IFLIGHT G15 3-Axis Brushless Gimbal
IFLIGHT STABILIZED GIMBAL SYSTEMS USER GUIDE
Last Modified: January 13, 2016
NOTICE
All IFLIGHT warranties, instructional manuals, or any miscellaneous documentation for the IFLIGHT G15 must be speculated.
IFLIGHT does their best to resolve any technical errors in order to increase the overall efficiency of the IFLIGHT G15.
DISCLAIMER
While the IFLIGHT G15 does not require a license to use, please regard this as advanced cinema gear that must be handled with
caution and good judgment. A basic understanding of mechanical functions is needed in order to operate the IFLIGHT G15 safely and
responsibly. Failure to do so could not only result in injury of yourself and others, but irreparable damage to your gimbal.
It is essential to read our User Manual to ensure a safe and smooth experience. Please note that IFLIGHT will not be held responsible
for any contrary interpretation made by the user that is different from what the manual intended. IFLIGHT reserves the right to adjust
the manual when needed and is not responsible to alert any user of such changes.
Package content
QTY 1 x IFLIGHT G15 3 Axis Handheld Camera Stabilizer
QTY 1x Joystick controller
QTY 1x Gimbal Tuning Stand
QTY 1x Battery Pack
QTY 1x Battery Charger
IFLIGHT STABILIZED GIMBAL SYSTEMS USER GUIDE
Copyright © 2015 BeStableCam. All rights reserved.
CONTENTS
I. WARNING BEFORE USE
II. BATTERY & CHARGER
III. BALANCING YOUR GIMBAL
oHorizontal Tilt
oVertical Tilt
oRoll Balance
oPan Balance
IV. OPTIONAL EQUIPMENT
V. PROGRAM MODES
VI.
VII.
VIII.
IX.
IFLIGHT STABILIZED GIMBAL SYSTEMS USER GUIDE
Copyright © 2015 IFLIGHT MODEL. All rights reserved.
GIMBAL TUNING GUIDE
OPERATING POSITIONS
SIMPLE BGC GUI SOFTWARE SET UP
TROUBLE SHOOTINGS
I. WARNING BEFORE USE
Please save the profile before you change any settings
IFLIGHT STABILIZED GIMBAL SYSTEMS USER GUIDE
Copyright © 2015 IFLIGHT MODEL. All rights reserved.
After IFLIGHT G15 is correctly balanced with your camera setup, it is ready for use. First, install battery on to handle where the Velcro is. Plug
battery into the power connector,and the gimbal is on,Hold the IFLIGHT G15 still while powering on, as to avoid improper start up.
IFLIGHT G15 comes equipped with 5 modes. The default mode is “Follow Underslung” mode with disable joystick function. The camera follows
heading of the gimbal. The second mode is still “Follow Underslung” mode with activated Joystick function. The third mode is “Lock axis” mode.
The fourth mode is Pan and Pitch Follow".The Fifth mode is"Inverted" mode.
Pan and tilt can be controlled by operating the joystick or using a RC Tx (optional)
IFLIGHT STABILIZED GIMBAL SYSTEMS USER GUIDE
Copyright © 2015 IFLIGHT MODEL. All rights reserved.
II.
**Never leave charger unattended, exceed maximum charge rate, charge with non-approved batteries or charge batteries in the wrong mode.
**Always ensure the battery you are charging meets the specifications of this charger and that the charger settings are correct. Not
doing so can result in excessive heat and other related product malfunctions, which can lead to user injury or property damage.
PLEASE DO NOT…
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
…leave the power supply, charger and battery unattended during use.
…attempt to charge dead, damaged or wet battery packs.
…attempt to charge a battery pack containing different types of batteries.
…allow minors to charge battery packs.
…charge batteries in extremely hot or cold places or place in direct sunlight.
…charge a battery if the cable has been pinched or shorted.
…connect more than one battery pack to this charger at a time
…connect the charger if the power cable has been pinched or shorted.
…connect the charger to an automobile 12V battery while the vehicle is running.
…attempt to dismantle the charger or use a damaged charger.
…reverse the positive and negative terminals.
…connect battery to AC power.
**Failure to follow the advised steps while using this product will not only result in product malfunction, but can also cause
severe injury and property damage.
