IEI Technology PPC-5020 Manuel utilisateur

PPC-5020

12.1”TFT Panel PC

(Ver 2.0)

The information in this document is subject to change without prior notice in order to

improve reliability, design and function and does not represent a commitment on the

part of the manufacturer.

In no event will the manufacturer be liable for direct, indirect, special, incidental, or

consequential damages arising out of the use or inability to use the product or

documentation, even if advised of the possibility of such damages.

This document contains proprietary information protected by copyright. All rights are

reserved. No part of this manual may be reproduced by any mechanical, electronic, or

other means in any form without prior written permission of the manufacturer.

Trademarks

PPC-5020 is a registered trademark of ICP Electronics Inc. IBM PC is a registered

trademark of International Business Machines Corporation. Intel is a registered

trademark of Intel Corporation. Other product names mentioned herein are used for

identification purposes only and may be trademarks and/or registered trademarks of

their respective companies. If you have any questions or need other information,

please visit to our web site.

http://www.iei.com.tw

Table of Contents

1. Introduction................................................................................. 3

1.1 Checklist ....................................................................... 3

1.2 Features......................................................................3-4

1.3 Specifications.............................................................4-5

1.4 Dimensions ................................................................... 6

2. System Setup............................................................................... 7

2.1 Assembly Diagram.....................................................7-9

2.2 POS-566/370 CPU Board Installation ........................ 10

2.3 Power Supply Installation......................................... 11

2.4 Drive Disk Installation......................................... 12-13

2.5 Speakers and Fan Installation ................................... 14

2.5 Panel Mounting......................................................... 15

2.6 Wall Mounting.......................................................... 16

2.7 Arm Mounting .......................................................... 17

2.8 Rack Mounting.......................................................... 18

Appendix A. Power Supply.......................................................... 19

Appendix B. Display Interface ................................................19-20

Appendix C. Control Panel Interface…………………………… 21

1Introduction

The PPC-5020, 12.1" high brightness LCD TFT Panel PC takes advantage of modern

flat-panel display technology, coupled with a POS-566/370 CPU board, one hard

drive bay and an integrated power supply to ensure minimum size. It is an IBM

PC/AT compatible computer specially designed to meet the applications in an

industrial environment.

1.1 Checklist

ITEM

DESCRIPTION Q’TY NOTES

1 PPC-5020 USERMANUAL 1

2 POWER CORD 1

3 WALL-MOUNT VIBRATION KIT2

4 WALL-MOUNT bracket 1

5 PANEL MOUNT KIT 4

6 SCERW KIT 1

6.1 SCREW BOLT (M4*P0.7*8mm) 4

6.2 Round with washer screw (M3*6)10

6.3 Sink with washer screw（M4*6）8

6.4 Round screw (M5*50)4

6.5 FLAT SCREW (6#32*6) 4

7 KEY WITH HDD 1

8 CF-507 SOKET-370 BLOWER COPPER COOLER

9 POS-370 OR POS-566 USER MANUAL 1 OPTION

10 DISK FOR SIS CHIP SET 1

11 MINI JUMPER SOME

12 Y CABLE. (MINI DIM TO MOUSE/KB) 1

13 TOUCH SCREEN DRIVER (option) 1 OPTION

1.2 Features

CPU Board

PPC-5020 is designed for POS-566/370 CPU board. The POS-566/370 board is a

LPX specification board, equipped with a high-performance socket 370 Celeron

Pentium III®CPU, LCD/CRT and 10/100Mbps Ethernet port, designed for system

manufacturers, integrators, or VARs to provide the ultimate in performance, reliability,

and quality.

LCD Display

The PPC-5020 is equipped with a high brightness 12.1" TFT LCD.

Power Supply

The PPC-5020 is equipped with a standard ACE-816APS 150W power supply with

PFC.

Touch Screen (option)

Aluminum front panel supports both resistive and capacity touch screens.

Plastic front panel supports a resistive touch screen only.

HDD

The PPC-5020 supportsone 3.5” removable HDD drive bay.

1.3 Specifications

Display Model SANYO

Display Type 12.1” TFT color

LCD model TM121SV-02L11

Resolution SVGA 800x600

Max. Colors Native 262k colors(r/g/b 6 bit each)

Brightness 360 cd/m2high luminance

LCD MTBF 50,000 hrs

Backlight MTBF 30,000 hrs

Nominal input Voltage VDD +3.3V

Support Voltage -0.3V to 4.0V

?? 3M touch resistive type touch screen (option)

Type: Analog Resistive

Resolution: Continuous

Light transmission: Typical value 72%

Surface Hardness: 4H (Test condition: ASTM D3363-92A)

8-wire touch screen

Support driver: Supports DOS, Windows 3.1, 95, 98, NT/Me/2000, WinCE. NET.

?? 3M touch capacitive type touch screen (option)

Type: Analog Resistive

Resolution: Continuous

Light transmission: Typical value 88%

Support driver: Supports DOS, Windows 3.1, 95, 98, NT/Me/2000, WinCE. NET.

Please download the capacitive type driver from IEI web site.

?? Environmental specifications

Operating Temperature: 0 ~ 50℃

Relative Humidity: 5~95 %, non-condensing

Vibration: 5 to 17 Hz, 0.1"double-amplitude displacement,

17 to 640 Hz, 1.5 G peak to peak.

1.4 Dimensions

Front Panel: 340mm x 260mm x 9mm (WxHxD)

Cabinet: 310mm x 230mm x 99mm (WxHxD)

2 System Setup

The PPC-5020, 12.1" LCD TFT Panel PC, is provided complete kit for your operation.

The following sections of this chapter will help your installation and maintenance.

2.1 Assembly Diagram

The Reverse Side of PPC-5020

The diagram shows below the reverse side of PPC-5020. For maintenance,

installation or upgrade, you will need to remove the back cover first by unfastening

the 9 screws as shown in the diagram.

Warning: Before any installation/un-installation, please notice any effects of static

electricity.

The Reverse Side of the Rear Cabinet

The following figure shows the reverse side of the rear cabinet.

One HDD and one power supply are accessible for operation on the driver frame.

?? POS-566

?? POS-370

The Side View of PPC-5020

On the side panel, you will find one fan and two speakers. Please bear this in mind

when mounting the unit. It is placed in to the cabinet and then fastened by four

screws.

FAN

SPEAKER
