1
Illustra Pro PTZ Outdoor Housing
To the Installer
This guide assumes that the outdoor mounting structure to which the housing is attached is in
place and that data and power cables have been pulled to the installation site.
For the purpose of this guide we are installing the Illustra Pro PTZ camera to an EndCap Mount
(ROENDC).
1. The installation shall be performed by a qualified person in accordance to all local regulations.
2. This equipment requires the use of an NEC class 2 or Certified Limited Power Source (LPS).
What’s in the box
Standard Items
• Quick Reference Guide
• Illustra Pro PTZ Camera CD
• Illustra Pro PTZ Outdoor Camera Assembly
• Illustra Pro PTZ Outdoor Bubble Assembly (in separate box)
• Pendant Adapter
• Threaded Adapter
•LockNut
• External Safety Lanyard
• Lanyard Lock and Release Pin
• Tamperproof Torx Wrench
• HEX L-Key Tool
• Weather proof Ethernet Connector
• Power Cable
• Desiccant bag and clip
Feature Plus Version
• Alarm Cable
• Audio Cable
• Breakout Box Assembly
Illustra Pro PTZ Outdoor Housing
2Quick Reference Guide
Additional Supplies (not in box)
ADSPOT - Power Supply, one output, 120/240 VAC to 24 VAC
Tools Required
• 6.6mm (1/4in) fixed-handle nut driver for Torx bit
• Wire cutters and strippers
• 2.5mm (0.1in) slotted screwdriver
Illustra Pro PTZ Outdoor Housing
3
Installing the Outdoor Housing
The following describes the installation procedure for the Illustra Pro PTZ Outdoor Camera
Housing.
1Remove the pendant adapter, threaded adapter, lock nut, external safety lanyard and
lanyard lock from the packaging.
Note
The threaded adapter and lock nut will be required for mounting options that use
the EndCap Mount (ROENDC).
2Cut a 30cm (12in) length of teflon tape.
3Apply the teflon tape to the threads on both ends of the threaded adapter.
4Attach the threaded adapter to the pendant adapter and tighten to secure.
5Attaching to the EndCap Mount (ROENDC):
If the Illustra Pro PTZ Outdoor Housing is being attached to an existing mount it is essential that
the EndCap (ROENDC) is replaced. Please contact your Tyco Security Products Sales
Representative for further information.
aRemove the access cover from the EndCap mount as seen in Figure 1.
Pendant Adaptor Threaded Adaptor
Lock Nut
Safety Lanyard
Lanyard Lock
Release Pin
Desiccant bag and clip
Illustra Pro PTZ Outdoor Housing
4Quick Reference Guide
Figure 1
bAlign the pendant adapter with the EndCap and rotate clockwise until approximately
6mm of the threaded adaptor is visible inside the EndCap.
cAttach the lock nut to the threaded adaptor and hold while rotating the pendant cap
until secure as seen in Figure 2.
Figure 2
Note
When securing the pendant adapter ensure that the two M8 screws can be easily
accessed. This can be seen in Figure 3.
Figure 3
Illustra Pro PTZ Outdoor Housing
5
6Attach the External Safety Lanyard:
aWrap the safety lanyard around the pipe and thread end through the loop as seen in
Figure 4.
Figure 4
bAttach the lanyard lock by threading the end of the safety lanyard through the hole in
the lanyard lock as seen in Figure 5.
Figure 5
cFeed the end of safety lanyard through vent slots on the pendant adaptor and back
through the lanyard lock as seen in Figure 6.
Figure 6
dPull the excess safety lanyard through the lanyard lock to remove the slack.
Note
To remove the lanyard lock, insert the supplied release pin into the pin hole at
either end of the lanyard lock and pull to release the cable.
7Route the supplied cable ends through the EndCap mount and through the pendant
adapter. We recommend that you form an external loop with the cables and then feed
them through the pendant adapter as seen in Figure 7, this allows freedom of movement
Illustra Pro PTZ Outdoor Housing
6Quick Reference Guide
in the cables when attaching the outdoor housing in later steps.
If audio cables are to be extended beyond 30m in length, they must be shielded.
Note
For ease of installation the power, alarm and audio cables should be routed
through first, followed by the Ethernet cable.
Figure 7
8Terminate the network cable using the supplied weather proof Ethernet connector.
9Remove the outdoor camera housing from the packaging.
10 Insert desiccant bag:
aRotate the camera to the position shown in Figure 8, this will allow for space while
inserting the desiccant bag.
Note
Avoid touching the lens during positioning and installation of the desiccant bag.
