IFM E30391 Manuel d'installation

Programming instructions

IO-Link Display 1,44”

E30391

Content

Installation and electrical connection..............................................3

Set-up.............................................................................................3

Parameter setting (acyclic communication)....................................5

3.1.

Parameter setting with LINERECORDER DEVICE............6

3.2.

Process value display........................................................7

3.3.

Text content for info pages ................................................7

3.4.

Background colour of the info pages..................................9

3.5.

Free text instead of process values ...................................9

3.6.

Predefined text instead of process values........................11

3.7.

Display configuration........................................................13

3.8.

QR code...........................................................................13

IO-Link process data (cyclic communication)...............................14

4.1.

Output data......................................................................14

4.2.

Input data.........................................................................16

4.3.

Examples.........................................................................17

4.3.1.

Example 1: display one process value.............................17

4.3.2.

Example 2: display two process values ...........................18

4.3.3.

Example 3: display text instead of process values...........19

4.3.4.

Example 4: display info pages .........................................19

4.3.5. Example 5: Display QR-Code .............................................20

Technical data..............................................................................20

5.1.

Identification parameters..................................................20

Technical data, approvals, accessories and further

information at www.ifm.com

1.Installation and electrical connection

For installation and electrical connection please read see the

operating instructions →www.ifm.com.

2. Set-up

When the IO-Link Display is connected to an IO-Link master the

IO-Link port has to be configured.

In this example the IO-Link master AL1000 from ifm electronic

is used with the Siemens software Step 7.

The IO-Link Display has an interface with 1-byte input (→4.2 Input

data) and 14-byte output (→4.1 Output data).

If there is no explicit module on the master used it is possible to use

an existing module with a wider interface.

Drag, for example, a 24/24-byte I/O module to the master port

to which the IO-Link Display is to be connected.

Double click on the module:

Enter name and comment as an option:

Enter addresses for input and output ranges:

Enter vendor ID and device ID to ensure that only an IO-Link

Display 1,44” can be operated at that port.

Set the data storage according to the application's requirements:

Write the configuration to the controller or PLC.

Connect the IO-Link Display to the master using a 3-wire cable.

3.Parameter setting (acyclic communication)

Settings can be made and predefined text can be entered by

means of the IO-Link parameter setting tool or a PLC by writing

the corresponding parameters.

The LINERECORDER DEVICE can for example be used as

IODD-based parameter setting tool (→3.1).

It is possible to configure the following properties:

•

Process value display (unit, description text, decimal places) →

3.2

•

Text content for info pages →3.3

•

Background colour of the info page →3.4

•

Text instead of process values →3.5; →0

•

Display layout →3.7

•

Content of a QR code →3.8

The process values, colours and layout switching are controlled

via the cyclic communication of the controlling PLC. (→4 )

3.1.

Parameter setting with LINERECORDER DEVICE

►Connect the IO-Link Display via the USB interface E30390.

►Start the LINERECORDER DEVICE.

►Read parameters from the IO-Link Display:

►Change parameters.

►Write parameters to the IO-Link Display:

> The IO-Link Display can now be connected to the IO-Link master.

3.2.

Process value display

Name Index /

subinde

Type /

length

Content

Unit 1 80/0

String/8

Units of the process

values

Unit 2 81/0

Unit 3 82/0

Unit 4 83/0

Description 1 90/0

String/16

Description text of

the process values

Description 2 91/0

Description 3 92/0

Description 4 93/0

Decimal place 1 100/0

UINT8/1

Number of decimal places of

the process values:

0 = no decimal place

1 = 1 decimal place

2 = 2 decimal places

3 = 3 decimal places

Decimal place 2 101/0

Decimal place 3 102/0

Decimal place 4 103/0

3.3.

Text content for info pages

Up to 16 characters per line can be used.

Name Index /

subind

Type /

length

Content

Info page 1, line 1 120/0

String/16

Text content of page 1

Info page 1, line 2 121/0

Info page 1, line 3 122/0

Info page 1, line 4 123/0

Info page 1, line 5 124/0

Info page 2, line 1 125/0

String/16

Text content of page 2

Info page 2, line 2 126/0

Info page 2, line 3 127/0

Info page 2, line 4 128/0

Info page 2, line 5 129/0

Name Index /

subindex

Type /

length

Content

Info page 3, line 1 130/0

String/16

Text content of page 3

Info page 3, line 2 131/0

Info page 3, line 3 132/0

Info page 3, line 4 133/0

Info page 3, line 5 134/0

Info page 4, line 1 135/0

String/16

Text content of page 4

Info page 4, line 2 136/0

Info page 4, line 3 137/0

Info page 4, line 4 138/0

Info page 4, line 5 139/0

Info page 5, line 1 12100/0

String/16

Text content of page 5

Info page 5, line 2 12101/0

Info page 5, line 3 12102/0

Info page 5, line 4 12103/0

Info page 5, line 5 12104/0

Info page 6, line 1 12105/0

String/16

Text content of page 6

Info page 6, line 2 12106/0

Info page 6, line 3 12107/0

Info page 6, line 4 12108/0

Info page 6, line 5 12109/0

Info page 7, line 1 12110/0

String/16

Text content of page 7

Info page 7, line 2 12111/0

Info page 7, line 3 12112/0

Info page 7, line 4 12113/0

Info page 7, line 5 12114/0

Info page 8, line 1 12115/0

String/16

Text content of page 8

Info page 8, line 2 12116/0

Info page 8, line 3 12117/0

Info page 8, line 4 12118/0

Info page 8, line 5 12119/0

Name Index /

subind

Type

lengt

Content

Info page 9, line 1 12120/0

String/16

Text content of page 9

Info page 9, line 2 12121/0

Info page 9, line 3 12122/0

Info page 9, line 4 12123/0

Info page 9, line 5 12124/0

Info page 10, line 1 12125/0

String/16

Text content of page 10

Info page 10, line 2 12126/0

Info page 10, line 3 12127/0

Info page 10, line 4 12128/0

Info page 10, line 5 12129/0

3.4.

Background colour of the info pages

Name

Index /

subind

Type /

length

Content

Background colour info page

140/0

INT8/1

Page colour:

0 = black-white

1 = red

2 = green

3 = yellow

Background colour info page

141/0

Background colour info page

142/0

Background colour info page

143/0

Background colour info page

144/0

Background colour info page

145/0

Background colour info page

146/0

Background colour info page

147/0

Background colour info page

148/0

Background colour info page

149/0

3.5.

Free text instead of process values

Text defined by the user which can be displayed instead of process

values.

Name Index /

subindex

Type /

length

Content

Text 1 161/0

String/16

Text which can be

freely defined.

Maximum length: 16

bytes

Text 2 162/0

Text 3 163/0

Text 4 164/0

Text 5 165/0

Text 6 166/0

Text 7 167/0

Text 8 168/0

Text 9 169/0

Text 10 170/0

Text 11 171/0

Text 12 172/0

Text 13 173/0

Text 14 174/0

Text 15 175/0

Text 16 176/0

Text 17 177/0

Text 18 178/0

Text 19 179/0

Text 20 180/0

Text 21 181/0

Text 22 182/0

Text 23 183/0

Text 24 184/0

Text 25 185/0

Text 26 186/0

Text 27 187/0

Text 28 188/0

Text 29 189/0

Text 30 190/0

Text 31 191/0

Text 32 192/0
