IgniteNet SunSpot AC1200 Manuel utilisateur

www.ignitenet.com

Outdoor Stand-Alone Access Points

SkyFire™ AC1200 Series

SkyFire™ AC866 Series

Indoor Stand-Alone Access Points

SunSpot™ AC1200

SunSpot™ N300

Software Release v1.0.0

User Guide

SkyFire AC1200 Series Outdoor Stand-Alone Access Points

Dual Band (2.4 GHz/802.11n and 5 GHz/802.11ac) Concurrent Access Points

with one 1000BASE-T (RJ-45 PoE-Input) Port

and one 100BASE-TX (RJ-45 PoE-Output) Port.

SF-AC1200 – integrated 5 GHz antenna and 2x RP-SMA (2.4 GHz)

SF-AC1200-1 – 2x RP-SMA (5 GHz) and 2x RP-SMA (2.4 GHz)

SF-AC1200-2 – integrated 5 GHz antenna and integrated 2.4 GHz antenna

SkyFire AC866 Series Outdoor Stand-Alone Access Points

Single Band (5 GHz/802.11ac) Access Points

with one 1000BASE-T (RJ-45 PoE-Input) Port

and one 100BASE-TX (RJ-45 PoE-Output) Port.

SF-AC866 – integrated 5 GHz antenna

SF-AC866-1 – 2x RP-SMA (5 GHz)

Sunspot AC1200 Indoor Stand-Alone Access Point

Dual Band (2.4 GHz/802.11n and 5 GHz/802.11ac) Concurrent Access Point

with one 1000BASE-T (RJ-45 PoE-Input) Port,

two 100BASE-TX (RJ-45 PoE-Output) Port

and one USB 2.0 port.

SS-AC1200 – desktop, wall or ceiling mount; integrated antenna

Sunspot N300 Indoor Stand-Alone Access Point

Single Band (2.4 GHz/802.11n) Access Point

with one 1000BASE-T (RJ-45 PoE-Input) Port,

two 100BASE-TX (RJ-45 PoE-Output) Port

and one USB 2.0 port.

SS-N300 – desktop, wall or ceiling mount; integrated antenna

FW1.0.0

E072014/ST-R01

– 3 –

How to Use This Guide

This guide includes detailed information on the access point (AP) software,

including how to operate and use the management functions of the AP. To deploy

this AP effectively and ensure trouble-free operation, you should first read the

relevant sections in this guide so that you are familiar with all its software features.

Who Should Read

This Guide?

This guide is for network administrators who are responsible for operating and

maintaining network equipment. The guide assumes a basic working knowledge of

LANs (Local Area Networks), the Internet Protocol (IP), and Simple Network

Management Protocol (SNMP).

How This Guide

is Organized

The organization of this guide is based on the AP’s main management interfaces.

The web management interface and command line interface (CLI) are described in

separate sections. An introduction and initial configuration information is also

provided.

The guide includes these sections:

◆Section I “Getting Started” — Includes an introduction to AP management and

initial configuration settings.

◆Section II “Web Configuration” — Includes all management options available

through the web interface.

◆Section III “Appendices” — Includes information on troubleshooting AP

management access.

Documentation

This guide focuses on AP software configuration, it does not cover hardware

installation of the AP. For specific information on how to install the AP, see the

following guide:

Quick Start Guide

For all safety information and regulatory statements, see the following documents:

Quick Start Guide

Safety and Regulatory Information

How to Use This Guide

– 4 –

Conventions The following conventions are used throughout this guide to show information:

Note:

Emphasizes important information or calls your attention to related features

or instructions.

Caution:

Alerts you to a potential hazard that could cause loss of data, or damage

the system or equipment.

Warning:

Alerts you to a potential hazard that could cause personal injury.

Revision History This section summarizes the changes in each revision of this guide.

September 2014 Revision

This is the first revision of this guide. It is valid for software release v1.0.0.

– 5 –

Contents

How to Use This Guide 3

Contents 5

Figures 7

Tables 9

Section I Getting Started 11

1 Introduction 12

Configuration Options 12

Network Connections 13

Connecting to the Web Interface 13

Setup Wizard 15

Main Menu 18

Dashboard 19

Common Web Page Buttons 20

Section II Web Configuration 21

2 Status Information 22

System and Product Information 22

Internet Status 23

Local Networks 24

Wireless Status 25

Traffic Graphs 27

3 Network Settings 28

Internet Settings 28

Ethernet Settings 31

Contents

– 6 –

LAN Settings 33

Hotspot Settings 34

4 Wireless Settings 37

Radio Settings 37

VLAN Settings 50

5 System Settings 52

System Settings 53

Maintenance 54

Displaying System Logs 54

Rebooting the Access Point 55

Resetting the Access Point 55

Backing Up Configuration Settings 55

Restoring Configuration Settings 55

Upgrading Firmware 56

User Accounts 56

Services 57

Remote Management Settings 57

SSH 57

Telnet 58

Web server 58

Network Time 59

SNMP 60

Section III Appendices 61

A Troubleshooting 62

Problems Accessing the Management Interface 62

Using System Logs 62

Index 64

– 7 –

Figures

Figure 1: Login Page 14

Figure 2: Select Your Country 15

Figure 3: Select Setup Method 16

Figure 4: Easy Setup 16

Figure 5: Advanced Setup 17

Figure 6: Bridge to Internet 17

Figure 7: Route to Internet 18

Figure 8: The Dashboard 19

Figure 9: Set Configuration Changes 20

Figure 10: System and Product Information 22

Figure 11: Internet Status 23

Figure 12: Options 23

Figure 13: ARP Table 24

Figure 14: DHCP Leases 24

Figure 15: Local Networks 24

Figure 16: Wireless Status 25

Figure 17: Traffic Graphs 27

Figure 18: Internet Settings 28

Figure 19: IP Address Mode – Static IP 29

Figure 20: IP Address Mode – PPPoE 30

Figure 21: IP Alias 30

Figure 22: Ethernet Settings – Internet Source 31

Figure 23: Ethernet Settings – Network Behavior 32

Figure 24: Network – LAN Settings 33

Figure 25: Hotspot Settings (Network Settings) 34

Figure 26: Hotspot Settings (RADIUS Settings) 35

Figure 27: Hotspot Settings (Captive Portal Settings) 36

Figure 28: Radio Settings (Physical Radio Settings) 38

Figure 29: Radio Settings (Wireless Network Configuration) 40

Figures

– 8 –

Figure 30: WMM Backoff Wait Times 42

Figure 31: Configuring VLANs 51

Figure 32: System Settings 53

Figure 33: Maintenance 54

Figure 34: System Log 54

Figure 35: Rebooting the Access Point 55

Figure 36: Resetting to Defaults 55

Figure 37: Restoring Configuration Settings 55

Figure 38: Upgrading Firmware 56

Figure 39: User Accounts 56

Figure 40: SSH Server Settings 57

Figure 41: Telnet Server Settings 58

Figure 42: Web Server Settings 58

Figure 43: NTP Settings 59

Figure 44: SNMP Settings 60

– 9 –

Tables

Table 1: Radio Channels 39

Table 2: WMM Access Categories 41

Table 3: 802.11 Data Rates 46

Table 4: Tx Power 48

Table 5: Troubleshooting Chart 62

Tables
