you increase your safety risk and the possibility of

noncompliance with regional laws and regulations.

User Guide for NUC8i3CYSM, NUC8i3CYSN

This guide tells you how to:

•

Change/install a 2.5-inch drive

•

Change/install an M.2 SSD

•

Use a VESA mount bracket

•

Connect power

•

Set up Microsoft® Windows® 10

•

Install the latest device drivers and software

•

Recover the operating system

Open the Chassis

Unscrew the four corner screws on the bottom of the chassis and lift the cover.

User Guide for NUC8i3CYSM, NUC8i3CYSN

Changing a 2.5” Hard Drive or SSD

The Intel NUC Kits

NUC8i3CYSM

and

NUC8i3CYSN

have pre-installed 2.5” Hard Disk Drive (HDD).

Find compatible 2.5” drives in the Intel Product Compatibility Tool:

•NUC8i3CYSM

•NUC8i3CYSN

1. Unscrew the 4 screws holding the current drive in the bay.

2. Remove the pre-installed drive from the drive bay.

3. Slide the new 2.5” drive into the drive bay, ensuring the SATA connectors are fully seated into the

connectors of the SATA daughter card (A).

4. Secure the drive into the drive bay with the four screws that were used in step 1. Set the drive bay

bracket down inside the chassis (C).

User Guide for NUC8i3CYSM, NUC8i3CYSN

Changing an M.2 SSD or Intel® Optane™ Memory Module

The Intel NUC Kits

NUC8i3CYSM

and

NUC8i3CYSN

support an 80mm SSD.

Find compatible M.2 SSDs in the Intel Product Compatibility Tool

•NUC8i3CYSM

•NUC8i3CYSN

To Change an M.2 SSD:

1. Remove the small silver screw from the 80mm metal standoff on the board (A).

2. Remove the SSD/Intel Optane Memory from the connector if there is one installed.

3. Align the space at the bottom of the new M.2 SSD to the key on the connector.

4. Insert the bottom edge of the M.2 SSD into the connector (B).

5. Secure the card to the standoff with the small silver screw (C).

User Guide for NUC8i3CYSM, NUC8i3CYSN

Close the Chassis

After all components have been installed, close the Intel NUC chassis (using an electric or battery

operated screw driver can damage the NUC).

Attach and Use the VESA Bracket (Optional)

Follow these instructions to attach and use the VESA mount bracket:

1. Using the four small black screws that were included in the box, attach the VESA bracket to the

back of the monitor or TV.

User Guide for NUC8i3CYSM, NUC8i3CYSN

2. Attach the two slightly larger black screws to the bottom chassis cover of the Intel NUC.

3. Slide the Intel NUC onto the VESA mount bracket.

User Guide for NUC8i3CYSM, NUC8i3CYSN

Connect Power

Each Intel NUC model includes either a region-specific AC power cord or no AC power cord (only the

power adapter).

Product codes

Power cord type

BOXNUC8i3CYSM

BOXNUC8i3CYSN

No power cord included. An AC power cord needs to be purchased

separately. Power cords are available at many Internet sites for use in

multiple countries. The connector on the power adapter is a C5 type

connector.

BOXNUC8i3CYSM1

BOXNUC8i3CYSN1

US power cord included.

BOXNUC8i3CYSM2

BOXNUC8i3CYSN2

EU power cord included.

BOXNUC8i3CYSM3

BOXNUC8i3CYSN3

UK power cord included.

BOXNUC8i3CYSM4

BOXNUC8i3CYSN4

Australia/New Zealand power cord included.

BOXNUC8i3CYSN5

India power cord included.

BOXNUC8i3CYSM6

China power cord included.

Set Up Microsoft® Windows® 10

Microsoft Windows 10 is already installed on the Intel NUC. The first time you start the computer, you

are guided through the Windows 10 setup steps, including:

•Selecting your region and language.

•Accepting the Microsoft Windows license terms.

•Personalizing Windows and assign a PC Name.

•"Get Online" dialog to pick a wireless network (this step is optional).

•Choosing Express Settings or Customize.

•Assigning a User Name and Password.

Reinstalling the Operating System

If you upgrade or replace the computer’s drive, you may need to install a new version of the operating

system. See these resources:

•Supported Operating Systems

•Windows Setup Guide

User Guide for NUC8i3CYSM, NUC8i3CYSN

Install the Latest Device Drivers and Software

Here are the options for keeping device drivers current:

•Allow the Intel® Driver & Support Assistant (Intel® DSA) to detect out-of-date drivers

•Manually download drivers, BIOS, and software from Download Center:

oNUC8i3CYSM

oNUC8i3CYSN

The following device drivers and software are available.

•Intel® Chipset Device Software

•Intel® Management Engine

•Intel® Wireless

•Intel® Bluetooth

•Intel® Gigabit Ethernet

•Intel® Serial /IO

•Intel® GNA Scoring Accelerator

•Radeon™ 540 Graphics

•Realtek* Card Reader

•Realtek* Audio

•ITE* Consumer Infrared

•Intel® Rapid Storage Technology

Operating System Recovery

There’s a Windows recovery partition on the Intel NUC. You can use this partition to Refresh, Reset, or

Restore Windows. Here is what each of these actions do:

Refresh

If your PC isn't performing as well as it once did, and you don't know why, you can

refresh your PC. This action doesn’t delete any of your personal files or change

your settings. Refresh does the following:

•Files and personalization settings won’t change.

•PC settings are changed back to their defaults.

•Apps from the Windows Store are kept.

•Apps installed from disks or websites are removed.

•List of removed apps is saved on the desktop.

Reset

If you want to recycle your PC, give it away, or start over with it, you can reset it

completely. This process removes everything. Reset does the following:

•All personal files and apps are removed.

•PC settings are changed back to their defaults.

•Windows is reinstalled.

Restore

If a recently installed app or driver is causing problems with your PC, you can

restore Windows back to an earlier point in time, called a restore point. System

Restore doesn’t change your personal files, but it can remove recently installed

apps and drivers.

User Guide for NUC8i3CYSM, NUC8i3CYSN

Caution - Before performing a Refresh or Reset:

•Make sure to back up all personal data to external storage.

•Remove SD card from the card slot, if one is inserted.

To access the recovery media:

If Windows starts

From Windows Start, type Recovery and select Recovery Options.

See Recovery options in Windows 10 for complete details on how

to use the recovery options.

If Windows doesn’t start

The recovery process should automatically start. If Recovery

doesn’t automatically start, you can try to initiate it as follows:

1. Press F8 during boot, when you see the prompt “F8 to

Activate Windows 8.1/10 Recovery Mode”.

2. Follow the recovery steps.
