Operating instructions

Object inspection sensor

O2V

80232358 / 00 10 / 2015

Object inspection sensor O2V

Contents

1 Preliminary note ................................................. 4

1.1 Symbols used............................................... 4

2 Safety instructions ............................................... 4

3 Items supplied................................................... 4

3.1 Accessories ................................................ 4

4 Functions and features ............................................ 5

5 Installation...................................................... 5

5.1 Mounting accessory .......................................... 5

5.2 Mounting dimensions ......................................... 6

5.3 Installation location........................................... 6

6 Electrical connection.............................................. 7

6.1 Wiring ..................................................... 8

6.2 Wiring diagram .............................................. 8

6.3 External illumination .......................................... 9

6.4 External trigger source ........................................ 9

6.5 Timing diagrams ............................................ 10

6.5.1 Inputs/outputs ............................................ 10

6.5.2 Static selection of the application ............................. 12

6.5.3 Pulse-controlled selection of the application ..................... 13

7 Operating and display elements .................................... 14

7.1 LED display ............................................... 14

7.2 Display ................................................... 15

7.2.1 Operating indicators ....................................... 15

7.2.2 Evaluation results ......................................... 16

7.2.3 Connection via the operating program ......................... 16

7.2.4 Error messages ........................................... 16

7.3 Pushbuttons ............................................... 16

8 Set-up ........................................................ 17

8.1 Parameter setting on the unit .................................. 17

8.2 Verify and set the IP address on the unit ......................... 17

8.3 Adjustable parameters ....................................... 18

8.3.1 Parameter structure........................................ 19

8.4 Lock / unlock sensor......................................... 20

8.4.1 Lock the reading or changing of sensor parameters. .............. 20

8.4.2 Lock changing of sensor parameters. .......................... 20

8.4.3 Unlock the sensor ......................................... 20

8.4.4 Reset device to factory settings .............................. 21

8.4.5 Reboot the unit. ........................................... 21

8.5 Parameter setting via PC operating program ...................... 21

9 Operation ..................................................... 22

9.1 Evaluation mode (normal operating mode) ....................... 22

Object inspection sensor O2V

10 Scale drawing ................................................. 22

11 Technical data ................................................. 23

11.1 Operating distance L........................................ 23

11.2 Factory settings ........................................... 23

12 Process data protocol........................................... 24

12.1 Configuring the process interface.............................. 24

12.2 Communication basics ...................................... 24

12.2.1 Abbreviations and terms ................................... 24

12.2.2 Commands for the device .................................. 24

12.2.3 Replies from the device.................................... 24

12.3 Protocol versions .......................................... 25

12.4 Command types ........................................... 25

12.5 Release trigger ............................................ 26

12.6 Release trigger, evaluate captured image and result output via process

interface ..................................................... 26

12.7 Select protocol version ...................................... 26

12.8 Select the application ....................................... 27

12.9 activate/deactivate result output............................... 27

12.10 Transmit the application data set to the device .................. 27

12.11 Request the assignment of the application data from the device ..... 28

12.12 Request the statistics from the device ......................... 28

12.13 Request the error code from the device ........................ 28

12.14 Request the last image from the device ........................ 29

12.15 Request the last result from the device ........................ 29

12.16 Request the protocol version ................................ 29

12.17 Request the device information .............................. 30

12.18 Request the last "bad" image from the device ................... 30

12.19 Request help for process interface............................ 31

12.20 Result message .......................................... 31

12.21 Error codes from the device ................................. 34

13 Maintenance, repair and disposal.................................. 37

14 Approvals/standards ............................................ 37

15 Note on the software............................................ 37

Object inspection sensor O2V

1 Preliminary note

1.1 Symbols used

►Instruction

> Reaction, result

[…] Designation of pushbuttons, buttons or indications

→Cross-reference

Important note

Non-compliance can result in malfunction or interference

Information

Supplementary note

2 Safety instructions

These instructions are part of the device. They contain information and illustrations

about the correct handling of the device and must be read before installation or

use.

Observe the operating instructions.

Non-observance of the instructions, operation which is not in accordance with use

as prescribed below, wrong installation or incorrect handling can affect the safety

of operators and machinery.

The installation and connection must comply with the applicable national and inter-

national standards. Responsibility lies with the person installing the unit.

Only the signals indicated in the technical data or on the device label may be sup-

plied to the connections or wires.

3 Items supplied

1 object inspection sensor O2V

1 screwdriver to set the image definition

1 operating instructions "Object inspection sensor O2V“, ident no.: 706239

The device is supplied without installation/connection accessories or software.

