User Guide

ReXgen1 - Manual

ReXgen 1: Product Manual

ABOUT THIS MANUAL

This document provides a brief idea of the usage, safety precautions, installation procedures and

operation of the Influx ReXgen1. This document is intended for professional engineers and academic

researchers, allowing them to understand the concept of operating the device and integrate this

knowledge into systems with components of other manufacturers.

DISCLAIMER

Translation of the original Product Manual ReXgen1.

Version

Date

Remarks

1.0

26-10-2022

First official version

Table 1: Version Details

The content of this document, including all brands and trademarks and possibly protected by third-party

rights, are subject without limitation to the terms of the valid trademark law and intellectual property

rights of their respective registered owner.

CONTACT ADDRESS

Influx Technology Ltd

Office 22, Building 03, Millbrook Proving Ground

Bedford, MK45 2JQ, United Kingdom

Telephone: +44 (0) 1525 842504,

Sales: sales@influxtechnology.com

Support: support@influxtechnology.com

www.influxtechnology.com

ReXgen 1: Product Manual

SAFETY INSTRUCTIONS

▪Ensure that the device is installed, connected, and commissioned by a qualified professional following all

safety norms.

▪Disconnect the device completely before handling it and disconnect any independently supplied output load

circuits.

▪Do not connect the housing to the Ground externally. This will suspend the reverse voltage protection of the

power supply. Applying a reverse voltage, in this case, will destroy the supply circuits.

▪Provide all the device connectors with plugs and any protection caps required to ensure protection class IP65.

▪Never immerse the device in water or other liquids.

▪The manufacturer must only repair the device.

▪Keep substances that contain solvents away from the type label.

The following formatting and symbols will help you recognise the purpose of each paragraph:

Severe injury or death. Probability: Possible

Slight or medium injury. Probability: Possible

Property damage

WARNING

CAUTION

ATTENTION!

Notes

•Important usage instructions/notes/limits.

ReXgen 1: Product Manual

Table of Contents

ABOUT THIS MANUAL.........................................................................................................................................................1

DISCLAIMER........................................................................................................................................................................1

COPYRIGHT & LICENSE AGREEMENT...................................................................................................................................1

CONTACT ADDRESS.............................................................................................................................................................1

SAFETY INSTRUCTIONS .......................................................................................................................................................2

1. OVERVIEW OF THE DEVICE..................................................................................................................................4

1.1 GENERAL INFORMATION ..................................................................................................................................6

1.1.1 DEVICE ELEMENTS......................................................................................................................................6

1.1.2 PRODUCT DRAWINGS ...............................................................................................................................6

1.1.3 TECHNICAL SPECIFICATION ......................................................................................................................7

1.1.4 ELECTRICAL DATA ......................................................................................................................................7

2. HARDWARE & FUNCTIONALITY...........................................................................................................................9

2.1 FUNCTIONS ...............................................................................................................................................................9

2.1.1 RECORDING CAN DATA.............................................................................................................................9

2.1.2 Functioning as a PASS-THRU device using J2534:.......................................................................................9

2.2 HARDWARE ........................................................................................................................................................9

2.2.1 INSTALLATION ...........................................................................................................................................9

2.2.2 ENCLOSURE..............................................................................................................................................10

2.2.3 LED............................................................................................................................................................10

2.2.4 CABLES......................................................................................................................................................11

2.2.4.1 CONNECTOR PIN DETAILS...........................................................................................................................11

2.2.5 ACCESSORIES ..................................................................................................................................................11

3. GETTING STARTED ............................................................................................................................................12

3.1 CONNECTING THE DEVICE..............................................................................................................................12

3.1.1 POWER .....................................................................................................................................................12

3.1.2 CAN...........................................................................................................................................................12

3.1.3 USB ...........................................................................................................................................................12

3.2 SOFTWARE INSTALLATION .............................................................................................................................13

3.3 DRIVER INSTALLATION....................................................................................................................................15

3.4 ReXgen1 as a J2534 tool ...................................................................................................................................17

3.5 FIRMWARE UPDATE..............................................................................................................................................17

4 ANNEXURES ......................................................................................................................................................18

4.1 CAN OVERVIEW ...............................................................................................................................................18

ReXgen 1: Product Manual

1. OVERVIEW OF THE DEVICE

This chapter overviews the ReXgen1 device and explains its operating procedures, functions, and

intended use in detail.

