STEP 1: Mounting the Cells
The Infinitybox system is a modular, multiplexed wiring system. This means that there are
multiple remote cells that are mounted in the car where you need them.
The MASTERCELL connects to your switches. You will mount that close to your switches.
The MASTERCELL is also your main diagnostics tool for the system. You should locate it in
the vehicle where you can get reasonable access to view the inSIGHT screen, remove the
cover and push the buttons under the cover. You should also mount the MASTERCELL in a
location where you can easily plug and unplug the harnesses for maintenance.
The POWERCELLs control your loads (headlights, cooling fans, ECU power, starter
solenoid, horn and other switched accessories). In most installations, you will mount one
POWERCELL in the front of the car and one POWERCELL in the rear. The POWERCELL
holds the fuses that protect the wires in your harness. You need to have access to the
POWERCELL to be able to change fuses if they ever were to open. You should also mount
the POWERCELL in a location where you can easily plug and unplug the harnesses for
maintenance.
The difference between the Infinitybox 10 and 20 Circuit Kits is the number of
POWERCELLs included in the kit. Each POWERCELL has 10 outputs. The 10-Circuit Kit
comes with one POWERCELL and the 20-Circuit Kit comes with 2 POWERCELLs.
The POWERCELLs are designed to be mounted under the hood. They were designed and
tested to survive the extreme temperatures, chemicals and vibrations found in the engine
compartment. The one warning with mounting POWERCELLs under the hood is to keep
them clear of exhaust headers and ignition coil wires.
The mounting locations are identical for all the Infinitybox cells. This includes the
MASTERCELL, POWERCELL and inMOTION Cell. The mounting points were designed for a
¼” stud, ideally a 5/8” long shoulder screw. You can use any mounting hardware that you
choose. Take care not to crush the mounting points by over-tightening the hardware.
The POWERCELLs carry all the electrical current in your system. They are designed to
carry up to 125-amps continuously per cell. In most applications, you can mount them
anywhere in the vehicle in any orientation. If your continuous current draw through a
POWERCELL will exceed 80-amps, it is recommended that the POWERCELL be in an open
area with free air flow. The POWERCELL should be mounted with the fins on the heat sink
oriented vertically. Contact our technical support group with questions on current usage
and mounting.
