Operating Manual

D-TEK Stratus®

Refrigerant Leak Detector and Portable Monitor

English · Español · Deutsch · Français · Italiano · 中文 ·日本語 · Pyccĸий·

Polski · Svenska · Türkçe · Nederlands · 한국어

074-708-P16B

EA705EJ-30

INFICON

2 074-708-P16B D-TEK Stratus Operating Manual

English .................................................................................................................... 3

Español................................................................................................................... 34

Deutsch................................................................................................................... 66

Français.................................................................................................................. 99

Italiano .................................................................................................................... 132

中文 ......................................................................................................................... 163

日本語 ..................................................................................................................... 190

Pyccĸий .................................................................................................................. 218

Polski....................................................................................................................... 251

Svenska.................................................................................................................. 282

Türkçe..................................................................................................................... 312

Nederlands............................................................................................................. 343

한국어 ..................................................................................................................... 375

INFICON Table of Contents

074-708-P16B D-TEK Stratus Operating Manual 3

Table of Contents

1 Declaration of Conformity.................................................................................................................................4

2 Cautions and Warnings ....................................................................................................................................5

3 Specifications ...................................................................................................................................................6

4 D-TEK Stratus ................................................................................................................................................10

5 What is Cloud Hunting?..................................................................................................................................12

6 Charging the Battery.......................................................................................................................................13

7 Turning On the Instrument and Preparing for Use .........................................................................................14

8 Screen Layout and Symbols...........................................................................................................................15

9 Cloud Hunting (Portable Monitor) Mode.........................................................................................................17

10 Pinpoint Mode.................................................................................................................................................19

11 Manual Zero Mode .........................................................................................................................................20

12 Earbuds and Volume Control .........................................................................................................................21

13 Removing and Installing the Lithium Ion Battery ............................................................................................22

14 Removing and Installing the Sensor...............................................................................................................23

15 Replacing Filters.............................................................................................................................................24

16 Extra-long Probe.............................................................................................................................................25

17 Needle Probe Extension.................................................................................................................................26

18 Optional Sensors............................................................................................................................................27

19 Cleaning and Storage.....................................................................................................................................28

20 Replacement Parts and Accessories..............................................................................................................29

21 Troubleshooting Guide ...................................................................................................................................30

22 Warranty and Liability-Limitation ....................................................................................................................32

23 Returning the Instrument for Warranty or Repair ...........................................................................................33

1 | Declaration of Conformity INFICON

4 / 405 074-708-P16B D-TEK Stratus Operating Manual

1 Declaration of Conformity

English

INFICON Cautions and Warnings | 2

074-708-P16B D-TEK Stratus Operating Manual 5 / 405

2 Cautions and Warnings

Cautions:

• Only use a certified charger/cord with an output of 5 V (dc) ±5%, 1 A ±5%.

• Keep the device out of extremely high or low temperature locations.

• Do not expose the battery to liquid.

• Do not use the device if you notice any damage to the battery.

• Do not disassemble or modify the battery.

• Handle and dispose of the battery per local regulations.

• If the recharging operation fails to complete, even when the specified recharging

time has elapsed, immediately stop further recharging.

• Do not leave the battery unattended while charging.

• Unplug the charger when the battery is fully charged.

• Improper use or disposal of lithium ion batteries can cause a fire.

• High RF environments may cause a false alarm.

WARNING

This symbol alerts the user to the presence of important operating and

maintenance (servicing) instructions.

WARNING

Exposure to high concentrations of CO2 or refrigerants is dangerous and can

be life-threatening.

The instrument is not for use in toxic or hazardous environments. It is not a personal

protection or life-saving device. Always exercise extreme caution in potentially toxic or

hazardous environments.

WARNING

This product is not intrinsically safe and should not be used in the presence of

explosive fumes, explosive dust, or other explosive chemicals. Use in an

environment with flammable refrigerant concentration approaching the LEL

could cause an explosion or fire resulting in serious injury, death, or damage

to property.

