Inseego Wavemaker FG2000 Manuel utilisateur

FG2000 Quick Start Guide Table of Contents

English

ﺔﯿﺑﺮﻌﻟا

Deutsch

Español

Français

Italiano

English

Top View

This guide provides instructions for setting up, connecting, and

configuring your 5G Indoor Router FG2000.

Multicolor LED

LED Color Operation Meaning

Blue Solid

Blinking

Strong 5G connection (3 – 5 bars)

Weak 5G connection (1 – 2 bars)

Green Solid

Blinking

Strong 4G connection (3 – 5 bars)

Weak 4G connection (1 – 2 bars)

White Solid

Blinking

Internet is available only on Ethernet WAN

Factory reset

Yellow Solid Software update is in progress

Red Solid

Blinking

Router is booting up

No service, SIM error, or locked SIM card

English

Back View

SIM Slot

Power Port

Antenna

Ports*

ON/OFF WPS 1Gbps LAN Ports

Phone Port+

5Gbps LAN Port

1Gbps WAN Port

*For external 3.4-5GHz antennas supporting high sub-6 bands

+Optional feature

English

Step One: Install the SIM Card and Batteries

Setting Up Your FG2000

This device supports only Nano SIM cards.

• Remove the cover from the SIM slot on the right side of the device.

• Use the provided SIM tool to insert a Nano

4FF SIM card into the appropriate SIM slot

and reattach the cover.

NOTE: If necessary, remove the SIM from its protective sleeve, being

careful not to touch the gold-colored contact points. Insert the SIM

card notch first, with the contact points facing the back of the device.

• On the bottom of the device, slide the battery cover to the left and

insert a fingernail at the edge to lift it out of place.

• Insert three AA batteries and replace the cover.

• Press the Power button to turn the FG2000 on for the next step.

Step Two: Identify a Location for your FG2000

• Scan the QR code to download the Inseego Mobile App

from AppStore or Google Play , or visit https://inseego.com/

inseego-connect-get-app to download the App.

• Follow instructions within the Inseego Mobile App to connect to the

FG2000 and perform a location survey to identify the ideal location

for your FG2000.

NOTE: Make sure to place your FG2000 on a sturdy surface.

English

Connecting to a Wireless Device

To wirelessly connect a Wi-Fi-capable device (such as a PC, laptop, tablet,

or phone) to your 5G Indoor Router for the first time:

1. Make sure the 5G Indoor Router is powered on and the indicator

LED is blue, green, or white.

2. On the device you want to connect to the Internet, open the

Wi-Fi settings or application and in the displayed list of available

networks, find the Primary Wi-Fi network name printed on the

bottom of your 5G Indoor Router.

3. Click Connect or otherwise select the network name.

4. When prompted, enter the Primary Wi-Fi password printed on

the bottom of the FG2000. You can change the default name or

password to something easier to remember (see“Monitoring and

Managing Your 5G Indoor Router”).

Your Wi-Fi–capable device is now connected to the Internet.

Step Three: Power on the FG2000

• Attach the power cord to the charger (power cord comes in two pieces).

• Plug the power cord into the router power port and plug the power

adapter into an AC wall outlet.

• Press the Power button on the device to turn it on. The indicator LED

turns on while the FG2000 powers on. Once the unit is fully on, the LED

turns solid blue, indicating a strong 5G connection.

WARNING: Be sure to use the power adapter that came with your device to avoid damage that may

void the warranty.

NOTE: For information on connecting devices with WPS, see the User Guide available online at

https://www.inseego.com/download/FG2000_user_guide.pdf.

English

Restoring Factory Settings

To restore factory settings, follow these steps:

NOTE: When performing the factory reset, any changes made to settings will be lost.

Monitoring and Managing Your 5G Indoor Router

NOTE: The initial Admin Web UI and Wi-Fi passwords are printed on the label of your device. It is

strongly recommended to change your passwords before using your 5G Indoor Router.

You can use multiple options to monitor and manage your 5G Indoor Router:

Inseego Mobile App - Use the same mobile app you used to install your

FG2000 to perform basic device monitoring and management.

