Innovative DisplayWorks
G-11/GCG-11c
Instruction Manual
65
PREPARATION PRIOR TO OPERATION
•Remove all packaging materials before using cooler.
Thisincludes:foampedestal,adhesivetape(usedtoxaccessories)andprotectivegaskets.
• Inspectcoolerforconcealeddamage.Immediatelyleaclaimwiththefreightcarrierifthereisdamage.
IDW is not responsible for damage incurred during shipping.
•For proper operation, place the cooler on a dry, level surface.
• Cleantheinteriorsurfacewithasoftclothandlukewarmwaterbeforeoperation.
•Keep cooler in an upright position for 30 minutes prior to use.
• IDWrequiresthatasoleusecircuitbededicatedfortheunit.Failuretodosovoidswarranty.
WARNING:Donotuseextensioncords.
WARNING:Compressorwarrantiesarevoidifcompressorburnsoutduetolowvoltage.
WARNING:Powercordshouldnotberemovedoralteredinanyway.
Leveling
•Setunitinitsnallocation,makingcertainthereisadequateventilationintheroom.
WARNING:Warrantyisvoidifventilationisinsufcient.
•Proper leveling of the GCG-11c cooler is critical to it operating correctly. Condensation removal and door
operationwillbeaffectedbyleveling.
<The cooler should be leveled front to back and side to side with a level.
•Ensure that drain hose or hoses are positioned in the pan.
•Removeplugandcordfrominsidethelowerrearofthecooler.
•Theunitshouldbeplacedcloseenoughtotheelectricalsupplysothatextension
cords are never used.
Shelving Installation (Maximum load per shelf is 9kg.)
•Position all four
shelf clips equal
in distance
from the
oor
forat
shelves.
•Hook shelf
clips on
shelf
strip.
•Place shelf on
shelf clips.
FEATURES
•Designed with an elegant shape and quick refrigeration speed, this commercial-grade product is an ideal choice for
shopping malls, supermarkets, hotels, etc.
•Transparent glass doors are built with hollow, toughened glass that provides a high level of heat insulation. Clear
doors allow for high product visibility.
•The forced air system allows for fast cooling speeds, which helps maintain a consistent temperature.
•Adjustable shelves allow for a wide variety of products to be stocked.
•A built-in lock offers the ability to secure products.
•The refrigeration unit is designed for easy access, allowing for fast and simple repairs.
•This equipment is intended for storage and display of non-hazardous packaged product.
CAUTION FLAMMABLE REFRIGERANT
•WARNING – Keep clear of obstruction all ventilation openings in the appliance enclosure or in the structure for
building-in.
• WARNING – Do not use mechanical devices or other means to accelerate the defrosting process, other than those
recommended by the manufacturer.
• DO NOT damage the refrigerant circuit..
• DO NOT use electrical appliances inside the food storage compartments of the appliance, unless they are of the type
recommended by the manufacturer.
INSTRUCTIONS
Ambient Environment
•Place cooler on an even surface to reduce vibration and noise.
•To transport, do not tilt the cooler beyond a 45 degree angle.
•Do not place cooler in direct sunlight or near any heat sources.
•Do not place cooler in environment temperatures that exceed 109°F.
•Do not place cooler in below normal temperatures.
•Do not place cooler in extreme humid environments, this may cause components to rust.
•Do not place cooler near constant running or splattering water, this may cause immediate damage to refrigeration
system.
•Must allow at least 2” between rear of cooler and wall for proper ventilation and heat dissipation of cooler.
•Do not place furniture or other articles with sharp edges near the cooler in order to prevent damage to the glass door.
4”