Along with the free, user-friendly configuration software, the standalone ReXgen1 pass-thru

device and logger comes with the following advantages:

•Supports 1xCAN bus.

•Functions as an interface device and supports J2534 (Pass-thru).

•Supports live CAN monitoring RAW CAN signals, SAE J1939.

•Secure data storage with an 8 GB internal eMMC.

•Sleep modes with wake-up on CAN, with low power consumption.

•Encrypts data logs using Advanced Encryption Standard (AES).

•Enables Locking of the device using RSA data security.

•Open Libraries for logger management and data conversion.

•XML-based configuration, Schema provided.

•Supported Data formats ASAM MDF4, MATLAB (.mat), CSV, ASC, BLF, TRC*.

•Advanced trigger & filter conditions.

•Advanced CAN-Bit timing configuration.

•x1 LEDs indication to show the status of logging.

•Tolerable to harsh environments with an IP65 rating.

•Easy mounting.

ReXgen 1: Product Manual

•Free powerful graphic interface application tool ReXdesk provided.

•Micro USB 2.0 PC interface.

•CAN error logging.

•An extreme level of compactness –pocket size.

Available Models

Model

eMMC Storage

CAN

INF2109

8 GB

ReXgen 1: Product Manual

1.1 GENERAL INFORMATION

1.1.1 DEVICE ELEMENTS

1 –Micro USB connector.

3 –Mounting Holes.

2 –CAN LED.

4 –Channel Connector.

1.1.2 PRODUCT DRAWINGS

ReXgen 1: Product Manual

1.1.3 TECHNICAL SPECIFICATION

Functions

ReXgen 1

CAN Interfaces

1 x CAN

ISO 11898-1: Compliant with CAN (up to 1 Mbit/s)

Conforms to CAN protocol version 2.0 –part A, B Max 20000 mps

Meets the requirements of

ISO 11898-2:2016 & ISO 11898-5:2007 physical layer standards

PC Interfaces

Rugged Micro USB 2.0

(Datalogger mode and J2534)

Data Storage Capability

8 GB Inbuilt eMMC storage

Supported Protocols

CAN Monitoring

(RAW CAN signals, SAE J1939 support)

LEDs

Triggering

Trigger on a CAN ID

Trigger on Parameter Value

Trigger on DM1 J1939 counter.

Data Storage Format

FAT32, Log files accessible via ReXdesk Software and API

File Format Supported

ASAM MDF (.mf4), CSV, MATLAB, ASC, BLF

Data Logger Configuration

Supplied with Influx ReXdesk configuration software, XML based

1.1.4 ELECTRICAL DATA

BUS & Signals

Operating Voltage

Power supply - OBD

+4.5 to +31V

Power supply - USB

+4.5 to +5.5V

Function

Description

Transceiver Protection

Bus fault protection: ±58 V Thermal-shutdown protection (TSD)

Under-voltage protection

Enclosure

PC+ ABS

IP Rating

IP65

Dimension

L - 100 mm, W - 73.5 mm, H –27.4 mm

Weight

164 Grams

Mounting Holes

Four mounting holes and screws

Environmental Tolerance

Working temperature -40degC to +85degC;

Humidity max 90%

Power Saving

Wake Up On CAN, Power Down Mode, Sleep Modes

Power Consumption

Normal Operation: 87 mA at 12 V

Power Down Mode: <2 mA

ReXgen 1: Product Manual

1.1.5 INTENDED USE

The ReXgen1 is one of the most compact, pocket-sized pass-thru devices, which is also a data

logger suitable for automotive and various industrial applications.

The device is designed to:

•Support J2534 (Pass-thru).

•Logs data continuously for hours from a CAN bus.

•Saves your data to the embedded SD memory card.

Rexgen1 device tolerates all harsh environments that require IP65 class protection. It can be

easily mounted and integrated with your vehicle /machine.

1.1.6 LIABILITY & WARRANTY

Influx Technology assumes no liability for damages caused by normal wear, installation errors,

or operating or maintenance faults. This is also applicable when the user modifies the devices,

any accessories, or the Software without the prior approval of Influx Technology.