FG2000 Admin Web UI - Access the Web UI at http://192.168.1.1 for a full

set of device management features.

Inseego Connect - Go to connect.inseego.com to sign up for a free

Inseego Connect account, which provides the fullest experience for

monitoring and managing FG2000 devices from anywhere in the world

with access to a web browser.

1. Verify that your 5G Indoor Router is powered on.

2. On the bottom of your router, slide the battery cover to the left

and insert a fingernail at the edge to lift it out of place. Find the

master RESET opening in the compartment.

3. Place the RESET end of the provided

SIM tool (or one end of an unfolded

paper clip) into the RESET opening and

press down for approximately five

seconds until the device resets.

English

Inseego Mobile App Requirements

More information

To access a User Guide, go to https://www.inseego.com/download/

FG2000_user_guide.pdf.

Or, from the FG2000 Web UI, select Help > Customer Support > User

Guide.

Customer Service and Troubleshooting

Please reach out to your reseller.

WARNING: DO NOT ATTEMPT TO SERVICE THE WIRELESS COMMUNICATION DEVICE YOURSELF. SUCH

ACTION MAY VOID THE WARRANTY. THE ROUTER IS FACTORY TUNED. NO CUSTOMER CALIBRATION OR

TUNING IS REQUIRED. CONTACT INSEEGO TECHNICAL SUPPORT FOR INFORMATION ABOUT SERVICING

YOUR WIRELESS COMMUNICATION DEVICE.

Support and More

Any device with Wi-Fi capability and an Internet browser. The FG2000 is

compatible with all major operating systems and the latest versions of

browsers.

System Requirements

Smartphone or device on iOS 13 or above, or Android 9.0 or above.

ﺔﯿﺑﺮﻌﻟا

ناﻮﻟﻷا ةدﺪﻌﺘﻣ LED ةﺀﺎﺿإ

LED 



قرزأ

ﺾﯿﻣو

ﺖﺑﺎﺛ

(تﺎﻃﺮﺷ 5ﻰﻟإ 3ﻦﻣ) يﻮﻗ 5G لﺎﺼﺗا

(ﻦﯿﺘﻃﺮﺷ ﻰﻟإ ﺔﻃﺮﺷ ﻦﻣ) ﻒﯿﻌﺿ 5G لﺎﺼﺗا

ﺮﻀﺧأ

ﺾﯿﻣو

ﺖﺑﺎﺛ

(تﺎﻃﺮﺷ 5ﻰﻟإ 3ﻦﻣ) يﻮﻗ 4G لﺎﺼﺗا

(ﻦﯿﺘﻃﺮﺷ ﻰﻟإ ﺔﻃﺮﺷ ﻦﻣ) ﻒﯿﻌﺿ 4G لﺎﺼﺗا

ﺾﯿﺑأ

ﺾﯿﻣو

ﺖﺑﺎﺛ

Ethernet WAN ﻰﻠﻋ ﻂﻘﻓ حﺎﺘﻣ ﺖﻧﺮﺘﻧﻹا

ﻊﻨﺼﻤﻟا تاداﺪﻋإ ﻰﻠﻋ ﻂﺒﺿ ةدﺎﻋإ

ﺮﻔﺻأ

ﺾﯿﻣوﺞﻣﺎﻧﺮﺒﻟا ﺚﯾﺪﺤﺗ ٍرﺎﺟ

ﺮﻤﺣأ

ﺾﯿﻣو

ﺖﺑﺎﺛ

ﮫﯿﺟﻮﺘﻟا زﺎﮭﺟ ﺪﯿﮭﻤﺗ ٍرﺎﺟ

ﺔﻗﺎﻄﺑ وأ SIM ﺔﻗﺎﻄﺑ ﻲﻓ ﺄﻄﺧ كﺎﻨھ وأ ةﺮﻓﻮﺘﻣ ﺮﯿﻏ ﺔﻣﺪﺨﻟا

ﺔﻠﻔﻘﻣ SIM

يﻮﻠﻋ ﺮﮭﻈﻣ

ﺔﯿﻠﺧاﺪﻟا ﻦﻛﺎﻣﻸﻟ 5G ﺔﯿﻨﻘﺘﺑ دوﺰﻤﻟا FG2000 ﮫﯿﺟﻮﺘﻟا زﺎﮭﺟ داﺪﻋﻹ تادﺎﺷرإ ﻞﯿﻟﺪﻟا اﺬھ ﺮﻓﻮﯾ