English

3 | Specifications INFICON

6 / 405 074-708-P16B D-TEK Stratus Operating Manual

3 Specifications

Usage indoor/outdoor

Sensor type infrared

Compatible refrigerants

• Refrigerant sensor (standard, PN

724-701-G1)

All CFCs, HCFCs, HFCs, HFOs, and

blends (including A2Ls)

• CO2 sensor (PN 724-701-G2) R744 (carbon dioxide)

• Flammable refrigerant (HC) sensor

(PN 724-701-G3)

R290, R600a, R441a (see safety

warnings)

Minimum sensitivity (Pinpoint mode,

Super sensitivity)

0.03 oz/yr (1 g/yr)1

Display resolution (Cloud Hunting mode) 1 ppm

Display range (Cloud Hunting mode) 0 to 9999 ppm

Accuracy (Cloud Hunting mode, with

clean air reference, R134a)

±1 ppm ±10% of reading

Battery type lithium ion

Charging input type micro USB

Charging time (starting at 0%) approximately 3 hours

Battery life approximately 8 hours (Cloud Hunting)

approximately 10 hours (Pinpoint)

Input voltage 5 V (dc) ±5%

Input current 1 A ±5%

Warm-up period 45–90 seconds

Temperature ranges and humidity

• Storage -20–60°C (-4–140°F)

• Operating2-20–50°C (-4–122°F)

• Charging 0–45°C (32–113°F)

• Humidity 95% RH NC maximum

Altitude 2000 m (6500 ft.)

Pollution degree 2

Overvoltage category 2

Weight (with battery; not including

carrying case or accessories)

1.10 lb. (0.50 kg)

1 To achieve optimal performance and the specified sensitivities, it is recommended to

allow D-TEK Stratus to run for 15 minutes prior to use.

English

INFICON Specifications | 3

074-708-P16B D-TEK Stratus Operating Manual 7 / 405

2 Use in temperatures below 0°C (32°F) should be limited. Extended warm-up time is

recommended before use in low temperature environments.

Specification table in accordance with EN 14624

R134a R1234yf

Minimum sensitivity, fixed (static) 1 g/yr. 0.5 g/yr.

Maximum sensitivity, fixed (static)3>50 g/yr. >50 g/yr.

Minimum sensitivity, moving (dynamic) 1 g/yr. 1 g/yr.

Maximum sensitivity, moving (dynamic)3>50 g/yr. >50 g/yr.

Minimum response/detection time < 1 s < 1 s

Zeroing time 1–4 s 1–4 s

Recovery time for 50 g/yr exposure47.6 s 6.4 s

Minimum sensitivity in contaminated

environment

>2 g/yr. 1 g/yr.

Calibration frequency Check annually with calibrated leak

standard

3 The upper leak detection limit is not specified by INFICON as there is no upper limit

to the size of the leak the detector is able to detect.

4As no 50 g/yr. leak standard was available during testing, a 32 g/yr leak standard was

substituted.

SAE Applications SAE standards J2791 (R-134a) and J2913 (R-1234yf) specify sensitivity to the

following leak sizes for the corresponding settings below. Super sensitivity is more

sensitive than what is required by SAE for leak checking in a clean environment (free

of background refrigerant). If leak checking in a contaminated environment (high

background refrigerant), switch to Super sensitivity.

R-134a leak rate (g/yr) R-1234yf leak rate (g/yr) Sensitivity Setting

14 14 low

7 7 medium

4 4 high

The following table lists some common under-hood chemicals and indicates whether

or not they will cause a false-trigger from D-TEK Stratus.

Chemical False-Trigger

Windshield washer solvent (methanol base) yes

Ford® spot and stain remover yes

Ford rust penetrant and inhibitor yes

Ford gasket and trim adhesive yes

Permatex® natural blue cleaner and degreaser yes

English

3 | Specifications INFICON

8 / 405 074-708-P16B D-TEK Stratus Operating Manual

Chemical False-Trigger

Ford brake parts cleaner yes

Ford spray carburetor tune-up cleaner yes

Ford clear silicon rubber yes

Motorcraft® G-05 antifreeze/coolant no

Gunk® liquid wrench no

Ford pumice/lotion hand cleaner no

Ford Motorcraft DOT3 brake fluid no

Ford silcon lubricant no

Dexron® automatic transmission fluid no

Mineral engine oil no

SAE recommended

leak test procedure

Always leak test with the engine off.

Charge the system with sufficient refrigerant to have a gauge pressure of at

least 340 kPa (50 psi) with the system off. At ambient temperatures below 15 °C

(59 °F) leaks may not be measurable because the pressure may not be

reached.

Visually trace the entire refrigerant system, and look for signs of air conditioning

lubricant leakage, damage and corrosion on all lines, hoses and components.

Check each questionable area with the detector probe, as well as all fittings,

hose-to-line couplings, refrigerant controls, service valves with caps in place,

brazed or welded areas, and areas around attachment points and hold-downs

on lines and components. If looking for an apparently larger leak, check first at

the medium (7 g/year) or low (14 g/year) sensitivity setting.

