Ikelite 6973.03 Manuel utilisateur

Thank you for your purchase of kelite equipment. Please read this

instruction manual completely before attempting to operate or dive

with this product. Please refer to the back page of this manual to

Underwater Ho sing for Canon EOS M3

Prod ct N mber 6973.03

I n s t r c t i o n M a n a l

RE ARATION ..............................................................P. 3

S ECIFICATIONS - no camera installed ....................P. 4

INCLUDED in the BOX ..................................................P. 4

Parts of the Housing - Front View ..................................P. 5

Parts of the Housing - Back View ..................................P. 6

HOUSING and CAMERA SETU STE S......................P. 7

STEP 1 - Attach/Remove Tray and Handle ....................P. 7

STEP 2 - nitial Camera Settings ....................................P. 8 - 9

STEP 3 - Opening the Housing ......................................P. 9

STEP 4 - nstall Camera/Hotshoe in Housing ................P. 9 - 11

STEP 5 - Closing the Housing ........................................P. 12

STEP 6 - Attach Optional Mirrorless Lens Ports ............P. 12

STEP 7 - Final Check......................................................P. 13

USAGE............................................................................P. 13

Entering the Water ..........................................................P. 13

Removing the Camera from the Housing........................P. 14

STROBE USE and COM ATIBILITY ............................P. 15

Strobe Compatibility ........................................................P. 15

kelite Housing Conversion Circuitry ..............................P. 15

Attach kelite Sync Cord to the Housing and Strobe ......P. 15 - 16

Attach kelite Strobe Arm to the Housing Handle............P. 17

S ARE ARTS ..............................................................P. 18

RECOMMENDED ACCESSORIES ................................P. 18

MAINTENANCE ..............................................................P. 19 - 24

Table of Contents

This product has been water pressure tested at the factory and is depth

rated to 200 ft (60 m). Thoroughly inspect and immerse the empty

housing completely in water before installing a camera. f any fogging

occurs or droplets of water enter the housing, do not install a camera.

Clean the main housing o-ring and retest to make sure that the housing

is watertight. Refer to the Troubleshooting section, page 26.

Please read your camera manual thoroughly to have a full

understanding of each camera function.

f you are new to underwater photography, be sure to read the Photo

Tips section, page 25.

RE ARATION

HOTO TI S ..................................................................P. 25

TROUBLESHOOTING ....................................................P. 26 - 28

CUSTOMER SU ORT..................................................P. 29

LIMITED WARRANTY ....................................................P. 30

RETURNING RODUCTS FOR SERVICE ....................P. 31

RODUCT REGISTRATION ..........................................Back Page

Table of Contents - continued

Controls ................................All camera buttons and dials are accessible

Buoyancy ..............................Slightly negative in freshwater

Depth Rating..........................200 ft (60 m)

Strobe Connection................ kelite Digital TTL CS-5 5-pin Electrical

................................................Bulkhead plus TTL circuitry compatible with

................................................current model kelite DS-series strobes

Use Built-in Flash..................Yes, with Fiber Optic Ports only

Tray and Handle Weight ......8.7 oz (247 g)

Main O-Ring ..........................0110

Housing Dimensions ............6.4 x 7.6 x 5.3 in (16 x 19 x 13.5 cm)

Housing Weight ....................3.1 lb (1.4 kg) not including tray, handles or

................................................lens port

Housing Material ..................Polycarbonate front, acrylic back

- Housing

- nstruction Manual

- Tray with Quick Release Handle

- Waterproof Bulkhead Cap (connected to external strobe connector)

- Silicone 1cc Lubricant Tube

- Accessory Package (includes cleaning cloth and additional control tips).

S ECIFICATIONS - no camera installed

INCLUDED in the BOX

arts of the Housing - Front View

Shutter

Button

Lens ort Base

External Tray Mounts

Lid Snap

Front Dial

External Strobe

Connector & Cap

Lens

Release

Button

Exp. Comp. Dial

M-Fn Button

Fiber Optic Ports

Flash Pop-up

Switch

108

INFO

13 14

MOVIE

ISO

1. Mode Dial

2. Power Button

3. Movie Button

4. Playback Button

5. AE Lock Button

6. AF Frame Adjustment

7. SO/UP Button

8. MF/LEFT Button

9. Quick Setting Menu/SET Button

10. Flash/R GHT Button

11. Erase/DOWN Button

12. INFO nformation Button

13. MENU Button

14. Control Dial

arts of the Housing - Back View

Skip STEP 1 if Tray and Spacer are factory installed.

One side of the Spacer has an adhesive backing. Remove the Protective

Film to adhere the Spacer to the Tray.