3.1 Accessories

www.ifm.com

→ data sheet search → e.g. O2V100 → Accessories

Object inspection sensor O2V

4 Functions and features

The object inspection sensor monitors an object for completeness, shape de-

viations or colour changes. The unit uses incident light or back light to detect a

grey-scale pattern of the object. On the basis of the determined brightness values

the sensor differentiates between the object to be monitored and the background.

Then the unit compares the image found with one or several models in a reference

image. Depending on the degree of conformity the output can indicate if a model

was found or which one was found.

5 Installation

5.1 Mounting accessory

The device is compatible with the mounting accessories for ifm's photoelectric sen-

sors of the O2Dxxx (object recognition sensor), O2Ixxx (multicode reader) series

etc.

Example mounting with clamp and bracket

►Use the mounting accessory E2D110.

1. Focal setter

2. Mounting accessory

3. Object to be recognised

4. Field of view size W X H

5. Operating distance L

Object inspection sensor O2V

Depending on the intended location and type of mounting the following mounting

accessories are available:

Description Art. no.

Mounting set for shaft Ø 12 mm

(clamp and bracket for types O2Dxxx, O2Mxxx, O2Ixxx, O2Vxxx)

E2D110

Shaft, straight Ø 12 mm, length 130 mm, M10 E20938

Shaft, angled Ø 12 mm, length 200 mm, M10 E20940

Mounting set for shaft Ø 14 mm

(clamp and bracket for types O2Dxxx, O2Mxxx, O2Ixxx, O2Vxxx)

E2D112

Shaft, straight Ø 14 mm, length 130 mm, M12 E20939

Shaft, angled Ø 14 mm, length 200 mm, M12 E20941

You can find more information about the available accessories at:

www.ifm.com

→ data sheet search → e.g. O2V100 → Accessories

or directly

www.ifm.com

→ data sheet search → e.g. E2D110

5.2 Mounting dimensions

The device is mounted using the mounting accessories or 2 M4 screws and nuts.

Hole dimensions → Chapter 10 Scale drawing.

5.3 Installation location

►Mount the sensor in front of or above the area to be monitored.The detectable

field of view size depends on the operating distance → Chapter 11.1 Technical

Data.

►Back light or scattered light situations and continuously changing light condi-

tions are to be avoided.

►Do not position room lights directly facing the camera lens.

►Position the optional external illumination (e.g. O2D905) opposite the camera

lens.

►To avoid adverse effects on the image detection, avoid installation in dirty areas

of the machine.

►The connected cables must be provided with a strain relief.

Object inspection sensor O2V

6 Electrical connection

NOTE

The unit must be connected by a qualified electrician.

►Disconnect power before connecting the unit.

NOTE

The voltage on pins 2, 4, 5, 6, 7 and 8 must not exceed the supply voltage on

pin 1 (U+).

►Use the same power supply and protective equipment for

●the device (e.g. O2Dxxx),

●the signal generator at the inputs (e.g. trigger switch, plc),

●the signal pick-up at the outputs (e.g. plc).

As an alternative, a diode at the switching outputs can prevent feedback

(see fig. below).

O O

1 unit

2 switching output

3 diode

4 plc

5 common load

Object inspection sensor O2V

6.1 Wiring



Process interface (1)

M12 plug, A-coded, 8 poles (view on the unit)











1 U+

2 trigger input

3 0V

4 switching output / trigger output

5 switching output (ready)

6 switching output (OUT)

7 switching output / input 1

8 switching output / input 2

Parameter/process interface (2)

M12 socket, D-coded, 4 poles (view on the unit)









1 Ethernet TD +

2 Ethernet RD +

3 Ethernet TD -

4 Ethernet RD -

S Screen

6.2 Wiring diagram















 





  



  

process interface

controller e.g. PLC

external trigger

external illumination

(optional)

Pin Use (factory setting)

Output signal "READY" provides the status of the sensor:

"1" after the evaluation has been carried out. "0" as long as the evaluation is being carried out, a

different application is being selected or in case of an internal error (trigger signals are ignored).

Output signal "OUT" provides the result of the evaluation:

"0" no matching model "1" matching model

Object inspection sensor O2V

►For PNP units (e.g. O2V100) use trigger sensors, illumination units and control-

lers with PNP inputs and outputs.

►For NPN units (e.g. O2V101) use trigger sensors, illumination units and control-

lers with NPN inputs and outputs.

6.3 External illumination

►Connect external illumination to the trigger output of the device.

Example Art. no.

Backlight, 100 x 100 mm, infrared light 880 nm O2D905

For information about the example above see:

www.ifm.com

→ data sheet search → O2D905

6.4 External trigger source

►Connect an external trigger source (e.g. a diffuse reflection sensor) to the trig-

ger input of the device.