1.1.7 CONFORMITY

For detailed information on the respective tests, see Chapter Certifications.

The device meets the following standards and legal requirements:

1.2 DEVICE KIT

1.2.1 HARDWARE

Packaging will contain the following components:

INF 2109

▪1x ReXgen1

▪1x Micro USB Cable

1.2.2 SOFTWARE

ReXgen1 device will be supplied with a freely distributed configuration and data retrieval

software, ReXdesk. The Software can be downloaded from our website,

www.influxtechnology.com.

1.3 SERVICE & SUPPORT

Please visit the support section on our website https://www.influxtechnology.com/support

The latest versions of the drivers, Software, firmware, and documentation are available.

ReXgen 1: Product Manual

2. HARDWARE & FUNCTIONALITY

This chapter will provide information on the device's functionality and hardware.

2.1 FUNCTIONS

FUNCTION

ReXgen1

CAN Logging

Yes

J2534 Pass-Thru

Yes

Table 1: Device Functions

2.1.1 RECORDING CAN DATA

The device can effectively field log data on tests and a bench via the 1xCAN interface. The device

supports all standard CAN baud rates. ReXdesk software allows users to configure ReXgen1 with

custom baud rates and modify advanced bit timings. ReXdesk also allows the user to configure

ReXgen1 with CAN & J1939 filters. All logged data is saved to the secure embedded memory.

The user can configure triggers based on CAN IDs, parameter values &J1939 DM1 messages to

start or stop logging.

2.1.2 Functioning as a PASS-THRU device using J2534:

ReXgen1 is designed to function not just as a data logging device but also as a capable pass-thru

device. The communication protocols supported by ReXgen1 as a J2534 tool are; ISO14229,

ISO14230, CAN (ISO11898), ISO15765, and J1939.

It allows the users to connect to the vehicle CAN Bus using the Pass-Thru API (Application

Program Interface), enabling you to create programs that accomplish your vehicle

communication needs. The pass-thru feature is already supported by Influx Module Analyser,

SavvyCAN and K-Cal Software.

2.2 HARDWARE

2.2.1 INSTALLATION

The contents below specify the conditions to be ensured for the operation of ReXgen1.

GROUNDING

Since it is not required to provide a common ground between nodes, it is possible to have ground

offsets between nodes. Each node may observe different single-ended bus voltages (common

mode bus voltages) while maintaining the same differential voltage. Operating a CAN system with

large ground offsets can increase electromagnetic emissions. If the system is sensitive to

emissions, steps must be taken to eliminate ground offsets.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Influx Technology Enregistreur de données

Influx Technology

Influx Technology ReXgen Manuel utilisateur

Influx Technology

Influx Technology ReXgen 2 Manuel utilisateur

Influx Technology

Influx Technology ReXgen Manuel utilisateur

Manuels Enregistreur de données populaires d'autres marques

TESTO

TESTO 176 Manuel utilisateur

HT Italia

HT Italia XL421 Manuel utilisateur

HBM

HBM SOMAT XR CX22B-R Manuel utilisateur

Agtrix

Agtrix 380i Manuel utilisateur

Hobo

Hobo H8 Pro Manuel utilisateur

Beijing ART Tech

Beijing ART Tech PCI2320 Manuel utilisateur

Athena

Athena GET SL1 Manuel utilisateur

Motec Systems

Motec Systems C185 Manuel utilisateur

Beijing ART Tech

Beijing ART Tech USB2832 Manuel utilisateur

Rotronic

Rotronic HygroLog HL20 Manuel utilisateur

MRC

MRC DW-6092 Manuel utilisateur

Racelogic

Racelogic VBOX LapTimer Manuel utilisateur

Edu-Logger

Edu-Logger 900-240 Manuel utilisateur

Elma

Elma DT173 Manuel utilisateur

MadgeTech

MadgeTech PRTemp140 Fiche technique

Comet

Comet U0121M Manuel utilisateur

pico Technology

pico Technology PT-104 Manuel utilisateur

Soil Instruments

Soil Instruments GTecLink Manuel utilisateur
