OWNER'S MANUAL
955 Ignite Treadmill
PLEASE READ ALL INSTRUCTIONS CAREFULLY BEFORE USING THIS PRODUCT. REVIEW AND FOLLOW ALL
REFERENCED SAFETY GUIDELINES. RETAIN ALL PRODUCT LITERATURE FOR FUTURE REFERENCE.
SAFETY CAUTION: PROPERLY WARM UP & STRETCH BEFORE EXERCISING. IF YOU FEEL PAIN OR DIZZINESS AT
ANY TIME WHILE EXERCISING, STOP IMMEDIATELY AND CONSULT YOUR PHYSICIAN.
IMPORTANT:
Part No. 06062
Revision: A Date: 11/05
STEP 1
ASSEMBLY INSTRUCTIONS
Part # Description Q 'TY
Main frame & computer
Upright side cap
Allen Bolt
Washer
Phillip Head Screw
Allen Key
Screwdriver
Safety Key
Multi-Purpose Holder
Phillips Head Screw
A
B
C
D
E
F
G
H
I
J
1
2
6
6
6
1
1
1
1
2
1
Figure 1
Take the whole treadmill out of the box, and lay all parts flat on floor as shown in Figure 1.
Locate the hardware bag and parts that are listed in the chart below.
J
I
STEP 2
ASSEMBLY INSTRUCTIONS
2
Figure 2
Lift the upright and carefully thread the Allen Bolts (C) and washers (D) inside holes at the bottom of the
upright. Use the Allen Key (F) to tighten them down.
STEP 3
ASSEMBLY INSTRUCTIONS
3
Figure 3
Use the handgrips to pivot the console into position. (Caution: Be careful not to pinch the computer wire).
Use the Allen Key (F) to securely tighten the Allen Bolts (C) with Washers (D). (Figure 3)
STEP 4
ASSEMBLY INSTRUCTIONS
4
Place the upright side caps (B) to the correct position.
Use allen key (F) to tighten screws (E) to holes showing in Figure 4.
Mount the Multi-Purpose holder (I) using the phillips head screws (J).
Figure 4
FOLDING AND LOWERING THE TREADMILL
5
Figure 6
Figure 5
TO FOLD THE TREADMILL
After assembly is complete, you may fold the
machine into the upright position for storage.
To fold the machine, raise the deck and make
sure the latch is in place by turning the knob
as shown. (Figure 5)
WARNING: Make sure the treadmill's elevation
is at 1 before folding the deck. If
the elevation is not at 1, it will
cause damage to the machine.
TO LOWER THE TREADMILL
To lower the deck, pull and turn the knob on
the latch until it releases the deck. (Figure 6)
** This machine has a built-in soft-lowering
system to help the deck lower slowly.
WARNING: Please make sure there are no
children or other things under
the deck when you lower it.
MOVING THE TREADMILL
6
TO MOVE THE TREADMILL
Fold the treadmill to the upright position and make sure to engage the safety latch as
shown in Figure 5. Use the handgrips to maneuver your treadmill on its transport wheels.
Caution: treadmills are heavy pieces of equipment and require extreme care during transportation.
7
Power cord
Safety switch
CAUTION
The machine will shut off when the electricity load is above the machine's capacity.
To restart the machine, please follow the procedure below:
A. Unplug the power cord from the machine's socket.
B. Push in the safety switch.
C. Replug the power cord into the machine's socket.
** DO NOT PUSH IN THE SAFETY SWITCH BEFORE UNPLUGGING THE MACHINE'S POWER CORD.
If you leave the treadmill plugged in after turning off the console, there will still be current
running to the console. This treadmill is equipped with a safety control program that will
automatically shut down the machine after six hours of no use. In the event of an automatic
shut down, please follow the procedure below to restart the treadmill:
A. Unplug the power cord from the machine's socket.
B. Replug the power cord into the machine's socket to restart the machine.
CAUTION !
8
IMPORTANT PRECAUTIONS
Caution!
Do not attempt to plug in or operate your treadmill before reading the Important Precautions.
Important Precautions
Power Source
Plug the treadmill power cord into a dedicated (not shared) 110 volt, alternating current (AC), 15 amp
grounded outlet circuit. Do not use an extension cord or an ungrounded outlet.
Do not modify the plug to fit an existing outlet. If it will not fit your outlet, have the correct outlet
installed by a qualified electrician.
Never operate your treadmill if the power cord has been damaged. Keep the power cord away from
any heated surfaces.
Do not run the power cord under the treadmill. Make sure that the power cord has enough slack to
allow the walking deck to fully elevate.
Treadmill Placement
Select a location that is:
•Indoors, away from a water source (pool, hot tub, sauna etc.)
•Away from the use of aerosol sprays or the administration of oxygen.
•Level, free of obstructions, and offers clear access on all sides.
You may place the treadmill on a carpeted floor, but deep pile shag carpeting could interfere with
proper ventilation. Use a treadmill mat (usually available from your retailer) if you have deep pile carpeting.
Treadmill Operation
Consult your physician before beginning any exercise program.
Do not overexert yourself during a workout. If you feel any pain or discomfort, consult your
physician immediately.
Close supervision is required whenever your treadmill is in use. This is especially important when
in use around children, invalids, disabled persons and pets.
Wear clothing appropriate for exercising on your treadmill. Always wear running or training shoes
with rubber soles. Do not wear loose fitting clothing that may become caught in the treadmill. Keep
fingers, jewelry, towels and long hair away from any moving parts.
Always attach the Safety Key lanyard clip to your clothing so that the unit will shut down if you
stumble or fall.
9
IMPORTANT PRECAUTIONS
Never power up the computer or start the treadmill while standing on the walking belt. You should
straddle the walking deck by standing on the side rails until the belt starts moving. Don’t wait for the
treadmill to ramp up to full speed before stepping onto the walking belt.
Make sure that all users are familiar with the instructions and precautions in this manual. Allow only
one person at a time on your treadmill. Always keep your body facing forward when the walking belt
is moving. Use the handles when mounting, operating and exiting your treadmill.
It’s a good idea to remove the magnetic Safety Key when you finish your workout to prevent
unauthorized use. If your treadmill is going to be left unattended, remove the Safety Key and
unplug the power cord.
Heart Rate Control (HRC) Programs
Caution !
You should consult your physician to determine your target heart rate.
After determining your target heart rate, monitor your heart rate while using the Manual Program
to help choose the optimal walking belt speed. The speed should be set at a comfortable pace that
slowly brings your heart rate to approximately 10 BPM (beats per minute) below your target.
While walking at your optimal speed, the 955 computer will automatically adjust the incline to help
you reach your target heart rate.
If you feel any pain or discomfort, stop and consult your physician immediately.
Treadmill Maintenance
Allow only trained personnel to service your treadmill.
Do not modify your treadmill, use any parts or attachments not recommended by the manufacturer,
or attempt any service other than the assembly and maintenance recommended in this manual.
Always unplug the power cord before attempting to move or perform any maintenance on your treadmill.
When folded, make sure that the Safety Lock is fully engaged. Refer to the Folding And Lowering The
Treadmill section of this manual for the proper folding and lowering procedure.
Regularly inspect and tighten any of the hardware used in the treadmill assembly process.
