IHome IBN10 Manuel utilisateur

iBN10

instruction manual

iBN10 IB (Eng)

Size: 153 x 120 mm

Color: Black text on white paper

May 19, 2014 P1

Bluetooth Wireless

Stereo Speaker System

with Speakerphone and USB Charging

Questions? Contact Customer Service at 1-800-288-2792

Introduction

Thank you for purchasing the iHome iBN10. This product is designed to provide high quality wireless

sound from your iPad, iPhone, iPod, computer, or other Bluetooth audio device.

Along with the included Quick Bluetooth Connection Guide this instruction booklet explains the basic

operation and care of the unit. Please read them carefully and keep for future reference.

This unit features NFC (Near Field Communication) technology which allows you to wirelessly connect

your NFC–enabled device to instantly ‘pair and play’. See your device’s user manual for details on how

to interact with NFC devices. If your Bluetooth device does not support NFC, you can pair it manually

with this unit.

Maintenance

• Place the unit on a level surface away from sources of direct sunlight or excessive heat.

• Protect your furniture when placing your unit on a natural wood and lacquered finish. A cloth or other

protective material should be placed between it and the furniture.

• Clean your unit with a soft cloth moistened only with mild soap and water. Stronger cleaning agents,

such as thinner or similar materials can damage the surface of the unit.

7*/* (

iBN10

FCC ID:EMOiBN10

IC:986B-iBN10

FCC/IC Information

• Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could

void the user’s authority to operate the equipment.

• NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to

Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined by turning the equipment off and on,

the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

CAN ICES-3 (B)/NMB-3(B)

The device meets the exemption from the routine evaluation limits in section 2.5 of RSS 102 and compliance

with RSS-102 RF exposure, users can obtain Canadian information on RF exposure and compliance.

This device complies with Part 15 of the FCC Rules, operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may cause undesired operation.

FCC Radiation Exposure Statement

This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This transmitter

must not be co-located or operating in conjunction with any other antenna or transmitter.

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:

(1) This device may not cause interference, and

(2) This device must accept any interference, including interference that may cause undesired operation of the device.

iBN10

Table of Contents

Included

Meet Your iBN10 ............................................................................................. 1-3

Setting Up the Unit

Turning the Unit ON and OFF .................................................................. 4

Setting the Clock

FM Radio ............................................................................................... 5

Setting and Using FM Presets

Using FM Radio in Other Countries.............................................. 6

Using Bluetooth: Pairing Your Device Using NFC ..................................................................... 7

Using Bluetooth: Pairing Your Device using Bluetooth ................................................................ 8

Playing Audio Via Bluetooth.................................................................................................. 9

Using the Speakerphone feature.......................................................................................... 10

Playing Audio Via Aux line-in ............................................................................................. 10

Charging Devices Via USB Port

Dimming the Display ........................................................... 11

Replacing and Installing Clock Backup Batteries .................................................................... 12

Consumer Product Safety Guide .................................................................................... 13-14

Troubleshooting ............................................................................................................... 15

Warranty ....................................................................................................................... 16

iBN10

Included

• iBN10 System

• 100V-240V universal AC adaptor

• Audio cable

Audio cable

iBN10 AC adaptor

iBN10

Meet Your iBN10

Power/Pairing Button

Press to power on/off

Press and hold to pair

Volume Knob

Turn to adjust

NFC

Antenna Area

Touch NFC device to pair Speakerphone

Mic

FM Antenna

Aux-in Jack

DST SwitchDisplay/Clock Adjust Button DC JackUSB Charging Port

Top

Back

Play/Pause/Preset

Button

Forward/

End Call Button

Reverse/Talk/

Answer Call Button

Mode Button

dst aux

in DC 12V, 2.5Adisplay

-1 | +1clock adjust

USB

iBN10

Meet Your iBN10

Low Backup Battery

Indicator

FM Mode Indicator Status Indicator

(volume, dimmer, pairing, etc)

Aux-in Mode Indicator

Daylight Saving Time

(DST) Mode Indicator

The Display

Time Display

End Call Indicator

Talk Mode Indicator

(Speakerphone)

Bluetooth/Pairing Mode Indicator

PM Indicator

When unit is off press and hold the Display/Clock Button on the back of the unit

for 5 seconds to adjust the clock display from High to Low.

iBN10

Using the

Setting Up the Unit

Connect the included AC adaptor to the DC jack

located on the back panel of the unit and connect

the other end to a working wall outlet. Extend the

FM antenna fully for best reception.

Turning the Unit ON and OFF

1.Once the AC adaptor is properly connected, press

the Power/Pairing Button located on top of the

unit to turn the unit ON. The power indicators on

the front panel display and the Power/Pairing

Button will light.

2. Press the Power/Pairing Button to turn the unit

OFF.

outlet

Setting the Clock

The unit features a Daylight Saving Time (DST) Switch on the back of the unit to quickly add or subtract an

hour to account for Daylight Saving Time and Standard Time differences. Before setting the time, move the

DST Switch to +1 to add an hour or to -1 to subtract an hour.

1. Press the Display/Clock Adjust Button located on the back of the unit. The clock display flashes and

a beep sounds, indicating clock setting mode.

2. Press the or Buttons to adjust the clock to the current time (hold for rapid setting).

Make sure you set the correct AM/PM time. The PM indicator appears to the left of the display.

3. To toggle the clock display between standard 12 hour time and 24 hour (“military”) time display,

press the Mode Button during time setting while time digits are flashing.

4. Press the Display/Clock Adjust Button to confirm the time and exit clock setting mode. 2 beeps will

confirm clock setting is complete.

FM Radio

Extend the FM antenna for best reception.

1. Press the Button on the unit to turn it on.

2. Press and release the Mode Button as needed until the FM indicator icon and current FM radio

frequency appear on the display.

3. Press the or Buttons to tune the radio to the desired station (hold to scan for the next clear station).

4. Turn the Volume Knob to adjust the volume on the unit.

5. When you are through listening, press the Button to turn the unit off.

Using the iBN10

P10

Setting and Using FM Presets

The unit allows you to store up to 6 FM radio station presets

1. Press the Button on the unit to turn it on.

2. Press and release the Mode Button as needed until the FM indicator icon and current FM radio

frequency appear on the display.

3. Press and release the

Presets Button as needed until the preset number (P1- P6) you wish to set is

displayed, then press and hold the Presets Button to enter setting mode.

4. Press the

or Buttons to tune the radio to the desired station (hold to scan for the next clear

station).

5. Press and release the

Presets Button to confirm. 2 beeps will sound to confirm the preset has been

assigned. Continue steps 3 - 5 until you have set up to 6 preset stations.

6. To listen to a preset FM station at any time, follow steps 1 - 3 to turn on FM radio mode and cycle

to the desired preset.

Using FM Radio in Other Countries

Different areas of the world use different FM frequency steps and ranges. By default, this unit is

set to USA frequency steps. To use the radio outside the USA:

1. Make sure unit is OFF.

2. Press and hold the Button + Mode Button together for 5 seconds until “USA” flashes in the display.

3. Turn the Volume Knob to cycle to your location: Europe, Japan, Australia, China or USA.

4. Press the Mode Button again to exit frequency setting mode. 2 beeps will confirm setting.

Using the iBN10
