IMOU Turret Manuel utilisateur
Turret
Quick Start Guide
www.imoulife.com
Welcome
Thank you for choosing IMOU.
We are devoted to providing you easy smart home products.
If you have problems using the product, please contact
our service team before returning your product.
Our service mail: service.global@imoulife.com
Frequently asked questions can be found at
imoulife.com/support/help
Package content
Camera introduction
Power Adapter ×1 Screw Package ×1
Camera ×1 Mounting Plate ×1 Waterproof Connector ×1Positioning Map ×1
Quick Start Guide ×1
Build-in Mic
Lens
Spotlight
LED Indicator
Note:
Double-press the reset button to enable the camera hotspot.
The pattern of the LED indicator is included in the following table.
Press and hold the reset button for 10 s to reset the camera.
Micro SD Card Slot
Built-in Speaker
Reset Button
LED Indicator Status
Off
Booting
Device malfunction
Network connection failed
Pairing failed
Red light on
Device Status
Green light on
Waiting for network
Enter Pairing mode
Operating properly
Green light flashing
Red light flashing
Firmware updating
Powered off/LED turned off
Rebooting after reset
Green and red light
flashing alternately
1
Windows
Imou Life
Setup
WIFI Name
Password
Next
Setup
Done
2
Ceiling Mounting
3
Camera
Expansion Bolt
2
Self-tapping Screw
Mounting Plate
1
Positioning Map
Mounting Surface
2
Wall Mount:Adjusting Angle:
+60
-30
Troubleshooting
Problem Solution
The camera cannot work
normally or start
• Make sure that the network cable is connected well, and the NVR or switch
supports POE power supply. When the indicator light on the NVR or switch
flashes, it means that the camera is powered up.
Where are the recorded
videos saved
• Scene1
Recorded videos are saved in NVR.
• Scene2
When the Imou cloud is enabled, recorded videos are saved in Imou cloud.
The IR effect is not good • The infrared light is reflected to the lens, so the effect is not good.Adjust the
ens angle to avoid occlusions around the lens.
Turret
www.imoulife.com
Kurzanleitung
Willkommen
Vielen Dank, dass Sie sich für IMOU entschieden haben.
Wir sind bestrebt, einfachere Produkte für das intelligente
Heim anzubieten. Wenn Sie Probleme bei der Verwendung
des Produkts haben, wenden Sie sich bitte an unser
Serviceteam.
Häug gestellte Fragen nden Sie unter imoulife.com/
support/help
Packungsinhalt
Einführung in die Kamera
Netzteil ×1 Schraubenbeutel ×1
Kamera×1 Montageschablone ×1 Wasserdichter Anschluss ×1Montageschablone ×1
Kurzanleitung ×1
Integriertes
Mikrofon
Objektiv
Scheinwerfer
LED-Anzeige
