Installation Instructions
WARNING: Before starting the installation,
please refer to the Safety Information section.
• Always switch the power o prior to
beginning the installation.
• Stainless steel is very easily damaged during
installation.
• Wherever possible, protect the rangehood
with the cardboard box or plastic
• A power point must be located within 1.5m
of the power cord exit from the rangehood,
and it should be always accessible to allow
isolation from power during cleaning or
maintenance.
• A 150mm round ducting adapter is supplied,
however all other ducting accessories are not.
• All ducting must comply with building codes
and local requirements.
• Ensure that the rangehood is mounted in a
level position, both horizontally and vertically.
This is essential to ensure the rangehood
operates correctly and prevents grease build
up at one end.
IMPORTANT: Never use a silicone around your
rangehood or ue pieces. Never install the
rangehood or ue pieces into the plaster ceiling
which prevents easy access to the rangehood for
servicing requirements.
IMPORTANT: Before installing your rangehood,
please record the details of your rangehood’s
rating label (located within the rangehood,
behind the aluminium grease lters) into the form
on page 15. This will be helpful should you need
to contact our service team in the future.
DUCTED INSTALLATION
Before beginning the installation of your
rangehood, consider your ducting method.
This rangehood has been supplied with
expandable plastic ducting, however for
maximum performance we recommend installing
with rigid or semi rigid ducting. Use cable ties or
suitable duct tape to secure the exible pipe or
ducting to the rangehood duct outlet.
WARNING: All ducting must be re retardant.
Depending on your situation, there are multiple
options for ducting your rangehood, as follows:
• Straight up through your tiled or metal
roof, using a roof cowl (not supplied with
the rangehood).
• Into your ceiling cavity (where compliant
with local and national building
regulations/codes. Seek approval from the
relevant authority or building inspector
where necessary.
• Into your ceiling cavity and then vented to
the atmosphere through your eaves, using
no more than 2 × 90 degree bends within
the ducting run.
• Through your wall.
IMPORTANT: Ducting can have a major eect on
your rangehoods performance. The following tips
outline how to correctly duct your rangehood.
• Always use the correct size ducting.
This rangehood is designed for use with
150mm ducting to achieve optimum airow
performance and minimised noise.
• For maximum performance use semi rigid or
rigid ducting
• Always use non-ammable ducting
• Always duct to the outside atmosphere,
unless your local building codes and
regulations permit otherwise