Using a 9/16” open/box end or socket Wrench (not supplied), firmly

tighten the External Tray and Spacer to the Mounting Bolts using the two

3/8-16 Nuts and Washers supplied in the accessory package. Reverse

procedure to remove. Note: Tray and Handle may be attached before or

after the camera is secured in the Housing. We recommend attaching

them immediately to avoid scratching table tops with the Mounting Bolts.

3/8-16 Nut

9/16” Wrench - not supplied

MADE IN USA

Tray Mounting Bolt

External Tray

& Handle

Spacer

Protective Film

STE 1 - Attach/Remove Tray and Handle

Washer

HOUSING and CAMERA SETU STE S

Adhere Spacer to Tray

before attachment to

Housing.

- nsert a fully charged camera battery and a SD card.

- Set Mode Dial to “M” Manual Mode. Set Aperture to f/8 and shutter

speed to 1/125th second. Other shooting modes are not recommended.

-In Menu:

Set mage Quality to “L” 24M and Still mage Aspect Ratio to “3:2.”

Set mage Review to “8 sec” and Touch Shutter to “Disable.”

Set AF operation to “ONE SHOT” and AF method to “1-point AF.”

Set AF + MF to “Off” and S Settings to “Continuous, Dynamic S 2.”

Set Lens Chromatic aberration and Peripheral illumination to “Enable.”

Set SO speed to “200” and Highlight tone priority to “Off.”

Set Auto Lighting Optimizer to “Standard.”

Set Metering mode to “Center-weighted avg.”

In Flash Control:

Set Flash firing to “ ” and E-TTL meter to “Evaluative.”

Set Red-eye reduc. to “Off”

Set Built-in flash settings Flash Mode to E-TTL and Shutter Sync. to

“1st curtain.”

Set External flash settings as desired once a strobe is detected and

turned on.

Set Movie rec. size to “FHD” and AF w/shutter button during to “ON.”

-In Menu:

nsert and format an SD card. CAUT ON: Save existing photos on a

separate storage device before formatting.

Set ECO Mode to “Off.”

n Power Saving, set Auto Power Down to and Display Off to “Off.”

Set Touch Operation to “Disable.”

-In Q.SET Menu:

Set White Balance to “Auto.” Always use auto white balance (AWB) > >

STE 2 - Initial Camera Settings -before placing camera in housing

Setup your camera for underwater use and then ad ust your settings once underwater.

STE 3 - Opening the Housing

Lid Snaps have a Lock.

1. Push Lid Snap Locks forward and lift as shown.

Open opposing Lid Snaps simultaneously. Keep

pressure on the Lid Snaps so they do not fly

open quickly. Some Lid Snaps have a lot of

spring tension once they go over center, so keep

a firm grip on each Lid Snap. Lid Snaps may

also be opened one at a time.

2. Remove the Housing Back.

Push Forward Lid

Snap

Lock

Lift

1. Make sure the camera battery is fully charged and a SD card is inserted

into the camera.

2. Rotate Housing Lens Release Button control up and forward against

front of housing. Pull top housing control knobs up for more clearance.

3. The Mounting Plate is secured to the inside bottom of the housing. The

camera Mounting Tray slides into the Mounting Plate. Use your index

finger and thumb to pull the Thumb Screw and Tray away from the

Mounting Plate, Diagram A, page 10. Use your other thumb to apply

opposite pressure against the bottom of the housing to assist in removal

of the Tray if necessary.

STE 4 - Install Camera/Hotshoe in Housing

when using a strobe/flash. When recording video or shooting stills

without a strobe, AWB can still be used, but for more accurate and

consistent colors we recommend setting Custom white balance .

*All other camera functions not mentioned should be set to the user’s

preference.

STE 2 - Initial Camera Settings - continued

STE 4 - Install Camera/Hotshoe in Housing - continued

4. Using a coin or flathead screwdriver (preferred), secure the camera

Mounting Tray to the camera tripod mount, Diagram B. Tighten camera

firmly to avoid movement on tray. The Mounting Tray only attaches one

way with the

Thumb Screw to

the back of the

camera.

An additional

1/4-20-inch tray

hole allows

attachment to a

land tripod stand.

HDMI

Diagram B

Thumb Screw

Mounting Tray

5. Gently slide the camera with Mounting Tray back into the Mounting

Plate, Diagram C, page 11. Using your thumbs, push against the

Mounting Tray until it stops sliding forward into the Mounting Plate. Give

the Tray an extra push to make sure it is properly seated all the way

forward in the Mounting Plate and no housing controls are in the way.

Diagram A

Mounting Plate

Mounting Tray

Pull to Remove