.ﮫﻨﯾﻮﻜﺗو ﮫﻠﯿﺻﻮﺗو

ﺔﯿﺑﺮﻌﻟا

ﺬﻓﺎﻨﻣ

*ﻲﺋاﻮﮭﻟا

ﺔﻗﺎﻄﺑ ﺔﺤﺘﻓ

SIM

ﻞﯿﻐﺸﺘﻟا فﺎﻘﯾإ/ﻞﯿﻐﺸﺗ WPS ﺔﻋﺮﺴﺑ LAN اﺬﻔﻨﻣ

ﺔﯿﻧﺎﺜﻟا ﻲﻓ ﺖﺑﺎﺠﯿﺟ 1

1 ﺔﻋﺮﺴﺑ WAN ﺬﻔﻨﻣ

ﺔﯿﻧﺎﺜﻟا ﻲﻓ ﺖﺑﺎﺠﯿﺟ

ﺔﻗﺎﻄﻟا ﺬﻔﻨﻣ

+ﻒﺗﺎھ ﺬﻔﻨﻣ

5 ﺔﻋﺮﺴﺑ LAN ﺬﻔﻨﻣ

ﺔﯿﻧﺎﺜﻟا ﻲﻓ ﺖﺑﺎﺠﯿﺟ

ﺰﺗﺮھﺎﺠﯿﺟ 6 ددﺮﺘﺑ ﺔﯿﻟﺎﻋ ﺔﯿﻋﺮﻓ تﺎﻗﺎﻄﻧ ﻢﻋﺪﺗ ﻲﺘﻟا ﺰﺗﺮھﺎﺠﯿﺟ 5و3.4 ﻦﯿﺑ حواﺮﺘﯾ ددﺮﺗ تاذ ﺔﯿﺟرﺎﺨﻟا ﻲﺋاﻮﮭﻟا ةﺰﮭﺟﻷ*

ﺔﯾرﺎﯿﺘﺧا ةﺰﯿﻣ+

ﻲﻔﻠﺨﻟا ﺀﺰﺠﻟاﺮﮭﻈﻣ

ﺔﯿﺑﺮﻌﻟا

•.زﺎﮭﺠﻟا ﻦﻣ ﻦﻤﯾﻷا ﺐﻧﺎﺠﻟا ﻰﻠﻋ SIM ﺔﻗﺎﻄﺑ تﺎﺤﺘﻓ ﻦﻋ ﺀﺎﻄﻐﻟا ﺔﻟازﺈﺑ ﻢﻗ

•لﺎﺧدﻹ ﺔﻨﻤﻀﻤﻟا SIM ةادأ مﺪﺨﺘﺳا ﺔﻗﺎﻄﺑ

.ﺀﺎﻄﻐﻟا ﺐﯿﻛﺮﺗ ﺪﻋأو ﺔﺒﺳﺎﻨﻤﻟا SIM ﺔﺤﺘﻓ ﻲﻓ Nano 4FF SIM

مﺪﻋ ﻰﻠﻋ صﺮﺤﻟا ﻊﻣ ،ﻲﻗاﻮﻟا ﺎﮭﻓﻼﻏ ﻦﻣ SIM ﺔﻗﺎﻄﺑ جﺮﺧأ ،ﺮﻣﻷا مﺰﻟ اذإ :

