Infinity Reference 2000.6 Manuel utilisateur

Technical Manual

Reference 2000.6

ACOUSTIC & ELECTRICAL SPECIFICATIONS

•Nominal Impedance 8 ohms

•Max Amp Power 200 watts

•Frequency Response 35Hz – 20kHz

•Sensitivity 92 dB SPL, 1 watt @ 1 meter

•Crossover Frequency 3600Hz

SYSTEM COMPONENTS:

•Cabinet (Black Ash) 331046-001 (Not for sale)

(Cherry) 331046-002 (Not for sale)

•Grille (Upper) 333204-001

(Lower) 330976-001

•Low Frequency 6 1/2” (160mm) Co-injected

Transducer woofer, shielded 330617-002

DC Resistance 7.2 ohms ±10%

• High Frequency 1” (25mm) Neodymium

Transducer Soft Dome 333232-001

SYSTEM COMPONENTS: (cont.)

DC Resistance 4.0 ohms ±10%

•Crossover Network 331103-003

AURAL SWEEP TEST SPECIFICATIONS:

•System Aural Sweep Test 6.0V Input 20 Hz to 20 kHz

•L.F. Aural Sweep Test 6.0V Input 20 Hz to 4kHz

•H.F. Aural Sweep Test 2.0V Input 3kHz to 20 kHz

PHYSICAL SPECIFICATIONS

•Enclosure dimensions: 40” x 7 1/2” x 14 3/8” (H x W x D)

(1016 x 190 x 365mm)

SHIPPING WEIGHT:

• 40.4 lbs. (18.1 kg) Each

WARRANTY:

• Refer to Warranty Statement packed with each product.

Owner's Manual

331351-001

Spiked Foot Set

331360-001

Survey Card

330033-001

Top Foam

331081-001

Bottom Foam

331082-001

OWNER'S

MANUAL

Outer Carton

331083-001

;;;

yyy

;;

;;;

yyy

;;

PACKAGING

Driver

High Frequency

333232-001

Driver(2)

Low Frequency

330617-002

Blue

Black

Red/Black

Red

331103-003

Network

WIRING DIAGRAM

0.65 mH

30.0 mfd

50V

20.0 mfd

100V

2.00 ohm

0.40 mH

35" RED

35" RED/BLACK

17" RED

17" RED/BLACK

34" BLUE

32" BLACK

+LF

–LF

+HF

–HF

250

+LF

250

–LF

205

110

205

R3 (–002 ONLY)

10.0 ohm 5W

0.20 mH

3.3 ohm 5W

3.3 mfd

100V

+IN

–IN

INPUT

2000.6 SCHEMATIC

9-98

Infinity Systems, Inc. 250 Crossways Park Dr., Woodbury, New York 11797

331109-001

Front baffle

331119-001

Kick Baffle

333232-001

1" Tweeter

333204-001

Grille Assembly

Cabinet (Not for Sale)

Black Ash 331046-002

Cherry 331046-002

330834-001

Tweeter Cup

63563 (4)

#6 x 3/4 PPH

Screw

905502-004 (2)

#4-40x1/4 PPH Zinc.

Screw

331121-001

Base Front Foot

331075-002

Rear Base Assembly

331723-001

Red Terminal

331724-001

Black Terminal

330617-002

Woofer

63563 (4)

#6 x 3/4 PPH

331875-001 (2)

Grille Gasket

331296-001

Logo

+ IN

— IN

35" RED/BLACK

35" RED

34" BLUE

32" BLACK

Acoustic Filter

(Not for Sale)

330976-001

Bottom Grille

Port Tube

(Not for sale)

Screws (10)

900101-016

331103-003

Crossover Network

Screws (3)

900101-016

COMPONENT EXPLODED VIEW

Reference 2000.6

SERVICE NOTE:

For access to the drivers the front baffle must be

removed (4 screws).

Reference 2000.6

9-98

Infinity Systems, Inc. 250 Crossways Park Dr., Woodbury, New York 11797