Battery & Charger
KEEP IN MIND TO ALWAYS…
Ø
Ø
Ø
Ø
…power on the charger before connecting the battery
…use only rechargeable batteries designed for use with this type of charger.
…inspect the battery before charging.
…keep the battery away from any material that could be affected by heat.
Ø
Ø
...monitor the charging area and have a fire extinguisher available at all times.
…end the charging process if the battery becomes hot to the touch or starts to change form (swell) during the charge process.
IFLIGHT STABILIZED GIMBAL SYSTEMS USER GUIDE
Copyright © 2015 IFLIGHT MODEL. All rights reserved.
III. BALANCING YOUR GIMBAL
We recommend you have your camera and accessories (i.e. filter, batteries, etc.) mounted before balancing the gimbal. If your
lens has an adjustable zoom, set the zoom to the desired position before balancing.
STEP 1: HORIZONTAL TILT/VERTICAL TILT
How to balance and adjust IFLIGHT G15 centre of gravity
The centre of gravity needs to be balance before IFLIGHT G15 can be used. The centre of gravity can be adjusted by moving the camera around
and certain mounting points. Little movements are all that are needed. Proper balancing is essential to correct operation of IFLIGHT G15 gimbal.
When the gimbal is able to never return to the same position after being gently tapped, balancing is complete.
First, the camera itself needs to be adjusted forwards/backwards. Work towards making the camera sit level.
Next, the up/down sliders on the pitch assembly need to be adjusted. Camera should roll without stopping in same position.
forwards/backwards up/down
IFLIGHT STABILIZED GIMBAL SYSTEMS USER GUIDE
Copyright © 2015 IFLIGHT MODEL. All rights reserved.
STEP 2: ROLL BALANCE
Verify the balance by moving your Roll Axis to several locations. If roll stays and does not fall to either side, your roll is balanced.
The roll needs to be adjusted next. There are two options to adjust roll. It can be adjust where the camera mounts or the back mounts on the roll
poll. Sometimes both need adjustment to get correct balance. We prefer that to move camera mount to adjust the camera balance.Lose the quick
release screws under the camera tray,move the camera tray left/right to get balance correct on camera mounts. Pay attention to keep everything
lined up horizontally.
left/right
IFLIGHT STABILIZED GIMBAL SYSTEMS USER GUIDE
Copyright © 2015 IFLIGHT MODEL. All rights reserved.
STEP 3: PAN BALANCE
The pan balance is the last axis to balance for the IFLIGHT G15. The Pan Balance will ensure that the entire mass below the pan
motor is balanced on the central axis line of the pan motor. The simplest way to check for your Pan Axis to be balanced is to tilt the
gimbal in the stand and see which way the Pan Axis swings.
front/rear
IFLIGHT STABILIZED GIMBAL SYSTEMS USER GUIDE
Copyright © 2015 IFLIGHT MODEL. All rights reserved.
IV. OPTIONAL EQUIPMENT
Bluetooth Module（OPtion to buy）
You can tune your gimbal controller without having to drag along a USB cable or using a computer, download SimbleBGC app on
your phone and enjoy the freedom of wireless.
How to connect using Bluetooth (PC)
1. Open devices and printers from the control panel.
2. Click add device in upper left hand corner.
3. Turn IFLIGHT G15 on. After a few seconds, Bestablecam will be visible.
4. Select Bestablecam
5. Enter 0000 for the devices pairing code.
After pairing is complete, find the SimplBGC device and right click properties. Go to the hardware tab and look for what COM number you have. (Example
COM4)
6. Open BaseCam software and under connection choose the correct COM# and click connect.
7. IFLIGHT G15 is now connected through Bluetooth. And all of the adjustments can be now done wirelessly.
IFLIGHT STABILIZED GIMBAL SYSTEMS USER GUIDE
Copyright © 2015 IFLIGHT MODEL. All rights reserved.
How to connect using Bluetooth ((Android))
(https://play.google.com/store/apps/details?id=ru.smartsoft.simplebgc&hl=en)
1. Install SimpleBGC from Play Store.
2. Click SimpleBGC App > Settings > Bluetooth
3. Turn IFLIGHT G15 on. After a few seconds, bestablecam will be visible.
4. Select bestablecam
5. Enter 0000 for the devices pairing code.
6. After pairing is complete, IFLIGHT G15 is now connected through Bluetooth. And all of the adjustments can be now done wirelessly.
