IN-COMMAND NCS40T Manuel utilisateur

™

Patent # US 9,679,735

NCS40T

Trailer Control and Monitoring system

Installation and Operation Manual

NCS40T

Read the iN-Command Manual, and these warnings and instructions carefully before using this product. Failure to follow the use

instructions in this owner’s manual, or improper use of the Mobile Application, Display Commander and/or Body Control Module, could

result in personal injury, including death.

Do not operate while vehicle is being driven.

The Mobile Application, Display Commander and/or Body Control Module should not be used while the vehicle is being driven. Use of

the Mobile Application, Display Commander and/or Body Control Module while the vehicle is being driven is dangerous and may cause

personal injury or property damage.

For adult use only.

The Mobile Application, Display Commander and Body Control Module are intended for adult use only, and are not to be used by persons

under the age of 18. Use by children may cause personal injury or property damage.

Operate only when you have a clear line of sight.

Do not operate any moving parts (including, but not limited to, awnings, jacks and slides), unless you have a clear line of sight to the

moving part. The Mobile Application, Display Commander or Body Control Module may be used only if you are giving instructions to,

and receiving instructions from, another person at least age 18 or older who can clearly see the moving part. Failure to follow these

instructions may result in serious personal injury or property damage.

Do not operate under the inﬂuence of alcohol or drugs.

Do not operate the Mobile Application, Display Commander or Body Control Module while under the inﬂuence of alcohol or drugs.

Doing so may result in personal injury or property damage.

Avoid moisture.

To reduce the risk of ﬁre or electric shock, do not expose this equipment to rain or moisture.

Use recommended accessories.

To reduce the risk of ﬁre or electric shock and annoying interference, use only the recommended accessories.

Important Safety Information

NCS40T

Introduction ..............................................................................5

Thank You! .........................................................................5

Feature Description ...........................................................5

Precautions ........................................................................5

Packing List........................................................................5

Installation and Mounting instruction .......................................6

Tools and Supplies .............................................................6

Connecting to the Battery...................................................6

Selecting the Mounting Location ........................................6

Mounting the NCS40T........................................................6

Mounting the BT Antenna................................................... 6

Wiring .......................................................................................7

Travel Lock out information .....................................................8

Mobile Devices ........................................................................9

Pairing A Mobile Device .........................................................10

iOS Pairing Instructions...................................................10

Android Pairing Instructions............................................. 11

Passcode Protection ..............................................................13

App Conﬁguration ..................................................................13

Adding Auxiliary Function ......................................................14

Adding TPMS .........................................................................15

Low Battery Voltage Alert .......................................................16

Home Page Operation ........................................................... 17

Battery Check...................................................................17

Hydraulic .........................................................................18

Light Check ......................................................................19

Auxiliary............................................................................20

TPMS ...............................................................................21

Troubleshooting .....................................................................22

Speciﬁcatons .........................................................................23

FCC NOTES ..........................................................................24

• Table Of Contents

NCS40T

• Thank You!

Thank you for choosing iN-Command. We hope you will ﬁnd the

instructions in this owner’s manual clear and easy to follow. If you take

a few minutes to look through it, you’ll learn how to use all the features

of your new NCS40T for maximum enjoyment.

• Feature Description

What does iN∙Command for Trailers control?*

• Hydraulic lift control

• Latch and momentary auxiliary functions

• Light checks for running, brake, and turn signal lights

What does iN∙Command for Trailers monitor?*

• Battery level monitoring and low voltage alert

* Functions may vary by trailer model

• Precautions

• Use the Proper Power Supply.

This product is designed to operate with a 12 volt DC, negative ground

battery system (the standard system in a North American vehicle).

• Use Authorized Service Centers.

Do not attempt to disassemble or adjust this precision product; contact

a professional for assistance.

• Avoid Moisture.

To reduce the risk of ﬁre or electric shock, do not expose this equipment

to rain or moisture.

• Avoid Cleaning Products.

