INSTRUCTION MANUAL

MODEL

ISD-A15

ISD-A15TDN

Color Camera

OUTDOOR USE WARNING

WARNING – TO PREVENT FIRE OR

ELECTRIC SHOCK, DO NOT EXPOSE

THIS APPLIANCE TO RAIN OR

MOISTURE.

The apparatus shall not be exposed to

dripping or splashing and that no

objects filled with liquids, such as

vases, shall be placed on the

apparatus.

Thank you for choosing this Ikegami Hyper Wide Dynamic DPS Camera.

Please read this Instruction Manual carefully to keep your Ikegami camera at peak

performance for longer service period.

This unit is a cube-type 1 CMOS color camera and making use of a 1/3” type digital

pixel sensor system (DPS).

This Ikegami product is made of ECO friendly components based upon the

Company policy and corporate social responsibility to contribute towards the Global

Environmental Solution for energy conservation and environmental sustainability,

all the components used in this product are Non-hazardous, Toxic Free, Non-Lead

and conform with Japan's Green Product regulation, EU's RoHS directive and other

Environmental and hazardous chemical substances related regulations and laws.

Contents

Page

1. Handling precautions .................................................................... E-1

2. General ......................................................................................... E-1

3. Features........................................................................................ E-2

4. Name of each section and its function .......................................... E-3

5. Operating Procedure..................................................................... E-5

5-1. User Setup............................................................................. E-5

5-2. Names and functions of the setup buttons ............................ E-5

5-3. Setup mode Procedures........................................................ E-5

9. FOCUS EZ function ...................................................................... E-16

7. Warranty and After-sale service.................................................... E-17

8. Speciﬁcations ............................................................................... E-18

9. External Appearance

10.Setup Flow Chart

The exclamation point within an equilateral triangle isintended to alert the user to

the presence of important operating and maintenance (servicing) instructions in the

literature accompanying the appliance.

NOTE:

This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to part 15 of the FCC Rules.These limits are designed to provide

reasonable protection against harmful interference when the equipment is operated in a

commercial environment.This equipment generates, uses, and can radiate radio

frequency energy and, if not installed and used in accordance with the instruction

manual, may cause harmful interference to radio communications.Operation of this

equipment in a residential area is likely to cause harmful interference in which case the

user will be required to correct the interference at his own expense.

CAUTION;

ANY CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PART

RESPONSIBLE FOR COMPLIANCE COULD VOID THE USERS AUTHORITY TO

OPERATE THE EQUIPMENT.

Instructions for Disposal of Electrical and Electronic Equipment in Private

Households

Disposal of used Electric and Electronic Equipment

(Applicable in the European Union and other European countries with

separated waste disposal and collection methods)

This symbol on the product, or in the related documents in the package, indicates

that this product shall not be treated as normal household waste. Instead, it should be

taken to a proper applicable collection point or depot for the recycling of electric and

electronic equipment.

By ensuring this product is disposed of correctly, you will help prevent possible negative

consequences for the environment and human health, which could otherwise be caused by

inappropriate waste handling of this product. The recycling of materials will help to conserve natural

resources.

For more detailed information about recycling of this product, please contact your local city

authority, your household waste disposal service or the place where you purchased the product.

IMPORTANT SAFETY INSTRUCTIONS

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with a dry cloth.

7) Do not block any of the ventilation openings. Install in accordance with the

manufacturer's instructions.

8) Do not install near any heat sources such as radiators, heat registers,

stoves, or other apparatus (including ampliﬁers) that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding type plug. A

polarized plug has two blades with one wider than the other. A grounding

type plug has two blades and a third grounding prong. The wide blade or the

third prong is provided for your safety. When the provided plug does not ﬁt

into your outlet, consult an electrician for replacement of the obsolete outlet.

10) Protect the power cord from being walked on or pinched particularly at plugs,

convenience receptacles, and the point where they exit from the apparatus.

11) Only use the attachments/accessories speciﬁed by the manufacturer.

12) Use only with a cart, stand, tripod, bracket, or table specified by the

manufacturer, or sold with the apparatus. When a cart is used, use caution

when moving the cart/apparatus combination to avoid injury from tip-over.

13) Unplug this apparatus during lightning storms or when unused for long

periods of time.

14) Refer all servicing to qualiﬁed service personnel. Servicing is required when

the apparatus has been damaged in any way, such as power supply cord

or plug is damaged, liquid has been spilled or objects have fallen into the

apparatus, the apparatus has been exposed to rain or moisture, does not

operate normally, or has been dropped.