،ًﻻوأ SIM تﺎﻗﺎﻄﺑ ﻲﻓ ﺔﻋﻮﻄﻘﻤﻟا ﺔﻓﺎﺤﻟا ﻞﺧدأ .ﻲﺒھﺬﻟا نﻮﻠﻟا تاذ ﺲﻣﻼﺘﻟا طﺎﻘﻧ ﺲﻤﻟ.زﺎﮭﺠﻟا ﻦﻣ ﻲﻔﻠﺨﻟا ﺀﺰﺠﻟا ﺲﻣﻼﺘﻟا طﺎﻘﻧ ﮫﺟاﻮﺗ ﺚﯿﺤﺑ

•ﺪﻨﻋ كﺮﻓﺎﻇأ ﺪﺣأ ﻞﺧدأو رﺎﺴﯿﻟا ﻰﻟإ ﺔﯾرﺎﻄﺒﻟا ﺀﺎﻄﻏ كﺮﺣ ،زﺎﮭﺠﻟا ﻦﻣ ﻲﻠﻔﺴﻟا ﺀﺰﺠﻟا ﻲﻓ

.ﮫﻧﺎﻜﻣ ﻦﻣ ﮫﻌﻓﺮﻟ ﺔﻓﺎﺤﻟا

•.ﺀﺎﻄﻐﻟا ﻊﺿو ﺪﻋأو AA سﺎﻘﻣ تﺎﯾرﺎﻄﺑ ثﻼﺛ ﻞﺧدأ

•.ﺔﯿﻟﺎﺘﻟا ةﻮﻄﺨﻟا ﺀاﺮﺟﻹ FG2000 زﺎﮭﺟ ﻞﯿﻐﺸﺘﻟ ﻞﯿﻐﺸﺘﻟا رز ﻰﻠﻋ ﻂﻐﺿا

تﺎﯾرﺎﻄﺒﻟاو SIM ﺔﻗﺎﻄﺑ ﺐﯿﻛﺮﺗ :ﻰﻟوﻷا ةﻮﻄﺨﻟا

FG2000 زﺎﮭﺟ داﺪﻋإ

FG2000 زﺎﮭﺠﻟ ﻊﻗﻮﻣ ﺪﯾﺪﺤﺗ :ﺔﯿﻧﺎﺜﻟا ةﻮﻄﺨﻟا

•ةﺰﮭﺟﻸﻟ Inseego ﻖﯿﺒﻄﺗ ﻞﯾﺰﻨﺘﻟ ﺎًﯿﺋﻮﺿ ﺔﻌﯾﺮﺴﻟا ﺔﺑﺎﺠﺘﺳﻻا ﺰﻣر ﺢﺴﻣا

ةرﺎﯾﺰﺑ ﻞﻀﻔﺗ وأ Google Play وأ App Store ﻦﻣ ﺔﻟﻮﻤﺤﻤﻟا

.ﻖﯿﺒﻄﺘﻟا ﻞﯾﺰﻨﺘﻟ https://inseego.com/inseego-connect-get-app

•FG2000 زﺎﮭﺠﺑ ﻞﯿﺻﻮﺘﻠﻟ ﺔﻟﻮﻤﺤﻤﻟا ةﺰﮭﺟﻸﻟ Inseego ﻖﯿﺒﻄﺗ ﻲﻓ ةدﻮﺟﻮﻤﻟا تادﺎﺷرﻹا ﻊﺒﺗا

.FG2000 زﺎﮭﺠﻟ ﻲﻟﺎﺜﻤﻟا ﻊﻗﻮﻤﻟا ﺪﯾﺪﺤﺘﻟ ﻊﻗﻮﻤﻠﻟ عﻼﻄﺘﺳا ﺀاﺮﺟإو

.ﺖﺑﺎﺛ ﺢﻄﺳ ﻰﻠﻋ FG2000 زﺎﮭﺟ ﻊﺿو ﻦﻣ ﺪﻛﺄﺗ :

.ﻂﻘﻓ Nano SIM تﺎﻗﺎﻄﺑ ﻢﻋﺪﯾ زﺎﮭﺠﻟا اﺬھ

Mini 2FF ﺔﻗﺎﻄﺑ

ﺔﻗﺎﻄﺑ

Micro 3FF

Nano 4FF ﺔﻗﺎﻄﺑ
