Ink Bird IHT-2XP Manuel utilisateur
IHT-2XP
Digital Food Thermometer
With 2 External Probes
This instant-read food thermometer is designed with 2
sockets for external probes, in addition to a built-in probe.
Therefore, it’s available to measure temperature via 3
channels simultaneously. You can use it to measure
various food, such as steak, turkey, pork, chicken, fish,
and drinks, etc. It helps you cook at a precise tempera-
ture for each specific food, a good helper to create
perfect meals for your family and friends.
Product Name: Digital food thermometer with 2
external probes
Product Model: IHT-2XP
3 stainless steel probes for temperature measuring
Heat-resistant, waterproof probe cables
Temperature range of probes:-50.0℃ to 300℃(-58.0℉
to 572℉).
Measurement accuracy: ±0.5℃/±1.0℉
Readout time(Built-in Probe): 2 seconds
Auto-off/sleep mode
Clear backlit LCD screen
Selectable temperature units of ℃ and ℉
HOLD function to lock the measured temperature on
the LCD screen
ALARM function to alert you when the measured
temperature reaches the preset temperature for your
food
Temperature calibration range: -4.9℃～4.9℃/-9.9℉～
9.9℉
Waterproof to IPX5
Rechargeable lithium battery, more convenient to use;
It only takes 1 hour to get the battery fully charged
Easy to be stored with the attached hook and magnet
2-year product warranty
Overview
Features & Specifications
01
P1 P2
Product Diagram
02
➀ LCD Screen & Backlight
➁ HOLD/UP Button
➂ SET Button
➃ POWER/DOWN Button
1
56
7
8
23 4
P1
P2
8
➄ Probe 1/2 Sockets
➅ Battery Charge Port
➆ Built-in Probe
⑧ Magnetic Back
: Press and hold the button for 2 seconds to enter the
menu for function setting. During the setting process,
press the button to choose functions; press and hold the
button for 2 seconds to quit and save setting changes.
: Press the button to turn on the device. In normal
mode, press and hold the button for 2 seconds to turn off
the device. In setting mode, press the button to decrease
the value of parameters; long press the button to quickly
decrease the value of parameters.
: In normal mode, press the button to lock or unlock
the value of current temperature; press and hold the
button for 3 seconds to switch the display of 3 channels.
In setting mode, press the button to increase the value of
parameters; long press the button to quickly increase the
value of parameters.
Key Definition
Operation Instructions
Instruction Menu
03
CF
BEE
B LT
ALM
MENU
ITEMS DIS-
PLAY FUNCTIONS SETTING
RANGE DEFAULT
VALUES
Celsius / Fahrenheit
Key sound
Backlight active time
℃ or ℉ ℉
ON
10S
ON or OFF
5~60S
ON/OFF
Alarm function
for the built-in probe OFF
04
ON or OFF
-50.0℃~300℃
-58.0℉~572℉
Alarm value
for the built-in probe
Temperature
calibration
for the built-in probe
-4.9℃~4.9℃
-9.9℉~9.9℉
77.0℃
170℉
0.0℃
0.0℉
ON
ON or OFF
-50.0℃~300℃
-58.0℉~572℉
Alarm function
for the external
probe1
Alarm value
for the external
probe1
Temperature
calibration
for the external
probe1
-4.9℃~4.9℃
-9.9℉~9.9℉
77.0℃
170℉
0.0℃
0.0℉
ON
-50.0℃~300℃
-58.0℉~572℉
Temperature
calibration
for the external
probe2
Alarm value
for the external
probe2
Alarm function
for the external
probe2
-4.9℃~4.9℃
-9.9℉~9.9℉
77.0℃
170℉
0.0℃
0.0℉
ALM1
ALM2
CA1
TS1
CA2
TS2
TS
CA
Step 1: press and hold button for 2 seconds to enter
the menu for function setting, then press the button to
choose CF function.
Step 1: press and hold button for 2 seconds to enter
the menu for function setting, then press the button to
choose BEE function.
Step 2: press or button to choose ℃ or ℉.
NOTE: All parameters will be restored to their default
values once you change the temperature unit.
Step 3: press and hold button for 2 seconds to quit
and save changes. (All changes will be automatically
saved if there is no operation in 30 seconds.)
05
Parameter Setting Guide
Temperature Display Unit of ℃/℉
Key Sound
Step 2: press or button to choose ON or OFF.
Step 3: press and hold button for 2 seconds to quit
and save changes. (All changes will be automatically
saved if there is no operation in 30 seconds.)
Step 1: press and hold button for 2 seconds to enter
the menu for function setting, then press the button to
choose BLT function.
Step 2: press or button to decrease or increase
the value; long press or button to quickly
decrease or increase the value. (The active time of the
backlight is adjustable from 5 to 60 seconds.)
Step 3: press and hold button for 2 seconds to quit
and save changes. (All changes will be automatically
saved if there is no operation in 30 seconds.)
Step 1: press and hold button for 2 seconds to enter
the menu for function setting, then press the button to
choose ALM function.
06
Backlight Active Time
Alarm Function for the Built-in Probe
Step 1: press and hold button for 2 seconds to enter
the menu for function setting, then press the button to
choose TS function.
Step 2: press or button to choose ON or OFF.
Step 3: press and hold button for 2 seconds to quit
and save changes. (All changes will be automatically
saved if there is no operation in 30 seconds.)
Step 2: press or button to decrease or increase
the value; long press or to quickly decrease or
increase the value.
Step 3: press and hold button for 2 seconds to quit
and save changes. (All changes will be automatically
saved if there is no operation in 30 seconds.)
07
Alarm Value Setting for the Built-in Probe
Step 1: press and hold button for 2 seconds to enter
the menu for function setting, then press the button to
choose CA function.
Step 1: press and hold button for 2 seconds to enter
the menu for function setting, then press the button to
choose ALM1 function.
Step 2: press or button to decrease or increase
the value; long press or to quickly decrease or
increase the value.
Step 3: press and hold button for 2 seconds to quit
and save changes. (All changes will be automatically
saved if there is no operation in 30 seconds.)
When the current temperature is 75.5℉, the screen
displays 75.8℉ after setting the CA value as 0.3℉.
08
Temperature Calibration for the
Built-in Probe
Alarm Function for P1
(the External Probe 1)
Step 1: press and hold button for 2 seconds to enter
the menu for function setting, then press the button to
choose TS1 function.
Step 2: press or button to decrease or increase
the value; long press or to quickly decrease or
increase the value.
Step 3: press and hold button for 2 seconds to quit
and save changes. (All changes will be automatically
saved if there is no operation in 30 seconds.)
Step 2: press or button to choose ON or OFF.
Step 3: press and hold button for 2 seconds to quit
and save changes. (All changes will be automatically
saved if there is no operation in 30 seconds.)
09
Alarm Value Setting for P1
(the External Probe 1)