15) CAUTION - These servicing instructions are for use by qualified service

personnel only. To reduce the risk of electric shock, do not perform any

servicing other than that contained in the operating instructions unless you

are qualiﬁed to do so.

E-1

1. Handling Precautions

s $O NOT EXPOSE THE INTERNAL MECHANISM OF THE CAMERA IN A WATER

splashed or highly humid environment.

s $O NOT USE THE CAMERA WHERE THE AMBIENT TEMPERATURE DROPS BELOW

-10°C or rises above +50°C. The images and component parts may be

adversely affected or the camera may not function correctly.

s $ONOTOPENTHECASEOFTHECAMERAUNLESSITISABSOLUTELYNECESSARY

for setup or installation because there are precision electrical and

electronic components inside and accident may result.

s "ESURETOTURNOFFTHEPOWERBEFOREINSTALLINGORMAKINGCONNECTIONS

s"ECAREFULNOTTODROPORGIVEASTRONGSHOCKTOTHECAMERAWHILE

transporting it.

s $ONOTTOUCHTHEIMAGESENSOR

s $ONOTORIENTATETHECAMERADIRECTLYTOWARDSTHESUN

s "ECAUSEOFTHEDIGITALIMAGEDEVICE CHARACTERISTICS IMAGESMAY LOOK

unnatural at high temperatures, this does not mean the camera is faulty.

2. General

This color camera is provided with a 1/3-inch DPS CMOS sensor. The

CCTV camera features wide dynamic range, high sensitivity and high

resolution, and is equipped with the color/black-and-white switching, back-

light compensation, automatic iris control, line lock and other functions.

The unit is best suited for general surveillance.

E-2

3. Features

(1) Hyper Wide Light Dynamic Range (Hyper WDR)

The WDR function provides for very effective compensation of high

light and darkareas in screen. This situation may occur generally

outside or viewing from indoor to outdoor scenes. Even in large light

fluctuations, bright-and-dark subjects can be captured and viewed

clearly with a natural appearance.

(2) Small-size cube shape

The small-size cube shape of the camera allows it to be most suitable

to be installed into various devices such as ATM units.

(3) High-quality picture and high resolution

The camera is designed for smear-free imaging and low noise. The

well-designed DSP, Digital Signal Processor, effectively enhances

details, which achieves crisp and sharp images with a high signal-to-

noise ratio. The high resolution of a horizontal resolution of 520 TV

lines (690HTVL-Effective) is assured.

(4) Automatic white balance

Thanks to the automatic follow-up white balance control (ATW), the

white balance adjusts itself no matter how great the subject's color

temperature ﬂuctuates.

(5) Automatic Sensitivity Control

In conjunction with the wide dynamic control by the multi-sampling

system, the camera incorporates the automatic sensitivity control

function that always provides adequate and bright images even

through its ﬁxed-iris lens.

(6) Scene File

In addition to normal setting (NORMAL), there are four patterns for

scene ﬁles (setting ﬁles) that are preset beforehand to a particular

scene. By selecting those patterns, it is easy to carry out image

setting suited to the scene without having to carry out specialized

image adjustment.

(7) FOCUS EZ function

The level indicator is displayed to allow immediate judgment of focal

point. In addition, the focus of the auto-iris lens is released to allow

easy focusing without worrying about the depth of field even in a

bright environment during the daytime.

E-3

4. Name of each section and its function

LENS

MAX40mA

AC24V 50/60Hz 160mA

DC12V 170mA

VIDEO OUT SET UP

POWER

E-4

①Lens mount (CS mount)

This is used to mount the lens on the camera. Many types of CS

mount lens can be attached.

②Back focus lock screw

After completing the ﬂange back adjustment of the camera, use the

supplied Allen wrench to tighten the screw until it is fully ﬁxed.

③Holder mounting screw holes

These holes are used to install and fix the camera on the camera

mounting or bracket. They can be also applicable to general use

tripods which have a quarter inch thread.



Note

To use these holes to attach the camera on a tripod or other

mount, make sure you use suitable size mounting bolts as

follows (1/4" -20UNC), they should not be longer than 5.5 mm to

avoid an un-stable installation.

④Auto iris lens connector

Speciﬁcally used to connect the auto iris lens.