The front of this unit should only be cleaned with a slightly damp cloth.

Do not use cleaning products.

• Use Recommended Accessories.

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK AND

ANNOYING INTERFERENCE, USE ONLY THE RECOMMENDED

ACCESSORIES.

(1) Control System

(2) External Antenna (3) Four 1/4" bolts & nylock nut.

• Packing List

• Introduction

NCS40T

It’s a good idea to read all of the instructions before beginning the

installation.

• Tools and Supplies

You will need these tools and supplies to install your NCS40T :

• 7/16” socket with ratchet – or 7/16 wrench

• 1/4” drill/bit and drill

• 3/4” hole saw for mounting BT antenna

• Four ¼” bolts. Length determined by material thickness you are

mounting to.

• Four ¼” lock nuts.

• Connecting to the Battery

• To prevent a short circuit, make all other connections on the NCS40T

before connecting the Trailer Battery Power Input Red wire ring terminal

to the +12V battery post and the White wire ring terminal to the negative

battery post.

• Selecting the Mounting Location

• Select a location that provides access to the Pair button.

• Select a location that provides access to the wiring and in range of

all connections.

• Installation and Mounting instruction

• Mounting the BT Antenna

1/4" lock nuts

1/4" blots

• Mounting the NCS40T

Wall for Reference

Antenna Nut

Antenna

Waterproof Rubber

3/4" hole

cutout

LIGHT POWER OUTPUT

TPMS POWER OUTPUT

DUMP / SOLENOID POWER OUTPUT

AUX 1 POWER OUTPUT (BLUE)

AUX 2 POWER OUTPUT (ORANGE)

TRUCK / LIGHT POWER INPUT

TRAILER BATTERY POWER INPUT

EXTERNAL ANTENNA

#6. TRUCK POWER - (WHITE)

#5 . DC 12V ( YELLOW L2)

#4. EMPTY

#1. DC 12V (BROWN L1)

#3. TRUCK POWER+12V(RED )

#2. DC12V (GREEN L3)

#2 .TPMS POWER + (RED)

#1 .TPMS POWER - (WHITE)

#2 .RIGHT LIGHT OUT (GREEN L3)

#3 .EMPTY

#4 .EMPTY

#5 .LEFT LIGHT OUT (YELLOW L2)

#1 .RUNNING LIGHT OUT (BROWN L1)

#6 .EMPTY

#4 .HYD DOWN OUT (GREEN)

#3 .SOLDENOID POWER OUT (WHITE )

#2 .EMPTY

#1 . HYD UP OUT (RED)

[RED) (WHITE)

234

PAIR BUTTON PAIR

INDICATOR

POWER

INDICATOR

• Wiring

NCS40T

• Travel Lock out information (Safety)

iN∙Command ® Control Systems use travel-lock-out technology to disable any functions that are deemed unsafe when the vehicle is in motion.

NCS40T

• Mobile Devices

The iN-Command Trailer Control System requires a mobile app to

operate the system.

Visit the Google Play and Apple App stores on your mobile device to

download and use the iN-Command Trailer App.

Only one device can be actively paired to the iN-Command Trailer

Control System at a time.

To use another device, the active device needs to shut down its iN-

Command App to allow another device to pair.

iN•Command

ASA Electronics, LLC

Installed

The iN-Command Trailer Control System requires a mobile app to operate the system.

Visit the Google Play and Apple App stores on your mobile device to download and use the

iN-Command Trailer App.

Only one device can be actively paired to the iN-Command Trailer Control System at a time.

To use another device, the active device needs to shut down its iN-Command App to allow

another device to pair.

NCS40T

• Pairing A Mobile Device

• iOS Pairing Instructions

1. Enable "Bluetooth" in the system settings of the mobile device. 2. Press "Pair" on the mobile device.

Click " Pair " button to enter discovery mode.( Long press " Pair " button for 5-8 seconds to disconnect device.)

PAIR BUTTON PAIR

INDICATOR

POWER

INDICATOR