Always follow the refrigerant system around in a continuous path so that no

areas of potential leaks are missed. If a leak is found, always continue to test

the remainder of the system.

Recheck the service valves with the caps removed. Blow shop air over the

service valve to clear the immediate area. Check with a detector on the medium

sensitivity setting (7 g/year).

Move the detector at a rate of no more than 75 mm/s (3 in./s) and as close as

possible to 9.5 mm (3/8 in.) from the surface, completely encircling each test

position (switch, sensor, refrigerant tubing connection, etc.).

English

INFICON Specifications | 3

074-708-P16B D-TEK Stratus Operating Manual 9 / 405

Slower movement and closer approach of the probe normally improves the

likelihood of finding a leak. However, detectors made to meet this standard are

based on air sampling from the 9.5 mm (3/8 in) distance. A retest is advisable

when a leak appears to be found at the most sensitive settings, particularly if the

probe was in a static position on a joint, or making physical contact with a joint,

as it was moving. Repeat with a moving probe test at that location, taking care

to maintain the small gap (9.5 mm or 3/8 in.) to confirm that the leak is of

repairable size. Checking with the medium sensitivity setting (7 g/year) after

finding an apparent leak with the high sensitivity setting (4 g/year) also may be

helpful.

Patents (Pending) • Application #10 2018 206 877.1

• Application #18171080.7

• Application # 10 2018 208 826.8

English

4 | D-TEK Stratus INFICON

10 / 405 074-708-P16B D-TEK Stratus Operating Manual

4 D-TEK Stratus

MODE button

SENS/ZERO

button

eject button

exhaust port (do not block)

battery door

English

Table des matières

Autres manuels Inficon Capteur de sécurité

Inficon

Inficon Contura S600 Guide rapide

Inficon

Inficon D-TEK 3 Manuel utilisateur

Inficon

Inficon D-TEK CO2 Manuel utilisateur

Inficon

Inficon HLD6000 Manuel utilisateur

Inficon

Inficon IRwin S Manuel utilisateur

Inficon

Inficon D-TEK Select Manuel utilisateur

Inficon

Inficon ELT3000 Guide rapide

Inficon

Inficon Contura S400 Guide rapide

Inficon

Inficon Sion Manuel utilisateur

Inficon

Inficon ULTRATEST UL3000 Fab Guide rapide

Inficon

Inficon TEK-Mate Manuel utilisateur

Inficon

Inficon IRwin Series Manuel utilisateur

Inficon

Inficon Southern Cross IRwin Manuel utilisateur

Inficon

Inficon HLD6000 Manuel utilisateur

Inficon

Inficon GAS-Mate Manuel utilisateur

Inficon

Inficon XL3000flexRC Guide rapide

Inficon

Inficon UL6000 Fab Guide rapide

Inficon

Inficon Sensistor Sentrac Mode d'emploi

Inficon

Inficon Sensistor ISH2000 HySpeed Manuel utilisateur

Inficon

Inficon D-TEK 3 Manuel utilisateur

Inficon

Inficon Ecotec E3000 Manuel utilisateur

Inficon

Inficon UL6000 Fab Guide rapide

Inficon

Inficon Pernicka 700H CHLD Guide rapide

Inficon

Inficon IRwin Manuel utilisateur

Manuels Capteur de sécurité populaires d'autres marques

THORLABS

THORLABS PDA10JT Manuel utilisateur

Waeco

Waeco UV-DETECT Manuel utilisateur

Intermatic

Intermatic IOS-DSIMF Manuel utilisateur

urmet domus

urmet domus 1083 Manuel utilisateur

Siemens

Siemens AZL66 Series Manuel utilisateur

BTI

BTI Profiline Multi Finder Manuel utilisateur

Challenger

Challenger SL01 Manuel utilisateur

DMP Electronics

DMP Electronics 1122INT Manuel utilisateur

Rielta

Rielta Ladoga MK-RK Manuel utilisateur

Mirion Technologies

Mirion Technologies ACCURAD PRD Manuel utilisateur

Bosch

Bosch DS835 Manuel utilisateur

DBI SALA

DBI SALA EZ Stop Manuel de l'opérateur

Lamptime

Lamptime ST05C Manuel utilisateur

Ubiquiti

Ubiquiti MFI-MSC Manuel utilisateur

Subsite

Subsite 910R Instructions d'installation

Satel

Satel OPAL Pro Manuel utilisateur

Aleph

Aleph XC-1XTEU Manuel utilisateur

Pima

Pima LARIS QUAD Manuel utilisateur