Object inspection sensor O2V

6.5 Timing diagrams

6.5.1 Inputs/outputs

4.1

4.2

Example: Triggering positive edge

1: trigger input trigger signal

0: no action

1: triggering on positive edge

2: output READY ready signal

0: unit busy, OUT output not valid

1: unit ready for trigger signal, OUT output valid

3: OUT output,

static

object evaluation

0: object evaluation not successful

1: object evaluation successful

example 1 (dashed line):

last object OK, OUT = 1

next object faulty, OUT 1 → 0

next object OK, OUT 0 → 1

example 2 (solid line):

last object faulty, OUT = 0

next object OK, OUT 0 → 1

next object OK, OUT = 1

4 OUT output,

pulsed

object evaluation

0: object evaluation not successful or timeout of pulse length

1: object evaluation successful

example 4.1:

both objects OK, OUT = 1

after expiration of tB, OUT = 0

example 4.2:

first object OK, OUT = 1

after expiration of tB, OUT = 0

second object faulty, OUT = 0

Autres manuels pour efector 250

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels IFM Electronic Accessoires

IFM Electronic

IFM Electronic efector 200 OG laser Manuel utilisateur

IFM Electronic

IFM Electronic Efector 200 OL Series Manuel utilisateur

IFM Electronic

IFM Electronic efector 200 OT Manuel utilisateur

IFM Electronic

IFM Electronic efector100 GG507S Manuel utilisateur

IFM Electronic

IFM Electronic LR3000 Manuel utilisateur

IFM Electronic

IFM Electronic Efector 500 PL2058 Manuel utilisateur

IFM Electronic

IFM Electronic GM701S Manuel utilisateur

IFM Electronic

IFM Electronic Efector 300 SA1000 Manuel utilisateur

IFM Electronic

IFM Electronic LR8009 Manuel utilisateur

IFM Electronic

IFM Electronic efector300 SBU3 Manuel utilisateur

IFM Electronic

IFM Electronic efector 200 OG laser Manuel utilisateur

IFM Electronic

IFM Electronic EFECTOR200 OC Series Manuel utilisateur

IFM Electronic

IFM Electronic LR2750 Manuel utilisateur

IFM Electronic

IFM Electronic Efector 200 OI Series Manuel utilisateur

IFM Electronic

IFM Electronic Efector 250 O3M151 Manuel du propriétaire

IFM Electronic

IFM Electronic ecomat100 CR2101 Guide d'application

IFM Electronic

IFM Electronic efector 500 PM2055 Manuel utilisateur

IFM Electronic

IFM Electronic Efector 200 O6T3 Series Manuel utilisateur

IFM Electronic

IFM Electronic efector250 E2M250 Manuel utilisateur

IFM Electronic

IFM Electronic SM7000 Manuel utilisateur

IFM Electronic

IFM Electronic efector200 OGP3 Series Manuel utilisateur

IFM Electronic

IFM Electronic efector 250 O2D2 Series Manuel du propriétaire

IFM Electronic

IFM Electronic efector200 OG Series Manuel utilisateur

IFM Electronic

IFM Electronic Efector200 OG Manuel utilisateur

Manuels Accessoires populaires d'autres marques

Hillco

Hillco 2810 Manuel utilisateur

Siemens

Siemens QSA2700D Manuel de l'opérateur

Contours

Contours ZY024 Manuel utilisateur

Saivod

Saivod VS621 Manuel utilisateur

Virtuox

Virtuox VirtuCLEAN 2.0 Manuel utilisateur

SCE

SCE ENVIRO-THERM SCE-TE170B24VSS Manuel utilisateur

Z-Wave

Z-Wave HSD-200Z Manuel utilisateur

turck

turck FMX-IM-2UPLI63FX Manuel utilisateur

Decagon Devices

Decagon Devices 10HS Manuel utilisateur

UPPAbaby

UPPAbaby Cup Holder Manuel utilisateur

Elko

Elko SmartSensor Leakage Wireless Manuel utilisateur

Grizzly

Grizzly H8371 Manuel utilisateur

Panasonic

Panasonic HG-T Series Manuel utilisateur

DigiDesign

DigiDesign 888/24 I/O Manuel utilisateur

PROZIS

PROZIS QUAY Manuel utilisateur

patagonia

patagonia PSI Vest Manuel utilisateur

SFC Energy

SFC Energy EFOY GO! Manuel utilisateur

Axminster

Axminster Tooling Stylus Tip Ballpoint Pen Kit Manuel utilisateur

IFM Electronic efector 250 Manuel utilisateur

Manuels Accessoires populaires d'autres marques
