Image Access WideTek 36C Manuel utilisateur

Operation Manual

Art

-Nr.: WT36C/48C-600-MAN-EN

File: WT36C_WT48C_OperationManual_E.docx

Manual Page 3

2010 – 2015 by Image Access GmbH, Wuppertal, Germany.

Reproduction in whole or in part in any form or medium without express written permission of

Ima

ge Access is prohibited.

Scan2Net

®, WideTEK®and Bookeye®are registered trademarks of Image Access.

All other trademarks are the property of their respective owners.

Image Access reserves the right to change the described products, the specifications or

documents at any time without prior notice.

For the most recent version, always check o

ur web site www.imageaccess.de

www.imageaccess.us or the customer service portal at portal.imageaccess.de

Page 4 Manual

Introduction

Dear Customer,

The Image Access team congratulates you on the acquisition of this innovative large

format scanner.

We at Image Access are proud of the work we do; it is the result of our extremely high

standards of production and stringent quality control.

With the WideTEK®36C / WideTEK®48C, Image Access offers an efficient scanner

which covers a wide scope of applications due to its versatility. Its integrated web

based user interface makes all functions available in structured menus.

This operation manual is designed to lead you through all situations which will arise

when using the WideTEK®36C / WideTEK®48C.

For this reason, we ask you to read the manual attentively before starting to work with

the sanner. By doing so, you will avoid operation errors and you can control all

functions from the beginning.

In addition please consider the following points:

•Damages to your unit may have occurred during shipping. Please check for

damages immediately after delivery of the unit. Inform your supplier if damage

has occurred.

•Read and ensure that you understand the safety notes. They were developed

for your protection and safety as well as to protect the unit.

•Regular maintenance conserves the high quality and safety of the

WideTEK®36C / WideTEK®48C during the entire service life.

If you have any further questions, please feel free to contact your local dealer or

Image Access, Inc. directly. Our staff will be happy to help you.

For your daily work with the WideTEK®36C / WideTEK®48C scanner, we wish you

success and complete satisfaction.

Regards

Your Image Access Team

Manual Page 5

About this Manual

Operation Manual

The Operation Manual gives all information about the normal operation and behavior

of the device. It is written for people who only operate the device and do not perform

setup and adjustment procedures. All device elements and software functions are

described in detail, although some of them might never be used. This manual does not

cover any application software. Refer to the appropriate application software manual to

learn about the application software.

All available manuals for this device can be downloaded from our customer service

portal at http://portal.imageaccess.de. Be sure to always check for the latest versions of

these manuals.

This manual is divided into sections.

Section A contains the safety notes and the safety precautions. These safety

precautions must be followed carefully to avoid injury to the user while

working with the scanner.

Section B describes the scanner hardware and the first steps to take after the

device has been delivered. It contains also some maintenance

information.

Section C describes touchscreen operation and the functions of the applications.

Section D gives a short introduction and basic information about the user interface

ScanWizard Web. All details about the interface can be found in the

integrated “Help” texts in the scanner.

Section E informs about the setup levels in general and describes the access level

User in detail.

Section F describes test and troubleshooting procedures.

Section G contains all technical data of the scanner and the manufacturer

declarations concerning safety and electromagnetic compatibility (EMC).

Page 6 Manual

Version History

Version

Published in

Content/Changes/Supplements

A May 2011 Preliminary version.

July 2011

Information after EMC and safety testing and certification added.

A3 September 2011 Chapter C.3.9: New content, former chapter C.3.9

renumbered to

C.3.10.

Content of chapter C.5.2 revised, new screenshots added.

October 2011

Chapter B.6.3.1 added. In Chapter C.3.3 additional information

about “Container” format for multipage output.

Chapter C.3.7.2

added.

FCC note added in chapter E.6.

December 2011

Update Technical Data

April 2012

Update of content of User Settings (FW Vers. 5.71).

New structure in chapter C.3.5 and its subfolder.

B1 March 2013 Valid with firmware 5.8.

The new WideTEK®36C logo has been introduced.

New: Chapter B.5.1. Zonal OCR

Previous chapter B.5.1 and all following chapters renumbered.

New screen screenshots of some kiosk application screens.

June 2013

Section D describes now the “Setup Level”. Former chapter D and

E have been renumbered.

C December 2013

Section C: Content change because of introduction of the new

user interface ScanWizard.

April 2014

Combination of the

WideTEK®36C

WideTEK®48C

operation

manuals in one manual.

Differences between the scanner models will be highlighted.

Chapter B.3.2, B.3.3, B.3.5 and B.3.6 with new content.

Chapter B.1.1, chapter D.1.3.2, chapter D.1.3.4 added.

September 2014

Chapter C.1.1 and C.1.1 added. Table in chapter E.1 modified.

December 2015

Chapters in new order. Description of the ScanWizard touchscreen

interface added.

EMC information according to the standard EN 55022

Warning!

This is a class A

device. Operation of these equipment in a residential area is likely to

cause harmful interference in which case the user will be required to correct the

interference at his own expense.

Manual Page 7

Table of Content