Applicable connector: E4-191J-100 or equivalent

●DC Iris System

— Connector cable leads —

1. Damping coil (-)

2. Damping coil (+)

3. Driving coil (+)

4. Driving coil (-)

* Connect the leads as shown above.

Please refer also to the instructions of the lens to be used.

Connectorpinassignment

Auto iris lens

E-5

⑤Video output terminal (VIDEO OUT)

To be used to give out the video signal. Connect this to the video input

terminal of a monitor, switcher etc. (To be terminated with 75-ohm

impedance.)

⑥Power indicator (POWER)

The LED indicator stays on in green while the camera power is on.

⑦DC12V/AC24V power input terminal

Keep the input power at DC10.5-15.0 V or AC24V±10%.

* This installation should be made by a qualiﬁed service person and

should conform to all local codes.

⑧-⑨Camera setup function switches

 PleaserefertotheOperationProcedurechapter.

5. Operating Procedure

5-1. User Setup

This dome camera is provided with user setup function for picture quality,

and camera ID. The setup menu is a tree type on-screen-display.

When installing the camera it is possible to set up the various functions.

5-2. Names and functions of the setup buttons

UTo select setup parameters

D(up and down)

RTo change setup parameters

ETo get in or get out to setup

mode, and to enter and

execute procedures.

* To get into Setup mode, hold E button more than 2 seconds.

5-3. Setup mode Procedures

Hold down the E button longer than 2 seconds, and the setup menu screen

at left appears on screen. A highlighted item is now selected.

Use the L/R buttons to change the selection items.

SET UP

Autres manuels pour ISD-A15

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Ikegami Appareil photo numérique

Ikegami

Ikegami HDK-99 Manuel utilisateur

Ikegami

Ikegami ICD-E11 Manuel utilisateur

Ikegami

Ikegami ISD-A10 Manuel du propriétaire

Ikegami

Ikegami HDL-23 Manuel du propriétaire

Ikegami

Ikegami ISD-A35 Manuel utilisateur

Ikegami

Ikegami HDK-73 Manuel utilisateur

Ikegami

Ikegami HL-59 Guide d'installation

Ikegami

Ikegami HDK-790EXIII Manuel utilisateur

Ikegami

Ikegami ISD-2500HD Manuel utilisateur

Ikegami

Ikegami IHD-D525S Manuel utilisateur

Ikegami

Ikegami ICD-879S Manuel utilisateur

Ikegami

Ikegami ISD-A14 Manuel utilisateur

Ikegami

Ikegami ICD 525 Manuel utilisateur

Ikegami

Ikegami ICD-525S Manuel utilisateur

Ikegami

Ikegami ISD-A15 Manuel utilisateur

Ikegami

Ikegami ISD-2500HD Manuel utilisateur

Ikegami

Ikegami MKC-500HD Manuel utilisateur

Ikegami

Ikegami HDL-20 Manuel utilisateur

Ikegami

Ikegami ISD-200HD Manuel utilisateur

Ikegami

Ikegami HDK-97C Manuel utilisateur

Ikegami

Ikegami SKC-141TC Manuel utilisateur

Ikegami

Ikegami HDK-79GX Manuel utilisateur

Ikegami

Ikegami HDK-970A Manuel utilisateur

Ikegami

Ikegami ICD-48E Manuel utilisateur

Manuels Appareil photo numérique populaires d'autres marques

Mercury

Mercury 350K Manuel utilisateur

Pentax

Pentax Optio LS 465 Manuel utilisateur

Sanyo

Sanyo VPC-S1085 Manuel utilisateur

GE SMART A1255 Manuel utilisateur

Point Grey

Point Grey Gazelle Manuel utilisateur

Nikon

Nikon COOLPIX A Manuel utilisateur

Pentax

Pentax P-5 Manuel utilisateur

BlazeVideo

BlazeVideo A280 Manuel utilisateur

Sony

Sony MCA-20 Manuel utilisateur

Sony

Sony Alpha DSLR-A290 Manuel utilisateur

ATIK Cameras

ATIK Cameras One Manuel utilisateur

CohuHD Costar

CohuHD Costar 3930 Series Manuel utilisateur

Leica

Leica M10-R Manuel utilisateur

FujiFilm

FujiFilm FinePix A700 Manuel utilisateur

Lorex

Lorex LNZ81P25 Series Manuel utilisateur

GE J1470S Manuel utilisateur

Sony

Sony A6700 Guide de l'utilisateur

Canon

Canon EOS ELAN7 Manuel utilisateur
